2008 MERCEDES-BENZ R350 Owner's Manual

536 Technical data
Fuels, coolants, lubricants, etc.
Capacities
Vehicle components and their respective
lubricants must match. Therefore only use
products tested and approved by
Mercedes Benz.
Please refer to the Factory Approved
Service Products pamphlet (USA only), or
inquire at an Mercedes-Benz Light Truck
Center.
Warning!G
Comply with all valid regulations with re-
spect to handling, storing and disposing of
service fluids. Otherwise you could endan-
ger persons or the environment.
Keep service fluids out of the reach of chil-
dren.
For health reasons, you should prevent
service fluids from coming into direct
contact with your skin or clothing.
If a service fluid is swallowed, contact a
physician immediately.
ModelCapacityFuels, coolants, lubricants, etc.
Engine with oil filterR 320 CDI 4MATIC9.0 US qt (8.5 l)Approved engine oils
R 3501, R 350 4MATIC
1USA only.
8.5 US qt (8.0 l)
R 550 4MATIC2
2Canada only.
9.5 US qt (9.0 l)
Automatic transmission9.5 US qt (9.0 l)MB Automatic Transmission Fluid
Transfer case0.53 US qt (0.5 l)MB Automatic Transmission Fluid
Rear axle1.2 US qt (1.1 l)Hypoid gear oil
Front axle1.2 US qt (1.1 l)Hypoid gear oil

537 Technical data
Fuels, coolants, lubricants, etc.
ModelCapacityFuels, coolants, lubricants, etc.
Power steeringapprox. 1.3 US qt (1.2 l)MB Power Steering Fluid or approved
Dexron III ATF
Front wheel hubsapprox. 1.5 oz (43 g) eachHigh temperature roller bearing grease
Brake systemMB Brake Fluid (DOT 4+)
Cooling systemR 320 CDI 4MATIC10.0 US qt (9.5 l)MB Anticorrosion/Antifreeze
R 3501, R 350 4MATIC
1USA only.
10.0 US qt (9.5 l)
R 550 4MATIC2
2Canada only.
12.7 US qt (12 l)
Fuel tank
including a reserve of21.1 US gal (80.0 l)
approx. 3.4 US gal (13.0 l)Gasoline engine:
Premium unleaded gasoline:
Minimum Posted Octane 91
(Avg.of96RON/86MON)
Diesel engine:
ULTRA-LOW SULFUR HIGHWAY DIESEL
FUEL (15 ppm SULFUR MAXIMUM)

538 Technical data
Fuels, coolants, lubricants, etc.
Engine oils
Engine oils are specifically tested for their
suitability in our engines and durability for
our service intervals. Therefore, only use
approved engine oils and oil filters
required for vehicles with Maintenance
System. For a listing of approved engine
oils and oil filters, refer to the Factory
Approved Service Products pamphlet (USA
only), or contact an authorized
Mercedes-Benz Light Truck Center.Engine oil additives
Air conditioning refrigerant
R-134a (HFC) refrigerant and special PAG
lubricating oil are used in the air condition-
ing system.
ModelCapacityFuels, coolants, lubricants, etc.
Air conditioning systemR-134a refrigerant and special PAG lubricant
oil (never R-12)
Windshield washer
system and headlamp
cleaning system*8.0 US qt (7.6 l)MB Windshield Washer Concentrate1
1Use MB Windshield Washer Concentrate “MB SummerFit” and water for temperatures above freezing point or MB Windshield Washer Concentrate “MB SummerFit”
and commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point. Follow suggested mixing ratios (page 544).
!Using engine oils and oil filters of
specification other than those expressly
required for the Maintenance System, or chang-
ing of oil and oil filter at change intervals longer
than those called for by the Maintenance System
will result in engine or emission control system
damage not covered by the Mercedes-Benz
Limited Warranty.
Please follow Maintenance System recommen-
dations for scheduled oil changes. Failure to do
so will result in engine or emission control
system damage not covered by the
Mercedes-Benz Limited Warranty.
!Do not blend oil additives with engine oil.
They may damage the engine.
Damage or malfunctions resulting from blending
oil additives are not covered by the
Mercedes-Benz Limited Warranty.
!Never use R-12 (CFC) or mineral-based
lubricating oil. Otherwise damage to the system
will occur.

539 Technical data
Fuels, coolants, lubricants, etc.
Brake fluid
Only brake fluid approved by
Mercedes-Benz is recommended. Your
authorized Mercedes-Benz Light Truck
Center will provide you with additional
information.Premium unleaded gasoline
(gasoline engine)
Warning!G
During vehicle operation, the boiling point of
the brake fluid is continuously reduced
through the absorption of moisture from the
atmosphere. Under extremely strenuous
operating conditions, this moisture content
can lead to the formation of bubbles in the
system, thus reducing the system’s
efficiency.
Therefore, the brake fluid must be
replaced regularly. Refer to your vehicle’s
Maintenance Booklet for replacement
interval.
Warning!G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious
personal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid in-
haling fumes and skin or clothing contact,
extinguish all smoking materials.
Direct skin contact with gasoline and the in-
halation of gasoline vapors are damaging to
your health.
!To maintain the engine’s durability and
performance, premium unleaded gasoline must
be used. If premium unleaded gasoline is not
available and low octane fuel is used, follow
these precautions:

Have the fuel tank only partially filled with
unleaded regular gasoline and fill up with
premium unleaded gasoline as soon as
possible.

Avoid full throttle driving and abrupt acceler-
ation.

Do not exceed an engine speed of 3 000 rpm
if the vehicle is loaded with a light load such
as two persons and no luggage.

Do not exceed2/3of maximum accelerator
pedal position if the vehicle is fully loaded or
operating in mountainous terrain.

540 Technical data
Fuels, coolants, lubricants, etc.
Fuel requirements
Gasoline engine
Only use premium unleaded fuel.

The octane number (posted at the
pump) must be 91 min. It is an
average of both the Research Octane
Number (RON) and the Motor Octane
Number (MON): (RON+MON) /2.
This is also known as the ANTI-KNOCK
INDEX.
Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not
exceed 10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional cosolvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains
10% ethanol and 90% unleaded gasoline,
can be used.These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.
Diesel engine
Only use commercially available vehicular
ULTRA-LOW SULFUR HIGHWAY DIESEL
FUEL (15 ppm SULFUR MAXIMUM).
To prevent malfunctions, diesel fuel with
improved cold flow characteristics is
offered in the winter months. Check with
your fuel retailer.
Gasoline additives (gasoline engine)
A major concern among engine
manufacturers is carbon build-up caused
by gasoline. Mercedes-Benz recommends
only the use of quality gasoline containing
additives that prevent the build-up of
carbon deposits.
After an extended period of using fuels
without such additives carbon deposits
can build up, especially on the intake
valves and in the combustion area, leading
to engine performance problems such as:

Warm-up hesitation

Unstable idle

Knocking/pinging

Misfire

Power loss
!Do not fill the tank with gasoline. Do not
blend diesel fuel with gasoline or kerosine.
The fuel system and engine will otherwise be
damaged, which is not covered by the
Mercedes-Benz Limited Warranty.

541 Technical data
Fuels, coolants, lubricants, etc.
In areas where carbon deposits may be
encountered due to lack of availability of
gasolines which contain these additives,
Mercedes-Benz recommends the use of
additives approved by us for use on
Mercedes-Benz vehicles. Refer to Factory
Approved Service Products pamphlet (USA
only) or contact an authorized
Mercedes-Benz Light Truck Center for a
listing of approved product(s). Follow
directions on product label.
Do not blend other specific fuel additives
with fuel. This only results in unnecessary
costs and may be harmful to the engine
operation.Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which
provides:

Corrosion protection

Freeze protection

Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -35°F (-37°C) and
corrosion protection.If the antifreeze mixture is effective to
-35°F (-37°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).
The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for
replacement interval.
!Damage or malfunction resulting from poor
fuel quality or from blending additional fuel
additives other than those tested and approved
by us for use on Mercedes-Benz vehicles are not
covered by the Mercedes-Benz Limited
Warranty.
! Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the Mercedes-Benz
Limited Warranty.

542 Technical data
Fuels, coolants, lubricants, etc.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification are used to
renew the coolant concentration or bring it
back up to the proper level.
For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Light Truck
Center.To provide important corrosion protection,
the solution must be at least
50% anticorrosion/antifreeze (equivalent
to freeze protection to approximately
-35°F [-37°C]). If you use a solution that is
more than 55% anticorrosion/antifreeze
(freeze protection to approximately
-49°F [-45°C]), the engine temperature
will increase due to the lower heat transfer
capability of the solution.
Therefore, do not use more than this
amount of anticorrosion/antifreeze.
If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage). Please make sure the
mixture is in accordance with label
instructions.The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality,
consult an authorized Mercedes-Benz
Light Truck Center.

543 Technical data
Fuels, coolants, lubricants, etc.
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be
specifically formulated to protect the aluminum parts. Failure to use such anti-
corrosion/antifreeze coolant will result in
a significantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Light Truck Center for service.
Anticorrosion/antifreeze quantity
Approximate freeze protection
Model-35°F (-37°C)-49°F (-45°C)
R 320 CDI 4MATIC5.0 US qt (4.75 l)5.5 US qt (5.2 l)
R 3501
1USA only.
5.0 US qt (4.75 l)5.5 US qt (5.2 l)
R 350 4MATIC5.0 US qt (4.75 l)5.5 US qt (5.2 l)
R 550 4MATIC2
2Canada only.
5.6 US qt (5.25 l)6.1 US qt (5.8 l)
