2008 MERCEDES-BENZ R350 Owner's Manual

240 Controls in detail
3-zone automatic climate control*
Rear automatic climate control
(second and third row)*
The rear automatic climate control for the
second and third row* is operated in the
same manner as the rear automatic
climate control for the second row
(
page 236).
Air vents are located in the left and right
side trim below the rear quarter windows.
1Defrost air vent for rear quarter
window, fixed
2Air vent, adjustable
3Thumbwheel for air volume controlAdjusting air volume
Turn thumbwheel 3 downwards to
increase the air volume.
or
Turn thumbwheel 3 upwards to
decrease the air volume.
Adjusting air distribution
Move air vent slider 2 to the left, right,
up, or down.
The air is directed in the desired
direction.

241 Controls in detail
Power windows
Power windows
The door windows and the hinged quarter
windows* are opened and closed electri-
cally. The switches for all door windows
and the hinged quarter windows* are
located on the driver’s door control panel.
The switches for the respective door win-
dows are located on the front passenger
door and the rear doors. The hinged
quarter windows* can be operated from
the driver’s seat only.
Switch on the ignition (page 39).
Warning!G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
Activate the override switch (
page 97)
when children are riding in the back seats of
the vehicle. The children could otherwise in-
jure themselves, e.g. by becoming trapped
in the window opening.
The closing of a door window can be imme-
diately halted by releasing the switch or, if
switch was pulled past the resistance point
and released, by either pressing or pulling
the respective switch.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you pulled the switch past the resistance
point and released it to close the door win-
dow, the automatic reversal function will
stop the door window and open it slightly.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you are closing a door window by pulling and
holding the switch, or by pressing and hold-
ing button‹on the SmartKey, by press-
ing and holding the lock button (vehicles
with KEYLESS-GO*) on the door handle, the
automatic reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from starter switch, take it with you, and
lock the vehicle. Do not leave childrenunattended in the vehicle, or with access to
an unlocked vehicle. A child’s unsupervised
access to a vehicle could result in an
accident and/or serious personal injury.
iYou can also open or close the windows
using the SmartKey, see “Summer opening
feature” (
page 244) and “Convenience
closing feature” (
page 245).
Depending on the current position, the power
windows may also open or close when the air
recirculation button:on the control panel
of the climate control (
page 210) or automatic
climate control* (
page 224) is pressed and
held.
iAfter switching off the ignition (page 39)
or removing the SmartKey from the starter
switch, the windows can be operated

until you open the driver’s or front passenger
door

for at least 5 minutes if nor door was opened

242 Controls in detail
Power windows
Door windows
1Left front door window
2Right front door window
3Right rear door window
4Left rear door windowOpening the door windows
Press switch1, 2, 3, or4
(
page 242) to the resistance point.
The corresponding door window moves
downwards until you release the
switch.
Closing the door windows
Pull switch1, 2, 3, or4
(
page 242) to the resistance point.
The corresponding door window moves
upwards until you release the switch.Fully opening the door windows
(Express-open)
Press switch1, 2, 3, or4
(
page 242) past the resistance point
and release.
The corresponding door window opens
completely.
Fully closing the door windows
(Express-close)
Pull switch1, 2, 3, or4
(
page 242) past the resistance point
and release.
The corresponding door window closes
completely.
Warning!G
If you pull and hold the switch up when clos-
ing the door window, and upward movement
of the door window is blocked by some
obstruction including but not limited to
arms, hands, fingers, etc., the automatic
reversal will not operate.
Warning!G
Driver’s door only:
If within 5 seconds switch is again pulled
past the resistance point and released, the
automatic reversal will not function.

243 Controls in detail
Power windows
Remove the obstruction.
Pull the respective door window switch
past the resistance point again and
release.
Stopping door windows during
Express-operation
Press or pull the respective door
window switch again.
Hinged quarter windows*
The switches for opening and closing the
hinged quarter windows are located on the
door control panel of the driver’s door.
1Hinged quarter windows: opening
2Hinged quarter windows: closingOpening
Press and release switch 1.
To stop the hinged quarter window:
Press and release switch 1 once
more.
Closing
Press and release switch 2.
To stop the hinged quarter window:
Press and release switch 2 once
more.
iIf the upward movement of a door window is
blocked during the closing procedure, the door
window will stop and open slightly.
iIf the door window still does not close when
there is no obstruction, pull and hold the respec-
tive power window switch. The door window will
then close without the obstruction sensor
function.
iWhen the obstruction sensor detects the
hinged quarter window is blocked during the
closing process, it will stop and open slightly.

244 Controls in detail
Power windows
Synchronizing the door windows
The door windows must be synchronized

after the battery was disconnected

if the door windows cannot be fully
opened (Express-open) or closed
(Express-close)
Close all doors.
Switch on the ignition (page 39).
Pull and hold switch1, 2, 3, or4
(
page 242).
Once a door window is closed
completely, hold the respective switch
for approximately 3 seconds.
The door window is synchronized.
Summer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously

opening the door windows

opening the hinged quarter windows*

opening the tilt/sliding sunroof* (or
the tilt/sliding panel*)

switching on the seat ventilation* for
the driver’s seat
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle.
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.
Vehicles without tilt/sliding panel
Press and hold buttonŒon the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* have reached
the desired position.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.
iEach door window must be synchronized
separately.

245 Controls in detail
Power windows
Vehicles with tilt/sliding panel*
If roller sunblinds are closed:
Press and hold buttonŒon the
SmartKey or SmartKey with
KEYLESS-GO*.
The windows and roller sunblinds begin
to open after approximately 1 second.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.
With the windows and roller sunblinds
fully opened, press and hold
buttonŒon the SmartKey or
SmartKey with KEYLESS-GO* once
more.
The tilt/sliding panel opens.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.If roller sunblinds are open:
Press and hold buttonŒon the
SmartKey or SmartKey with
KEYLESS-GO*.
The windows and the tilt/sliding panel
begin to open after approximately
1 second.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.
Convenience closing feature
When locking the vehicle, you can simulta-
neously close

the door windows

the hinged quarter windows*

the tilt/sliding sunroof* (or the
tilt/sliding panel*)
Warning!G
When closing the windows and the
tilt/sliding sunroof* (or tilt/sliding panel*),
make sure that there is no danger of anyone
being harmed by the closing procedure.
If potential danger exists, proceed as
follows:

Release button‹to stop the closing
procedure. To open, press and hold
button Œ. To continue the closing
procedure after making sure that there
is no danger of anyone being harmed by
the closing procedure, press and hold
button ‹.


246 Controls in detail
Power windows
Vehicles without tilt/sliding panel
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 244).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close
proximity to the driver’s door handle.
Press and hold button‹on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* are completely
closed.
Release button‹on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 68) until
the windows and the tilt/sliding
sunroof* are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.Vehicles with tilt/sliding panel*
If tilt/sliding panel is closed:
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 244).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close
proximity to the driver’s door handle.
Press and hold button‹on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the roller sunblinds are completely
closed.
Release button‹on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
Vehicles with KEYLESS-GO*:

Release the lock button (page 68) on
the driver’s outside door handle to stop
the closing procedure.

Immediately pull on the same outside
door handle and hold firmly. The
windows and the tilt/sliding sunroof*
(or tilt/sliding panel*) will open for as
long as the door handle is held but the
door is not opened.


247 Controls in detail
Power windows
Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 68) until
the windows and the roller sunblinds
are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.
If tilt/sliding panel is open:
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 244).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close
proximity to the driver’s door handle.
Press and hold button‹on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding panel* are completely
closed.
Release button‹on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
With the windows and the tilt/sliding
panel completely closed, press and
hold button‹on the SmartKey or
SmartKey with KEYLESS-GO* once
more.
The roller sunblinds close.
Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 68) until
the windows and the tilt/sliding panel*
are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.
With the windows and the tilt/sliding
panel completely closed, press and
hold the lock button on an outside door
handle (
page 68) once more.
The roller sunblinds close.
