2008 MERCEDES-BENZ R350 Owner's Manual

304 Controls in detail
Useful features
Storage compartments Glove box/CD changer*
1Glove box lid release
2Glove box lid
Opening the glove box
Pull lid release1 in direction of arrow.
Glove box lid2 opens downward.Closing the glove box
Push glove box lid 2 up to close.
Releasing CD changer*
1Release button
2CD changer
3AUX-socket
Open the glove box.
Press release button 1.
CD changer 2 is released and swings
down automatically.
For information on CD changer operation,
see separate COMAND system operating
instructions.
Warning!G
To help avoid personal injury during a
collision or sudden maneuver, exercise care
when storing objects in the vehicle. Put
luggage or cargo in the cargo compartment
if possible. Do not pile luggage or cargo
higher than the seat backs.
Always use cargo net* when transporting
cargo. Cargo net* cannot secure hard or
heavy objects.
Parcel nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during

braking

vehicle maneuvers

an accident
iDepending on vehicle equipment, a
CD changer* and an AUX-socket are located in
the glove box.

305 Controls in detail
Useful features
Closing CD changer*
1CD changer
Gently push CD changer 1 up in
direction of arrow until it engages.
For information on CD changer operation,
see separate COMAND system operating
instructions.
Locking and unlocking the glove box
separately
You can lock the glove box separately, e.g.
when the vehicle is in the shop for service.
Take the mechanical key out of the
SmartKey or SmartKey with
KEYLESS-GO* (
page 474).
1Unlocking glove box
2Locking glove box
Insert mechanical key into glove box
lock.
Turn mechanical key to position 2 to
lock the glove box.
Turn mechanical key to position 1 to
unlock the glove box.Storage compartment in front center
console
1Cover
2Chrome label
Tab lightly on chrome label 2 of
cover1.
Cover 1 swings open.
iThe glove box can only be locked or
unlocked with the mechanical key.

306 Controls in detail
Useful features
Front armrest storage compart-
ment/telephone* tray
The storage compartment and the
telephone* tray can be opened separately.
1Button to open telephone* tray
2Button to open storage compartment3Telephone tray
4Coinholders
Opening the storage compartment
Press button2 and lift up armrest.
Opening the telephone tray
Press button1 and lift up armrest.
Two coin holders 4 are located in front of
telephone tray 3.Rear armrest storage compartment*
A storage compartment is located in the
armrest of the rear center console*
between the second-row seats.
Press button under armrest and lift up
armrest.
iIf your vehicle is equipped with Rear Seat
Entertainment Package*, the storage compart-
ment contains the DVD player (see separate
operating instructions).
iThe mobile phone cradle (page 320), the
Roadside Assistance button• (
page 325)
and the Information button¡ (
page 326)
are located in telephone tray 3.

307 Controls in detail
Useful features
Rear storage compartment
A storage compartment is located in front
of the second-row seats.Third-row storage compartment
Storage compartments are located on the
side trims of the third-row seats.
1Storage compartmentParcel nets
iDepending on vehicle equipment, the upper
storage compartment may be replaced by a
control panel, for example in vehicles with rear
climate control* (
page 220) or rear automatic
climate control* (
page 236).
iIf your vehicle is equipped with a
3-zone automatic climate control*, the storage
compartment is replaced by an adjustable air
vent (
page 240).
Warning!G
Do not place objects with a combined
weight of more than 4.4 lbs (2 kg) into the
parcel net on the back of the front passen-
ger seat. Otherwise, the Occupant
Classification System OCS (
page 77) may
not be able to properly approximate the
occupant weight category.
Parcel nets are intended for storing
light-weight items only.
Heavy objects, objects with sharp edges, or
fragile objects may not be transported in the
parcel nets. In an accident, during hard
braking, or sudden maneuvers, they could
be thrown around inside the vehicle and
cause injury to vehicle occupants.
Parcel nets cannot protect transported
goods in the event of an accident.

308 Controls in detail
Useful features
Parcel net in front passenger footwell
1Parcel net
Parcel nets on front seat backrests
1Parcel netCup holders
Cup holders in front center console
A cupholder and a card/ticket holder with
bottle opener are located in the front
center console.
1Cup holders
Warning!G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep rear cup holders
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an
accident.
Keep in mind that objects placed in a cup
holder may come loose during braking,
vehicle maneuvers, or an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle in-
terior may cause an accident and/or serious
personal injury.

309 Controls in detail
Useful features
Card/ticket holder with bottle opener
A card/ticket holder and a bottle opener
are located in the cup holder of the front
center console.
Cards and tickets can be inserted into the
slot in the middle. The card/ticket holder
is removable and has a bottle opener
underneath.
Removing
1Card/ticket holder with bottle opener
Lift card/ticket holder 1 at the rear
and take it out.The bottle opener is located underneath
the card/ticket holder and has openers for
crown caps and screw caps.
2Opener for screw caps
3Opener for crown capsReinserting
1Tabs
2Card/ticket holder
Guide tabs 1 into openings.
Guide rear of card/ticket holder 2
into the cupholder.iWith the card/ticket holder removed, you
can also take the rubber inlet from the cupholder
for cleaning.

310 Controls in detail
Useful features
Cup holder in front of second-row seats
A cupholder is located in front of the
second-row seats.
Opening cup holder
Open ashtray cover1(page 312).
1Ashtray cover
Press ashtray cover 1 down in
direction of arrow as far as it will go.
1Ashtray cover
2Cup holder
Pull out cup holder 2 in direction of
arrow as far as it will go.Closing cup holder
Make sure you have removed all
containers from the cup holder.
Push cup holder 2 in until it engages.
Close ashtray cover.
Cupholders in rear center console*
Cupholders are located on the rear center
console between the second-row seats.
1Cup holders
!Close the cup holder when not in use and
before folding the second-row seats.
iVehicles with rear center console*
(
page 315) are not equipped with cupholders
in front of the second-row seats.

311 Controls in detail
Useful features
Cupholders in third-row side trim
Cupholders are located in the side trims of
the third-row seats.
1Cup holderAshtrays
Your vehicle is equipped with an ashtray
and a cigarette lighter (
page 313)
located in the front center console and an
ashtray located in front of the second-row
seats (
page 312).
Ashtray in the front center console
Opening the ashtray
1Cover
2Chrome label
Tab lightly on chrome label 2 of
cover1.
Cover 1 swings open.
Removing ashtray insert
Warning!G
Remove ashtray insert only with vehicle
standing still. Set the parking brake to
secure vehicle from movement. Set auto-
matic transmission toP. With the automatic
transmission set toP, turn off the engine.
