2007 MERCEDES-BENZ R350 Owner's Manual

248 Controls in detail
3-zone automatic climate control*
Setting the temperature
Use temperature controla (
page 245)
to separately adjust the air temperature of
the rear passenger compartment.
You should raise or lower the temperature
setting in small increments, preferably
starting at 72°F (22°C). The automatic
climate control will adjust to the set
temperature as fast as possible.Increasing the temperatureTurn temperature controla
(
page 245) slightly clockwise.
The rear automatic climate control will
correspondingly adjust the interior air
temperature for the rear passenger
compartment.
Decreasing the temperature
Turn temperature controla
(
page 245) slightly counterclock-
wise.
The rear automatic climate control will
correspondingly adjust the interior air
temperature for the rear passenger
compartment.Adjusting air volume
Adjusting manually
Five blower speeds are available.
Press button
to decrease or
buttonQ to increase air volume to
the desired level.
The indicator lamp on buttonU
goes out. The selected blower speed is
shown by the indicator lamps for air
volume settings 9 (
page 245).
Adjusting automatically
Press buttonU.
The indicator lamp on the button
comes on. The air volume is adjusted
automatically.
iThe rear automatic climate control will not
cool the air when the air conditioning is switched
off (
page 243).

249 Controls in detail
3-zone automatic climate control*
B-pillar air vents
Air vents are located in both B-pillars.
1Air vent, adjustable
2Thumbwheel for air volume control
Adjusting air volume
Turn thumbwheel 2 to the left to
increase the air volume.
or
Turn thumbwheel 2 to the right to
decrease the air volume.Adjusting air distribution
Move air vent slider 1 to the left, right,
up, or down to direct the air in the de-
sired direction.
Rear automatic climate control
(second and third row)*
The rear automatic climate control for the
second and third row* is operated in the
same manner as the rear automatic
climate control for the second row
(
page 245).Air vents are located in the left and right
side trim below the rear quarter windows.
1Defrost air vent for rear quarter
window, fixed
2Air vent, adjustable
3Thumbwheel for air volume control

250 Controls in detail
3-zone automatic climate control*
Adjusting air volume
Turn thumbwheel 3 downwards to
increase the air volume.
or
Turn thumbwheel 3 upwards to
decrease the air volume.
Adjusting air distribution
Move air vent slider 2 to the left, right,
up, or down.
The air is directed in the desired
direction.

251 Controls in detail
Power windows
Power windows
Opening and closing
The door windows and the hinged quarter
windows* are opened and closed electri-
cally. The switches for all door windows
and the hinged quarter windows* are
located on the driver’s door control panel
(
page 36). The switches for the respec-
tive door windows are located on the
control panels of the front passenger door
and the rear doors. The hinged quarter
windows* can be operated from the
driver’s seat only.1Left front door window
2Right front door window
3Right rear door window
4Hinged quarter windows*
5Override switch (
page 97)
6Left rear door window
Switch on the ignition (page 39).
Warning!G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
Activate the override switch (
page 97)
when children are riding in the back seats of
the vehicle. The children could otherwise in-
jure themselves, e.g. by becoming trapped
in the window opening.
The closing of a door window can be imme-
diately halted by releasing the switch or, if
switch was pulled past the resistance point
and released, by either pressing or pulling
the respective switch.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you pulled the switch past the resistance
point and released it to close the door win-
dow, the automatic reversal function will
stop the door window and open it slightly.


252 Controls in detail
Power windows
Opening the door windows
Press switch1, 2, 3, or6
(
page 251) to the resistance point.
The corresponding door window moves
downwards until you release the
switch.
Closing the door windows
Pull switch1, 2, 3, or6
(
page 251) to the resistance point.
The corresponding door window moves
upwards until you release the switch.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you are closing a door window by pulling and
holding the switch, or by pressing and hold-
ing button‹on the SmartKey, by press-
ing and holding the lock button (vehicles
with KEYLESS-GO*) on the door handle, the
automatic reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from starter switch, take it with you, and
lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment can cause an accident
and/or serious personal injury.iYou can also open or close the windows us-
ing the SmartKey, see “Summer opening fea-
ture” (
page 254) and “Convenience closing
feature” (
page 256).
Depending on the current position, the power
windows may also open or close when the air
recirculation button:on the control panel of
the climate control (
page 220) or automatic
climate control (
page 234) is pressed and
held.
iWith the SmartKey in starter switch
position0 or removed from the starter switch,
the windows can be operated

until you open the driver’s or front passenger
door

for at least 5 minutesWarning!G
If you pull and hold the switch up when clos-
ing the door window, and upward movement
of the door window is blocked by some
obstruction including but not limited to
arms, hands, fingers, etc., the automatic
reversal will not operate.


253 Controls in detail
Power windows
Fully opening the door windows
(Express-open)
Press switch1, 2, 3, or6
(
page 251) past the resistance point
and release.
The corresponding door window opens
completely.
Fully closing the door windows
(Express-close)
Pull switch1, 2, 3, or6
(
page 251) past the resistance point
and release.
The corresponding door window closes
completely.If the upward movement of a door window
is blocked during the closing procedure,
the door window will stop and open
slightly.
Remove the obstruction.
Pull the respective power window
switch past the resistance point again
and release.
Stopping door windows during
Express-operation
Press or pull the respective door
window switch again.Hinged quarter windows*
The switches for opening and closing the
hinged quarter windows are located on the
door control panel of the driver’s door
(
page 36).
1Hinged quarter windows: opening
2Hinged quarter windows: closing
Warning!G
Driver’s door only:
If within 5 seconds switch is again pulled
past the resistance point and released, the
automatic reversal will not function.
iIf the door window still does not close when
there is no obstruction, pull and hold the respec-
tive power window switch. The door window will
then close without the obstruction sensor
function.

254 Controls in detail
Power windows
Opening
Press and release switch 1.
To stop the hinged quarter window:
Press and release switch 1 once
more.
Closing
Press and release switch 2.
To stop the hinged quarter window:
Press and release switch 2 once
more.
Synchronizing the door windows
The door windows must be synchronized

after the battery was disconnected

if the door windows cannot be fully
opened (Express-open) or closed
(Express-close)
Close all doors.
Switch on the ignition (page 39).
Pull and hold door window switch1,
2, 3, or6 (
page 251).
Once a door window is closed
completely, hold the respective switch
for approximately 3 seconds.
The door window is synchronized.
Summer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously

opening the door windows

opening the hinged quarter windows*

opening the tilt/sliding sunroof*
(or tilt/sliding panel*)

switching on the seat ventilation* for
the driver’s seat
iWhen the obstruction sensor detects the
hinged quarter window is blocked during the
closing process, it will stop and open slightly.
iEach door window must be synchronized
separately.

255 Controls in detail
Power windows
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle.
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.
Vehicles without tilt/sliding panel
Press and hold buttonŒon the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* have reached
the desired position.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.Vehicles with tilt/sliding panel*
If roller sunblinds are closed:
Press and hold buttonŒon the
SmartKey or SmartKey with
KEYLESS-GO*.
The windows and roller sunblinds begin
to open after approximately 1 second.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.
With the windows and roller sunblinds
fully opened, press and hold
buttonŒon the SmartKey or
SmartKey with KEYLESS-GO* once
more.
The tilt/sliding panel opens.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.If roller sunblinds are open:
Press and hold buttonŒon the
SmartKey or SmartKey with
KEYLESS-GO*.
The windows and the tilt/sliding panel
begin to open after approximately
1 second.
Release buttonŒon the SmartKey
or SmartKey with KEYLESS-GO* to in-
terrupt the opening procedure.
