2007 MERCEDES-BENZ R350 Owner's Manual

264 Controls in detail
Panorama roof with power tilt/sliding panel*
Synchronizing the panorama roof with
power tilt/sliding panel
The tilt/sliding panel and its roller
sunblinds must be synchronized

after the battery has been
disconnected or discharged

after a malfunction

if the tilt/sliding panel does not open
smoothly
Switch off the ignition (page 40) and
remove the SmartKey from the starter
switch.
Vehicles with KEYLESS-GO*:
Switch off the ignition (page 41).
Open the driver’s door (this puts
the starter switch in position 0,
same as with the SmartKey re-
moved from the starter switch). The
driver’s door then can be closed
again.
Remove the fuse for the tilt/sliding
panel from the fuse box (
page 521).
Reinsert the fuse in the fuse box.
Switch on the ignition (page 39).
Push and hold the roof panel switch in
direction of arrow2 (
page 263)
until the roller sunblinds are fully
closed.
Keep holding the roof panel switch in
direction of arrow2 (
page 263) for
approximately 1 second.
Pull and hold the roof panel switch in
direction of arrow1 (
page 263)
until the roller sunblinds are fully
opened.
Keep holding the roof panel switch in
direction of arrow1 (
page 263) for
approximately 1 second.
!Do not attempt to open or close the
tilt/sliding panel before the tilt/sliding panel is
properly synchronized. The tilt/sliding panel
could otherwise lock-up in the open position.
If the tilt/sliding panel cannot be closed or
synchronized, see an authorized Mercedes-Benz
Light Truck Center or call Roadside Assistance
(
page 333).
iFor information on which fuse box contains
the fuse for the power tilt/sliding panel, see the
fuse chart provided with the vehicle tool kit
(
page 473).

265 Controls in detail
Panorama roof with power tilt/sliding panel*
Press and hold the roof panel switch in
direction of arrow3 (
page 263)
until the tilt/sliding panel is fully raised
at the rear.
Push and hold the roof panel switch in
direction of arrow2 (
page 263)
until the tilt/sliding panel is fully
closed.
Keep holding the roof panel switch in
direction of arrow2 (
page 263) for
approximately 1 second.
Open the tilt/sliding panel using the
Express-open feature (
page 263).
If the tilt/sliding panel opens
completely, the roof is synchronized.
If the tilt/sliding sunroof does not open
completely:
Repeat the above steps.

266 Controls in detail
Driving systems
The driving systems of your vehicle are
described on the following pages:

Cruise control (page 266) and
Distronic* (
page 271), with which
the vehicle can maintain a preset
speed.

Distance warning function*
(
page 284) is only available with
Distronic*, which warns of stationary
obstacles or slower moving vehicles
that you are closing in on too quickly.

AIRMATIC* (page 285) adjusts the
vehicle suspension characteristics
automatically and controls the vehicle
level.

Parktronic* (page 291) and rear view
camera* (
page 295), which serve as
a parking aid.
For information on the ABS, BAS, EBP,
ESP
®, and 4-ETS, see “Driving safety sys-
tems” (
page 100).
Cruise control
The cruise control automatically maintains
the speed you set for your vehicle.
The use of cruise control is recommended
for driving at a constant speed for extend-
ed periods of time. You can set or resume
cruise control at any speed above
20 mph (30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 24).
Warning!G
The cruise control is a convenience system
designed to assist the driver during vehicle
operation. The driver is and must always
remain responsible for the vehicle’s speed
and for safe brake operation.
Only use the cruise control if the road, traffic
and weather conditions make it advisable to
travel at a constant speed.

The use of the cruise control can be
dangerous on winding roads or in heavy
traffic because conditions do not allow
safe driving at a constant speed.

The use of the cruise control can be
dangerous on slippery roads. Rapid
changes in tire traction can result in
wheel spin and loss of control.

Deactivate the cruise control when
driving in fog.
The “Resume” function should only be
operated if the driver is fully aware of the
previously set speed and wishes to resume
this particular preset speed.

267 Controls in detail
Driving systems
1Setting current or higher speed
Adjustment in 1 mph increments (to
the resistance point) or 5 mph
increments (past the resistance point)
(Canada: 1 km/h or 10 km/h)
2Setting current or lower speed
Adjustment in 1 mph increments (to
the resistance point) or 5 mph
increments (past the resistance point)
(Canada: 1 km/h or 10 km/h)
3Canceling cruise control
4Resuming to last set speedActivating cruise control
You can activate the cruise control when
the vehicle speed is above
20 mph (30 km/h).
In the following cases you cannot activate
the cruise control:

when you brake

when you have set the parking brake

when the automatic transmission is set
to positionP, R, or N

if the ESP® is switched off

if the ESP® has switched off due to a
malfunction
Warning!G
The cruise control brakes automatically so
that the set speed is not exceeded. The
brake pedal depresses automatically when
the cruise control engages the brakes.
Keep driver’s foot area clear at all times,
including the area under the brake pedal.
Objects stored in this area may impair pedal
movement which could interfere with the
braking ability of the cruise control system.
Do not place your foot under the brake pedal
– your foot could become caught.
Keep in mind that the cruise control is a
convenience system designed to assist the
driver during vehicle operation. The driver is
and must always remain responsible for
the vehicle’s speed and for safe brake
operation.
iThe vehicle speed displayed in the speedo-
meter can briefly vary from the speed setting for
the cruise control system.

268 Controls in detail
Driving systems
Setting current speed
Accelerate or decelerate to the desired
speed.
Briefly lift the cruise control lever in
direction of arrow1 or depress in
direction of arrow2 (
page 267).
The current speed is set.
Remove your foot from the accelerator
pedal.
The cruise control is activated.
The currently set speed appears in the
multifunction display for approximately
5 seconds.Canceling cruise control
There are several ways to cancel the cruise
control:
Step on the brake pedal.
The cruise control is canceled. The last
set speed is stored for later use.
or
Briefly push the cruise control lever in
direction of arrow3 (
page 267).
The cruise control is canceled. The last
set speed is stored for later use.
iOn uphill grades, the cruise control may not
be able to maintain the set speed. Once the
grade eases, the set speed will be resumed.
On downhill grades, the cruise control maintains
the set speed by braking with the vehicle’s
braking system. In addition, on longer downhill
grades the automatic transmission will down-
shift automatically.
iThe last stored speed is canceled when you
turn off the engine.
iThe cruise control switches off
automatically when

you step on the brake pedal

you depress the parking brake pedal
The cruise control switches off automatically and
an acoustic warning will sound when

the vehicle speed is below 20 mph
(30 km/h)

the ESP® is in operation

the ESP® is switched off with the ESP®
switch (
page 104)

the ESP® has switched off due to a
malfunction (
page 441)

you set the automatic transmission toN
while driving
Observe additional messages in the
multifunction display that may appear.

269 Controls in detail
Driving systems
Setting a higher speed
You can increase the set speed in two
ways.
Adjustment in 1 mph (Canada: 1 km/h)
increments
Briefly lift the cruise control lever up to
the resistance point in direction of
arrow1 (
page 267).
Release the cruise control lever.
The vehicle set speed increases in in-
crements of 1 mph (Canada: 1 km/h).Adjustment in 5 mph
(Canada: 10 km/h) increments
!Setting the automatic transmission toN
while driving cancels the cruise control.
However, the automatic transmission should not
be set toN while driving except to coast when
the vehicle is in danger of skidding (e.g. on icy
roads).
iDepressing the accelerator pedal does not
deactivate the cruise control. After brief acceler-
ation (e.g. for passing), the cruise control will re-
sume the last speed set.
iThe set speed value is increased in 1 mph
(Canada: 1 km/h) increments each time you lift
the cruise control lever to the resistance point.
Warning!G
You can increase the vehicle speed in
5 mph (Canada 10 km/h) increments.
When using this feature, keep in mind that it
may take a brief moment until the vehicle
has reached the set speed.
Increase the vehicle set speed to a value
that the prevailing road conditions permit.
Otherwise, sudden and unexpected acceler-
ation of the vehicle could cause an accident
and/or serious injury to you and others.
iThe set speed value is increased in
5 mph (Canada: 10 km/h) increments each time
you lift the cruise control lever past the
resistance point.

270 Controls in detail
Driving systems
Briefly lift the cruise control lever up
past the resistance point in direction of
arrow1 (
page 267).
Release the cruise control lever.
The vehicle set speed increases in
increments of 5 mph
(Canada: 10 km/h).
Setting a lower speed
You can reduce the set speed in two ways.Adjustment in 1 mph (Canada: 1 km/h)
increments
Briefly press the cruise control lever
down to the resistance point in direc-
tion of arrow2 (
page 267).
Release the cruise control lever.
The vehicle set speed decreases in in-
crements of 1 mph (Canada: 1 km/h).Adjustment in 5 mph
(Canada: 10 km/h) increments
iThe new speed is set and the vehicle will
accelerate. Keep in mind that it may take a brief
moment until the vehicle has reached the set
speed.
iWhen you use the cruise control lever to
decelerate, the brake system will automatically
brake the vehicle if the engine’s braking power
does not brake the vehicle sufficiently.
iThe set speed value is decreased in 1 mph
(Canada: 1 km/h) increments each time you
press the cruise control lever down to the resis-
tance point.
Warning!G
You can decrease the vehicle set speed in
5 mph (Canada 10 km/h) increments. When
using this feature, keep in mind that it may
take a brief moment until the vehicle has
reached the set speed.
Decelerate the vehicle set speed to a value
that the prevailing road conditions permit.
Otherwise, sudden and unexpected deceler-
ation of the vehicle could cause an accident
and/or serious injury to you and others.
iThe set speed value is decreased in 5 mph
(Canada: 10 km/h) increments each time you
press the cruise control lever down past the
resistance point.

271 Controls in detail
Driving systems
Briefly press the cruise control lever
down past the resistance point in
direction of arrow2.
Release the cruise control lever.
The vehicle set speed decreases in
increments of 5 mph
(Canada: 10 km/h).Setting to last stored speed
(“Resume” function)
Briefly pull the cruise control lever in
direction of arrow4 (
page 267).
The cruise control resumes to the last
set speed or, if no speed is stored, it
will set and store the current speed.
Remove your foot from the accelerator
pedal.
The last set speed appears in the multi-
function display for approximately
5 seconds.
Distronic*
When activated, the Distronic adaptive
cruise control system increases the driving
convenience afforded by the cruise control
while traveling on expressways and other
major roadways.

If the Distronic distance sensor detects
a slower moving vehicle directly ahead,
your vehicle speed will be reduced so
that you follow that vehicle at your
preset following distance.

If there is no vehicle directly ahead of
you, Distronic will function in the same
way as standard cruise control
(
page 266).
iThe new speed is set and the vehicle will
decelerate. Keep in mind that it may take a brief
moment until the vehicle has reached the set
speed.
Warning!G
The set speed stored in memory should only
be set again if prevailing road conditions
permit. Possible acceleration or decelera-
tion differences arising from returning to the
preset speed could cause an accident
and/or serious injury to you and others.
