2007 MERCEDES-BENZ R350 Owner's Manual

328 Controls in detail
Useful features
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones. Please contact an
authorized Mercedes-Benz Light Truck
Center for information on features avail-
able for your mobile phone of choice.
The cradle is located in the front center
armrest.
Open telephone compartment
(
page 313).
Inserting mobile phone in mobile phone
cradle
Once the mobile phone has been inserted
in the mobile phone cradle, you have to
use the hands-free device to respond
during phone calls.
If applicable, remove the cover for the
external antenna connection from the
back of the mobile phone and store it in
a s a f e p l a c e . B e s u r e t o c o m p l y w i t h t h e
mobile phone’s operating instructions
as well.
Example illustration
1Inserting the mobile phone
2Connector contact
3Mobile phone cradle
Slide the lower end of the mobile phone
into connector contact 2 on
cradle3.
Push the top of the mobile phone in
direction of arrow 1, until the lug on
the mobile phone release button
engages.
The mobile phone is connected to the
network via the external antenna.
The mobile phone is linked to the
hands-free device and the multifunc-
tion steering wheel.
The battery is charged depending on its
charge status and the position of the
SmartKey in the starter switch. The
charge procedure will be indicated in
the mobile phone’s display.
You can place or receive phone calls. You
can control other functions of the mobile
phone via the control system (
page 193)
or COMAND system, see separate operat-
ing instructions.
!Do not try to remove the mobile phone along
with the cradle. You could otherwise damage the
mobile phone cradle.
iWhen you take the SmartKey or SmartKey
with KEYLESS-GO* out of the starter switch, the
mobile phone remains switched on for approx.
10 minutes. If you place or receive a call during
this time, the mobile phone switches off 10 min-
utes after the call has been completed.

329 Controls in detail
Useful features
Removing mobile phone from mobile
phone cradle
Example illustration
1Release catch for mobile phone
2Mobile phone cradle
Press release catch in direction of
arrow1 and take mobile phone out of
mobile phone cradle2.Changing mobile phone cradle
If you require a different cradle for your
mobile phone, remove the present cradle
before installing a new one.
Removing an existing mobile phone
cradle
Example illustration
1To release the mobile phone cradle
2To remove the mobile phone cradle
3Mobile phone cradle
Press release button in direction of
arrow1 and take mobile phone
cradle3 out in direction of arrow2.
Installing a different mobile phone
cradle
Example illustration
1Contact plate
2Recesses
3Mobile phone cradle
Insert mobile phone cradle3 into
recesses2 of contact plate1.
Push mobile phone cradle3 forward
until it engages.
iWhen using a flip-style mobile phone, open
flip top before removing from the cradle while
a call is connected. Otherwise, the call will be
disconnected.

330 Controls in detail
Useful features
Tele Aid*
Shortly after the completion of your Tele
Aid acquaintance call, you will receive a
user ID and password. By visiting
www.mbusa.com and selecting “Tele Aid”
(USA only), you will have access to account
information, remote door unlock and
more.The Tele Aid system
(Tele
matic Alarm Identification on
D
emand)
The Tele Aid system consists of three
types of response:

automatic and manual emergency

roadside assistance

information
The Tele Aid system is operational provid-
ing that the vehicle’s battery is charged,
properly connected, not damaged and cel-
lular and GPS coverage are available.
The speaker volume of a Tele Aid call can
be adjusted by using the volume control on
the COMAND system headunit or on the
multifunction steering wheel. To raise, turn
the rotary volume control on the COMAND
system headunit clockwise or press
buttonæ on the multifunction steering
wheel. To lower, turn the rotary volume
control on the COMAND system headunit
counterclockwise or press buttonç on
the multifunction steering wheel.
To activate, press the SOS button, the
Roadside Assistance button• or
the Information button¡, depend-
ing on the type of response required.
!The initial activation of the Tele Aid system
may only be performed by completing the sub-
scriber agreement and placing an acquaintance
call using the ¡button. Failure to complete
either of these steps will result in a system that
is not activated.
If you have any questions regarding activation,
please call the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada).
iThe SOS button is located in the overhead
control panel (
page 332).
The Roadside Assistance button•
(
page 333) and the Information
button¡(
page 334) are located below
the center armrest cover.
!The Tele Aid system utilizes the cellular
network for communication and the GPS (G
lobal
P
ositioning System) satellites for vehicle
location. If either of these signals are unavail-
able, the Tele Aid system may not function and if
this occurs, assistance must be summoned by
other means.

331 Controls in detail
Useful features
System self-check
Initially, after switching on the ignition,
malfunctions are detected and indicated
(the indicator lamps in the SOS button, the
Roadside Assistance button• and the
Information button¡ stay on longer
than 10 seconds or do not come on). The
message
Tele Aid inoperative appears
in the multifunction display.Emergency calls
An emergency call is initiated auto-
matically following an accident in which
the emergency tensioning devices (ETDs)
or air bags deploy.
An emergency call can also be initiated
manually by opening the cover next to the
interior rear view mirror labeled SOS, then
briefly pressing the button located under
the cover. See (
page 332) for
instructions on initiating an emergency call
manually.
Once the emergency call is in progress, the
indicator lamp on the SOS button will
begin to flash. The message
Connecting call appears in the multifunc-
tion display. When the connection is estab-
lished, the message
Call connected
appears in the multifunction display.
All information relevant to the emergency,
such as the location of the vehicle (deter-
mined by the GPS satellite location sys-
tem), vehicle model, identification number
and color are generated.
iWhen a Tele Aid call has been initiated,
the COMAND system audio is muted and the
selected mode (radio, CD etc.) pauses.
The optional cellular phone (if installed) inserted
in cradle switches off. If you must use this
phone, we recommend that you use it only with
the vehicle at a standstill in a safe location.
Remove the phone from the cradle and place the
call. The navigation* system (if engaged) will
continue to run. The display in the instrument
cluster is available for use, and spoken com-
mands are only available by pressing the
RPT button on the COMAND system. A pop-up
window will appear in the COMAND system dis-
play to indicate that a Tele Aid call is in progress.
After the Tele Aid call has ended, the optional
cellular phone inserted in the cradle switches on
again. A PIN entry might be necessary.
Warning!G
If the indicator lamps on the SOS button, on
the Roadside Assistance button, and/or on
the Information button remain illuminated
continuously in red and/or the message
Tele Aid inoperative is displayed in the
multifunction display after the system
self-check, a malfunction in the system has
been detected.
If a malfunction is indicated as outlined
above, the system may not operate as
expected. Have the system checked at the
nearest Mercedes-Benz Light Truck Center
as soon as possible.

332 Controls in detail
Useful features
A voice connection between the Response
Center and the occupants of the vehicle
will be established automatically soon
after the emergency call has been initiat-
ed. The Response Center will attempt to
determine more precisely the nature of the
accident provided they can speak to an
occupant of the vehicle.
The Tele Aid system is available if

it has been activated and is operation-
al. Activation requires a subscription
for monitoring services, connection
and cellular air time

vehicle battery power is available

the relevant cellular phone network
and GPS signals are available and pass
the information on to the Response
CenterInitiating an emergency call manually
1Cover
2SOS button
Briefly press on cover1.
The cover opens.
Press SOS button2 briefly.
The indicator lamp in SOS button2
will flash until the emergency call is
concluded.
Wait for a voice connection to the
Response Center.
Close cover1 after the emergency
call is concluded.
iLocation of the vehicle on a map is only
possible if the vehicle is able to receive signals
from the GPS satellite network and pass the
information on to the Response Center.
Warning!G
If the indicator lamp in the SOS button is
flashing continuously and there was no
voice connection to the Response Center
established, then the Tele Aid system could
not initiate an emergency call (e.g. the rele-
vant cellular phone network is not available).
The message
Call failed appears in the
multifunction display for approximately
10 seconds.
Should this occur, assistance must be
summoned by other means.

333 Controls in detail
Useful features
Roadside Assistance button•
The Roadside Assistance button• is
located below the center armrest cover.
1Roadside Assistance button•
Open the storage tray (page 313).
Press and hold button1 (for longer
than 2 seconds).
A call to a Mercedes-Benz Roadside
Assistance dispatcher will be initiated.
The button will flash while the call is in
progress. The message
Connecting call will appear in the
multifunction display.When the connection is established, the
message
Call connected appears in the
multifunction display. The Tele Aid system
will transmit data generating the vehicle
identification number, model, color and
location (subject to availability of cellular
and GPS signals).
A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established.
Describe the nature of the need for
assistance.
Warning!G
If you feel at any way in jeopardy when in the
vehicle (e.g. smoke or fire in the vehicle,
vehicle in a dangerous road location), please
do not wait for voice contact after you have
pressed the emergency button. Carefully
leave the vehicle and move to a safe loca-
tion. The Response Center will automatically
contact local emergency officials with the
vehicle’s approximate location if they
receive an automatic SOS signal and cannot
make voice contact with the vehicle
occupants.
iWhile the call is connected you can change
to the navigation menu by pressing the NAV
button on the COMAND system headunit.

334 Controls in detail
Useful features
The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest
Mercedes-Benz Light Truck Center. For
services such as labor and/or towing,
charges may apply. Refer to the Roadside
Assistance Manual for more information.
The following is only available in the USA:

Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.Information button¡
The Information button¡ is located
below the center armrest cover.
1Information button¡
Open the storage tray (page 313).
Press and hold button1 (for longer
than 2 seconds).
A call to the Customer Assistance
Center will be initiated. The button will
flash while the call is in progress. The
message
Connecting call will appear
in the multifunction display.
iThe indicator lamp on the Roadside
Assistance button• remains illuminated in
red for approximately 10 seconds during the
system self-check after switching on the ignition
(together with the SOS button and the
Information button¡).
See system self-check (
page 331) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp on the Roadside Assistance
button• is flashing continuously and there
was no voice connection to the Response Center
established, then the Tele Aid system could not
initiate a Roadside Assistance call (e.g. the rele-
vant cellular phone network was not available).
The message
Call failed appears in the mul-
tifunction display.
Roadside Assistance calls can be terminated
using thet button on the multifunction
steering wheel or the END button on the
COMAND system headunit.

335 Controls in detail
Useful features
When the connection is established, the
message
Call connected appears in the
multifunction display. The Tele Aid system
will transmit data generating the vehicle
identification number, model, color and
location (subject to availability of cellular
and GPS signals).
A voice connection between the Customer
Assistance Center representative and the
occupants of the vehicle will be estab-
lished. Information regarding the operation
of your vehicle, the nearest
Mercedes-Benz Light Truck Center or
Mercedes-Benz USA products and services
is available to you.
For more details concerning the Tele Aid
system, please visit www.mbusa.com and
use your ID and password (sent to you sep-
arately) to learn more (USA only).
iWhile the call is connected, you can change
to the navigation menu by pressing the NAV
button on the COMAND system headunit.
iThe indicator lamp in the Information
button¡ remains illuminated in red for
approximately 10 seconds during the system
self-check after switching on the ignition
(together with the SOS button and the Roadside
Assistance button•).
See system self-check (
page 331) if the
indicator lamp does not come on in red or stays
on longer than approximately 10 seconds.
If the indicator lamp in the Information
button¡ is flashing continuously and there
was no voice connection to the Response Center
established, then the Tele Aid system could not
initiate an Information call (e.g. the relevant
cellular phone network is not available).
The message
Call failed appears in the
multifunction display.
Information calls can be terminated using
thet button on the multifunction steering
wheel or the END button on the COMAND
system headunit.
!If the indicator lamps do not start flashing
after pressing one of the buttons or remain
illuminated (in red) at any time, the Tele Aid
system has detected a malfunction or the
service is not currently active, and may not
initiate a call. Visit your authorized
Mercedes-Benz Light Truck Center and have the
system checked or contact the Response Center
at 1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada) as soon as
possible.
