2007 MERCEDES-BENZ R350 Owner's Manual

256 Controls in detail
Power windows
Convenience closing feature
When locking the vehicle, you can close
the windows and the tilt/sliding sunroof*
(or tilt/sliding panel*) simultaneously.
Vehicles without tilt/sliding panel
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 255).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close
proximity to the driver’s door handle.
Press and hold button‹on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* are completely
closed.
Release button‹on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 69) until
the windows and the tilt/sliding
sunroof* are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.
Warning!G
When closing the windows and the
tilt/sliding sunroof* (or tilt/sliding panel*),
ma ke s ur e th at th er e is no dan ge r o f an y o ne
being harmed by the closing procedure.
If potential danger exists, proceed as
follows:

Release button‹to stop the closing
procedure. To open, press and hold
button Œ. To continue the closing
procedure after making sure that there
is no danger of anyone being harmed by
the closing procedure, press and hold
button ‹.
Vehicles with KEYLESS-GO*:

Release the lock button (page 69) on
the driver’s outside door handle to stop
the closing procedure.

Immediately pull on the same outside
door handle and hold firmly. The
windows and the tilt/sliding sunroof*
(or tilt/sliding panel*) will open for as
long as the door handle is held but the
door is not opened.

257 Controls in detail
Power windows
Vehicles with tilt/sliding panel*
If tilt/sliding panel is closed:
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 255).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close
proximity to the driver’s door handle.
Press and hold button‹on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the roller sunblinds are completely
closed.
Release button‹on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 69) until
the windows and the roller sunblinds
are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.
If tilt/sliding panel is open:
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 255).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close
proximity to the driver’s door handle.
Press and hold button‹on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding panel* are completely
closed.
Release button‹on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
With the windows and the tilt/sliding
panel completely closed, press and
hold button‹on the SmartKey or
SmartKey with KEYLESS-GO* once
more.
The roller sunblinds close.
Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 69) until
the windows and the tilt/sliding panel*
are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.
With the windows and the tilt/sliding
panel completely closed, press and
hold the lock button on an outside door
handle (
page 69) once more.
The roller sunblinds close.

258 Controls in detail
Power tilt/sliding sunroof*
Opening and closing
Warning!G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
If the tilt/sliding sunroof encounters an
obstruction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹on the
SmartKey, by pressing and holding the lock
button (vehicles with KEYLESS-GO*) on the
door handle, the automatic reversal function
will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately
halted by releasing the switch or, if the
switch was moved past the resistance point
and released, by moving the switch in any
direction.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts prop-
erly as entire body parts or portions of them
may protrude from the passenger compart-
ment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock your vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment can cause an accident
and/or serious personal injury.!To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding sunroof.
Do not open the tilt/sliding sunroof if there is
snow or ice on the roof, as this could result in
malfunctions.
The tilt/sliding sunroof can be opened or closed
manually should an electrical malfunction occur
(
page 481).
iWhen the tilt/sliding sunroof is open,
resonance noises may result in addition to the
usual wind noises. They are caused by minimal
pressure changes in the passenger compart-
ment. To reduce or eliminate theses noises,
change the position of the tilt/sliding sunroof or
open a door window slightly.
iYou can also open or close the tilt/sliding
sunroof using the SmartKey or the
KEYLESS-GO* function, see “Summer opening
feature” (
page 254) and “Convenience clos-
ing feature” (
page 256). Depending on the
current position, the tilt/sliding sunroofs may
also open or close when the air recirculation
button: on the control panel of the climate
control (
page 220) or automatic climate
control (
page 234) is pressed and held.

259 Controls in detail
Power tilt/sliding sunroof*
The tilt/sliding sunroof is opened and
closed electrically. The switch for the
tilt/sliding sunroof is located on the
overhead control panel.
Sunroof switch
1Push back to slide sunroof open
2Push forward to slide sunroof closed
3Push up to raise sunroof at rear
4Pull down to lower sunroof at rear
With the sunroof closed or tilted open, a
screen can be slid into the roof opening to
guard against sun rays. When sliding the
sunroof open, the screen will also retract.
Switch on the ignition (page 39).
Opening and closing
To open, close, raise, or lower the
tilt/sliding sunroof, move the sunroof
switch to the resistance point in the
required direction of arrows1to4
(
page 259).
Release the sunroof switch when the
tilt/sliding sunroof has reached the
desired position.Fully opening (Express-open) and
closing (Express-close)
To fully open or close the tilt/sliding
sunroof, move the sunroof switch past
the resistance point in the required
direction1or2 (
page 259) and
release.
The tilt/sliding sunroof opens or closes
completely.
Stopping the power tilt/sliding sunroof
during Express-open
Move the sunroof switch in any
direction.
The movement of the tilt/sliding
sunroof stops.
iIf the movement of the tilt/sliding sunroof is
blocked during the closing procedure, the
tilt/sliding sunroof will stop and reopen slightly.

260 Controls in detail
Power tilt/sliding sunroof*
Synchronizing
The tilt/sliding sunroof must be
synchronized

after the battery has been
disconnected or discharged

after the tilt/sliding sunroof has been
closed manually (
page 481)

after a malfunction

if the tilt/sliding sunroof does not open
smoothly
Remove the fuse for the tilt/sliding
sunroof from the fuse box
(
page 520).
Reinsert the fuse in the main box.
Switch on the ignition (page 39).
Press and hold the sunroof switch in
the direction of arrow3 (
page 259)
until the tilt/sliding sunroof is fully
raised at the rear.
Hold the sunroof switch in direction of
arrow3 for approximately 1 second.
Open the tilt/sliding sunroof using the
Express-open feature (
page 259).
If the tilt/sliding sunroof opens com-
pletely, it is synchronized.
If the tilt/sliding sunroof does not open
completely:
Repeat the above steps.
Warning!G
If the tilt/sliding sunroof encounters an
obstruction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹on the
SmartKey, by pressing and holding the lock
button (vehicles with KEYLESS-GO*) on the
door handle, the automatic reversal function
will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately
halted by releasing the switch or, if the
switch was moved past the resistance point
and released, by moving the switch in any
direction.
iFor information on which fuse box contains
the fuse for the power tilt/sliding sunroof, see
the fuse chart provided with the vehicle tool kit
(
page 473).

261 Controls in detail
Panorama roof with power tilt/sliding panel*
Panorama roof with power tilt/sliding panel*
Roller sunblinds for the panorama roof
with power tilt/sliding panel
The tilt/sliding panel and the front and
rear roller sunblinds are opened and
closed electrically. The switch for the
tilt/sliding panel and the roller sunblinds is
located on the overhead control panel.
The roller sunblinds only operate with the
tilt/sliding panel closed. The front and rear
roller sunblind cannot be operated individ-
ually.
Roof panel switch
1Open roller sunblinds
2Close roller sunblinds
Switch on the ignition (page 39).
To open or close the roller sunblinds,
move the roof panel switch to the resis-
tance point in the required direction of
arrow1 or2.
Release the roof panel switch when
the roller sunblinds have reached the
desired position.Fully opening the roller sunblinds
(Express-open)
Move the roof panel switch past the re-
sistance point in direction of arrow1
and release.
The roller sunblinds opens completely.
Stopping the roller sunblinds during
Express-operation
Move the roof panel switch in any
direction.Warning!G
When closing the roller sunblinds, make
sure that no one is in danger of being injured
by the closing procedure. The closing of the
roller sunblinds can be immediately halted
by releasing the switch.

262 Controls in detail
Panorama roof with power tilt/sliding panel*
Opening and closing the panorama roof
with power tilt/sliding panel
Switch on the ignition (page 39).
The tilt/sliding panel is opened and closed
electrically. The switch for the tilt/sliding
panel is on the overhead control panel.
The tilt/sliding panel only operates with
the roller sunblinds opened.
Warning!G
When opening or closing the tilt/sliding
panel, make sure that there is no danger of
anyone being harmed by the opening or
closing procedure.
The opening procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch or, if the switch was moved
past the resistance point and released, by
moving the switch in any direction.
The closing procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch.
The panorama roof with power tilt/sliding
panel is made out of glass. In the event of
an accident, the glass may shatter. This may
result in an opening in the roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts
properly as entire body parts or portions of
them may protrude from the passenger
compartment.
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle.
Unsupervised use of vehicle equipment can
cause an accident and/or serious personal
injury.
!To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding panel.
Do not open the tilt/sliding panel if there is
snow or ice on the roof, as this could result in
malfunctions.
iWhen the tilt/sliding panel is open,
resonance noises may result in addition to the
usual wind noises. They are caused by minimal
pressure changes in the passenger compart-
ment. To reduce or eliminate theses noises,
change the position of the tilt/sliding panel or
open a door window slightly.
iYou can also open or close the tilt/sliding
panel using the SmartKey or the KEYLESS-GO*
function, see “Summer opening feature”
(
page 254) and “Convenience closing
feature” (
page 256).
iThe tilt/sliding panel may also open when
using the air recirculation button:on the
control panel of the climate control
(
page 220) or automatic climate control
(
page 234).

263 Controls in detail
Panorama roof with power tilt/sliding panel*
Roof panel switch
1Push back to slide roof panel open
2Push forward to slide roof panel closed
3Push up to raise roof panel
4Pull down to lower roof panel
Opening
Pull and hold the roof panel switch to
resistance point in direction of
arrow1 (
page 263).
Release the roof panel switch when the
tilt/sliding panel has reached the
desired position.Closing
Press and hold the roof panel switch in
direction of arrow2 (
page 263).
Release the roof panel switch when the
tilt/sliding panel has reached the
desired position.
Raising
You can raise the tilt/sliding panel at the
rear for better ventilation of the vehicle
interior.
Press and hold the roof panel switch in
direction of arrow3 (
page 263).
Release the roof panel switch when the
tilt/sliding panel has reached the
desired position.
Lowering
Pull and hold the roof panel switch in
direction of arrow4 (
page 263)
until the tilt/sliding panel has lowered
and closed completely.Fully opening (Express-open) the
panorama roof with tilt/sliding panel
Pull the roof panel switch past the
resistance point in direction of
arrow1 (
page 263) and release.
The tilt/sliding panel opens com-
pletely.
Stopping the panorama roof with
tilt/sliding panel during Express-open
Move the roof panel switch in any
direction.
The tilt/sliding panel will stop in its
current position.
