2008 MERCEDES-BENZ R350 Owner's Manual

144 Controls in detail
Lighting
Low beam headlamps
Turn the exterior lamp switch to
positionB.
With the SmartKey in starter switch
position1or the KEYLESS-GO*
start/stop button pressed once, the
following lamps will switch on:

Tail and parking lamps

License plate lamps

Side marker lamps
With the SmartKey in starter switch
position1or the KEYLESS-GO*
start/stop button pressed once,
the following lamps will switch on addi-
tionally:

Low beam headlamps

High beam headlamps (when the
combination switch is pushed
forward)Automatic headlamp mode
The following lamps switch on and off
automatically depending on the brightness
of the ambient light:

Low beam headlamps

Tail and parking lamps

License plate lamps

Side marker lamps
Warning!G
If the exterior lamp switch is set toU,
the headlamps will not be automatically
switched on under foggy conditions.
To minimize risk to you and to others,
activate headlamps by turning exterior lamp
switch toB when driving or when traffic
and/or ambient lighting conditions require
you to do so.
In low ambient lighting conditions, only
switch from positionU toB with the
vehicle at a standstill in a safe location.
Switching fromUtoB will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.
The automatic headlamp feature is only an
aid to the driver. The driver is responsible for
the operation of the vehicle’s lights at all
times.

145 Controls in detail
Lighting
Turn the exterior lamp switch to
positionU.
With the SmartKey in starter switch
position1 or the KEYLESS-GO*
start/stop button pressed once, only
the parking lamps and the side marker
lamps will switch on and off depending
on the brightness of the ambient light.
When the engine is running, the low
beam headlamps, the tail and parking
lamps, the license plate lamps, and the
side marker lamps will switch on and
off depending on the brightness of the
ambient light.Daytime running lamp mode
In Canada the daytime running lamp mode
is mandatory and therefore in a constant
mode.
In the USA the daytime running lamp mode
is deactivated by default. Activate the day-
time running lamp mode using the control
system, see “Setting daytime running lamp
mode (USA only)” (
page 177).
Turn the exterior lamp switch to
positionM orU.
When the engine is running, the low
beam headlamps are switched on.
In low ambient light conditions, the
following lamps will switch on addition-
ally:

Tail and parking lamps

License plate lamps

Side marker lampsCanada only:
When the engine is running and you shift
from a driving position to positionN orP
with the vehicle at a standstill, the low
beam headlamps will switch off with a
three-minute delay.
When the engine is running and you

turn the exterior lamp switch to
positionC, the low beam head-
lamps, the tail and parking lamps, the
side marker lamps and the license
plate lamps switch on

turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime
running lamp mode
iCanada only:
High beam headlamps are only available with the
exterior lamp switch in position B.
iWith the daytime running lamp mode activat-
ed and the engine running, you cannot switch off
the low beam headlamps manually.
iWith the exterior lamp switch in
positionM orU, you cannot switch on the
high beam headlamps.
The high beam flasher is available at all times.
For nighttime driving, turn the exterior lamp
switch in positionB to permit activation of
the high beam headlamps.

146 Controls in detail
Lighting
USA only
When the engine is running, and you turn
the exterior lamp switch to positionC
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 143).Locator lighting and night security
illumination
The locator lighting and the night security
illumination are described in the “Control
system” section, see “Setting locator light-
ing” (
page 178) and “Setting night secu-
rity illumination” (
page 179).Fog lamps
iWith the daytime running lamp mode
activated and the exterior lamp switch in
positionM, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving, turn the exterior lamp
switch in positionB orU to permit
activation of the high beam headlamps.
Warning!G
In low ambient lighting or foggy conditions,
only switch from positionU toB with
the vehicle at a standstill in a safe location.
Switching fromU toB will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.
iFog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
iFog lamps cannot be switched on with the
exterior lamp switch in positionU. To switch
on the fog lamps, turn the exterior lamp switch to
positionB first.

147 Controls in detail
Lighting
Front fog lamps
Turn the exterior lamp switch to
positionC orB (
page 143).
Pull out the exterior lamp switch to first
stop.
The front fog lamps switch on.
The green indicator lamp‡ in the
exterior lamp switch comes on.
Push in the exterior lamp switch.
The front fog lamps switch off.
The green indicator lamp‡ in the
exterior lamp switch goes out.Rear fog lamp (driver’s side only)
Turn the exterior lamp switch to
positionB (
page 143).
Pull out the exterior lamp switch to
second stop.
The rear fog lamp switches on.
The yellow indicator lamp† in the
exterior lamp switch comes on.
Push in the exterior lamp switch to first
stop.
The rear fog lamp switches off.
The yellow indicator lamp† in the
exterior lamp switch goes out.
The front fog lamps remain lit.
Combination switch
1High beam
2High beam flasher
High beam
Turn the exterior lamp switch to
positionB (
page 143).
iThe front fog lamps will also switch on.


148 Controls in detail
Lighting
Push the combination switch in
direction of arrow1 to switch on the
high beam.
The high beam headlamp indicator
lampAin the instrument cluster
comes on (
page 29).
Pull the combination switch in direction
of arrow2 to its original position to
switch off the high beam.
The high beam headlamp indicator
lampAin the instrument cluster
goes out.
High beam flasher
Pull the combination switch briefly in
direction of arrow2.
Corner-illuminating front fog lamps*
The corner-illuminating front fog lamps
improve illumination of the area in the
direction into which you are turning.
The corner-illuminating front fog lamps will
operate with the engine running and with

the exterior lamp switch in
positionB (
page 143)
or

the exterior lamp switch in
positionU (
page 143)
or

the daytime running lamp mode
activated (
page 145)Driving forward
Switching on corner-illuminating front
fog lamps
Switch on the left or right turn signal
(
page 59), depending on whether
you are turning left or right.
The respective front fog lamp comes on
and illuminates the area in the
direction into which you are turning.
or
Turn steering wheel in desired direc-
tion.
The front fog lamp on the side of your
steering direction comes on.
iThe corner-illuminating front fog lamps will
only come on in low ambient lighting conditions.
iIf you are driving faster than
25 mph (40 km/h) or have the front fog lamps
switched on, the corner-illuminating function is
not available.
iIf you have switched on the turn signal for
one side but turn the steering wheel in the
opposite direction, the corner-illuminating front
fog lamp comes on for the side indicated by the
turn signal.
The corner-illuminating front fog lamp remains lit
for a maximum of three minutes. Afterwards, it
goes out even if the turn signal is still switched
on.


149 Controls in detail
Lighting
Switching off corner-illuminating front
fog lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating front fog lamps if they
were activated by switching on the left or
right turn signal.
If the turn signal should stay on after
making the turn, the turn signal and
corner-illuminating front fog lamps can be
switched off by returning the combination
switch to its original position.Driving in reverse
Switching on corner-illuminating front
fog lamps
Shift the automatic transmission to
reverse gearR (
page 192).
The front fog lamp opposite to your
steering direction comes on.
Switching off corner-illuminating front
fog lamps
Shift the automatic transmission
to a gear other than reverse
gearR(
page 190).
The respective front fog lamp goes out.
iThe corner-illuminating front fog lamps tem-
porarily come on both sides of the vehicle if you
turn the steering wheel in one direction and then
again in the other direction shortly thereafter.
iThe corner-illuminating front fog lamps will
come on automatically depending on the steer-
ing angle, even if you did not switch on either
turn signal. If the corner-illuminating front fog
lamps came on automatically, they will also go
out automatically depending on the steering
angle.
iThere may be a brief delay before the
corner-illuminating front fog lamps switch off.

150 Controls in detail
Lighting
Hazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher switches on
automatically when an air bag deploys.
The hazard warning flasher switch is
located on the upper part of the center
console.
1Hazard warning flasher switchSwitching on hazard warning flasher
Press hazard warning flasher
switch1.
All turn signals are flashing.
Switching off hazard warning flasher
Press hazard warning flasher switch1
again.
Interior lighting
1Front left reading lamp, on/off
2Rear interior lighting, on/off
3Automatic interior lighting
4Front interior lighting, on/off
5Front right reading lamp, on/off
6Front right interior lamp
7Reading lamps
8Front left interior lamp
iWith the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the ignition is
switched on.
iIf the hazard warning flasher has been
activated automatically, press hazard warning
flasher switch1 once to switch it off.

151 Controls in detail
Lighting
The controls are located in the overhead
control panel.
Deactivating automatic control
Press switch3.
The interior lighting and the locator
lighting (
page 178) remain switched
off even when you

unlock the vehicle

remove the SmartKey from the
starter switch

open a door

open the tailgateActivating automatic control
Press switch3.
The interior lighting and the locator
lighting (
page 178) come on when
you

unlock the vehicle

remove the SmartKey from the
starter switch

open a door

open the tailgate
The interior lighting switches off after
10 seconds see “Setting interior lighting
delayed shut-off” (
page 180).Manual control
Switching front/rear interior lighting on
and off
Press front/rear interior lighting
switch4 or 2 (
page 150) to switch
on the desired interior light.
Press front/rear interior lighting
switch4 or 2 again to switch off the
respective interior light.
Switching front reading lamps on and off
The front reading lamps are located in the
lower edge of the interior rear view mirror.
Press front reading lamp
switch1or5 (
page 150) to
switch on the desired front reading
lamp.
Press front reading lamp
switch1or5 again to switch off the
respective front reading lamp.
!An interior lamp switched on manually does
not go out automatically.
Leaving an interior lamp switch in the ON
position for extended periods of time with the
engine turned off could result in a discharged
battery.
iThe interior lighting is factory-set to
automatic mode.
iIf a door remains open, the interior lighting
switches off automatically after approximately
5minutes.
