2008 MERCEDES-BENZ R350 Owner's Manual

168 Controls in detail
Control system

With the COMAND system switched on
and route guidance activated, the
direction of travel and maneuver in-
structions appear in the multifunction
display.
Please refer to the COMAND system
manual for instructions on how to activate
the route guidance system.AIRMATIC*/Compass menu
The
AIRMATIC/Compass menu displays the
AIRMATIC* messages and the direction
into which you are currently driving.
Press buttonè orÿ repeatedly
until the
AIRMATIC/Compass menu
appears in the multifunction display.
For information on AIRMATIC*, see
“AIRMATIC*” (
page 276).
For information on the compass, see
“Vehicle submenu” (
page 180) and
“Compass” (
page 334).
Distronic* menu
Use the
DISTRONIC menu (page 267) to
display the current settings for your
Distronic system. The information shown
in the multifunction display depends on
whether the Distronic system is activated
or deactivated.
Please refer to the “Driving systems”
section of this manual (
page 262) for
instructions on how to activate Distronic.
Press buttonè orÿ repeatedly
to select the Distronic menu in the
multifunction display.

169 Controls in detail
Control system
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the
system. Such messages appear in the
multifunction display and are based on
conditions or system status the vehicle’s
system has recorded.
The vehicle status message memory menu
only appears, if messages have been
stored.
Press buttonè orÿ repeatedly
until the vehicle status message
memory appears in the multifunction
display.If conditions have occurred causing status
messages to be recorded, the number of
messages appears in the multifunction
display:
Press buttonk orj.
The stored messages will now be
displayed in the order in which they
have occurred. For malfunctions and
warning messages, see “Vehicle status
messages in the multifunction display”
(
page 427).
Warning!G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Light Truck Center to address the malfunc-
tion and warning messages (
page 427).
iAfter you have scrolled through all recorded
status messages, the first recorded message
appears again.

170 Controls in detail
Control system
Should the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display

when the SmartKey in the starter
switch is turned to position0 or
removed from the starter switch
or

when you turn off the engine by
pressing the KEYLESS-GO* start/stop
button (
page 66) in the starter
switch once and open the driver’s door
(this puts the starter switch in
position0, same as with the SmartKey
removed from the starter switch)
Settings menu
In the
Settings menu there are two
functions:

The function Reset to factory
settings?
, with which you can reset all
the settings to the original factory
settings.

A collection of submenus with which
you can make individual settings for
your vehicle.
Press buttonè orÿ repeatedly
until the
Settings menu appears in the
multifunction display.The following settings and submenus are
available in the
Settings menu:
iThe vehicle status message memory will
be cleared when you turn the SmartKey in the
starter switch to position1 or2, or when you
press the KEYLESS-GO* start/stop button once
or twice without depressing the brake pedal. You
will then only see high priority messages in the
multifunction display (
page 427).
FunctionPage
Resetting all settings171
Submenus in the Settings menu171
Instrument cluster submenu174
Time/Date submenu176
Lighting submenu177
Vehicle submenu180
Comfort submenu*183

171 Controls in detail
Control system
Resetting all settings
You can reset the functions of all
submenus to the factory settings.
Press the reset button in the
instrument cluster (
page 154) for
approximately 3 seconds.
The request to press the reset button
once more to confirm appears in the
multifunction display.
Press the reset button once more.
The functions of all the submenus will
reset to factory settings.Submenus in the Settings menu
Press buttonj.
The collection of the submenus
appears in the multifunction display.
Press buttonç.
The selection marker moves to the next
submenu.
The submenus are arranged by hierarchy.
Scroll down with buttonç, scroll up
with buttonæ.
iThe settings you have changed will not be
reset unless you confirm the action by pressing
the reset button a second time.
After approximately 5 seconds, the
Settings
menu reappears in the multifunction display
(
page 170).
iFor safety reasons, the function
Lamp Circuit Headlamp in the Lighting
submenu cannot be reset while driving.
The following message appears in the multifunc-
tion display:
Settings
Cannot be
completely reset
to factory settings
while driving
.

172 Controls in detail
Control system
With the selection marker on the desired
submenu, use thej button to access
the individual functions within that sub-
menu. Once within that submenu, you can
use thejbutton to move to the next
function or thekbutton to move to the
previous function within that submenu.
The settings themselves are made with
buttonæ orç.

173 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus.
Detailed instructions on making individual
settings can be found on the following
pages.
Instrument clusterTime/DateLightingVehicleComfort*
(page 174)(page 176)(page 177)(page 180)(page 183)
Selecting speedometer display
modeSetting the timeSetting daytime running
lamp mode (USA only)Compass adjustmentActivating
easy-entry/exit feature*
Selecting languageSetting the dateSetting locator lightingCompass calibrationSetting fold-in function
for exterior rear view
mirrors*
Selecting display (digital
speedometer or outside
temperature) for status indicatorSetting night security
illuminationAudio search function
Setting interior lighting
delayed shut-offSetting automatic
locking
Limiting opening height
of tailgate*

174 Controls in detail
Control system
Instrument cluster submenu
Access the
Instrument Cluster submenu
via the
Settings menu. Use the
Instrument Cluster submenu to change
the instrument cluster display settings.
The following functions are available:Selecting speedometer display mode
Move the selection marker with
buttonæ orç to the
Instrument Cluster submenu.
Press buttonj ork repeatedly
until the message
Display Unit
Digital Speedometer
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to set
speedometer unit to
Km or Miles.Selecting language
Move the selection marker with
buttonæ orç to the
Instrument Cluster submenu.
Press buttonj ork repeatedly
until the message
Language appears in
the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to select
the language to be used for the
multifunction display messages.
FunctionPage
Selecting speedometer display
mode174
Selecting language174
Selecting display (digital
speedometer or outside
temperature) for status indicator175
iIf you select a language that is not available
in the COMAND system, the messages for the
audio systems, such as radio or CD player, will
appear in English, regardless of the language
selected. For more information see separate
COMAND operating instructions.

175 Controls in detail
Control system
Available languages:

German

English

French

Italian

Spanish

Dutch

Danish

Swedish

Portuguese

Turkish

Russian (Canada only)Selecting display (digital speedometer
or outside temperature) for status
indicator
Move the selection marker with
buttonæ orç to the
Instrument Cluster submenu.
Press buttonj ork repeatedly
until the message
Status Line
Display
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
the desired setting.
The selected display is then shown
continuously in the status indicator
(lower display).
The other display now appears in the
menu of the standard display
(
page 165):

Digital speedometer
or

Outside temperature
