2007 MERCEDES-BENZ R350 Owner's Manual

544 Technical data
Fuels, coolants, lubricants, etc.
If the coolant level is low, water and
MB 325.0 anticorrosion/antifreeze should
be used to bring it up to the proper level
(have cooling system checked for signs of
leakage). Please make sure the mixture is
in accordance with label instructions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Light
Truck Center.

545 Technical data
Fuels, coolants, lubricants, etc.
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines ne-
cessitates that anticorrosion/antifreeze
coolant used in such engines be
specifically formulated to protect the aluminum parts. (Failure to use such anti-
corrosion/antifreeze coolant will result in
a significantly shortened service life.)
Therefore, the following product is strongly
recommended for use in your vehicle:
Mercedes-Benz 325.0 anticorrosion/anti-
freeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Light Truck Center for service.
Anticorrosion/antifreeze quantity
Approx. freeze protection
Model–35°F (–37°C)–49°F (–45°C)
R 320 CDI5.0 US qt (4.75 l)5.5 US qt (5.2 l)
R3505.0 US qt (4.75 l)5.5 US qt (5.2 l)
R5005.6 US qt (5.25 l)6.1 US qt (5.8 l)
R63 AMG6.1US qt (5.75l)6.8 US qt (6.4 l)

546 Technical data
Fuels, coolants, lubricants, etc.
Windshield washer and headlamp
cleaning* system
Both the windshield washer and headlamp
cleaning* system are supplied from the
windshield washer fluid reservoir.
The windshield and headlamp washer fluid
reservoir has a capacity of approx.
8.0 US qt (7.6 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer
solvent/antifreeze, depending on am-
bient temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:

1part “MBSummerFit” to 100parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1gal [4.0l] water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer
solvent/antifreeze:

1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent)
Warning!G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

547 Index
A
ABS 100
Indicator lamp 420
Messages in the multifunction
display 435
Accelerator position, automatic
transmission 203
Accessory weight 401
Accident 64
Active head restraint 83, 137, 482
Air bags 74
Children 75, 86
Front, Driver 77
Front, Passenger 77
Messages in the multifunction
display 445–448
Occupant Classification System
(OCS) 88
Safety guidelines 76
Side impact 78
Window curtain 78
Air conditioning, Cooling 228, 243
Air conditioning refrigerant 540Air conditioning system see
Climate control or
Automatic climate control (3-zone)*
Air distribution 223, 238
Air pressure see Tire inflation pressure
Air pressure, Tires 401
Air pump, Electric 502
Air recirculation mode 226, 240
Air vents, Front 218, 224, 232, 238
Air vents, Rear 230, 245, 249
Air volume 224, 239
AIRMATIC* 285
Messages in the multifunction
display 470
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 472, 500
Anticorrosion/antifreeze 543, 546
Antiglare, Interior rear view mirror 212
Antiglare, Auto-dimming rear view
mirrors* 213
Anti-theft systems 107
Anti-theft alarm system 107
Immobilizer 107Aquaplaning see Hydroplaning
Arm rests, Second-row 141
Armrest storage compartments
Front 313
Rear* 314
Ashtrays* 319
Aspect ratio 401
ATF 370
AUDIO menu 171
CD operation 172
Radio operation 171
Satellite radio* operation 172
Audio search function 188
Auto-dimming*, Rear view mirrors 213
Automatic antiglare for rear view
mirrors* 213
Automatic central locking, Control
system 189

548 Index
Automatic climate control (3-zone)* 232
Air conditioning, Cooling 243
Air conditioning refrigerant 540
Air distribution 238
Air recirculation mode 240
Air vents, Front 232, 238
Air vents, Rear 245, 249
Air volume 239
Control panel, Front 234
Control panel, Rear 245
Deactivating system 236
Defogging 240
Defrosting 239
Maximum cooling, MAX COOL 240
Rear passenger compartment 245
Residual heat utilization (REST) 244
Automatic headlamp mode 147
Automatic lighting control, Interior
lighting 154
Automatic locking when driving 130
Automatic shift program 206Automatic transmission 197
Accelerator position 203
Automatic shift program 206
Emergency operation
(limp-home mode) 211
Gear ranges 205
Gear selector lever 54, 197
Gear shifting malfunctions 211
Hill start assist system 204
Kickdown 203
Kickdown, manual shift program
(R 63 AMG only) 211
Manual shift program
(R 63 AMG only) 209
Program mode selector switch 206
Shifting procedure 200
Starting the engine 54
Steering wheel gearshift control 207
Transmission fluid level 370
Transmission positions 201
Automatic transmission fluid see ATF
AUX-socket 311B
Backrest
Seat 44
Seat, Lumbar support 136
Seat, Multicontour* 136
Backup lamps
Messages in the multifunction
display 463–468
Replacing bulbs 484
Bar 401
BAS 102
Lamps in instrument cluster 420
Messages in the multifunction
display 435
Batteries, SmartKey
Check lamp 112, 116
Checking battery condition 115, 120
Battery, Vehicle 506
Charging 513
Disconnecting and connecting 508
Jump starting 514
Removing and installing 508
Bead 401

549 Index
Beverage holder see Cup holder
Bleeding the fuel system
(diesel engine) 505
Bolts, Spare wheel 500
Bottle opener 317
Brake Assist System see BAS
Brake fluid 541
Checking 362
Messages in the multifunction
display 454
Brake lamp
Cleaning lenses 413
Messages in the multifunction
display 463–468
Replacing bulbs 484
Brake pads 348
Messages in the multifunction
display 452
Brakes 348
High-performance brake system
(AMG vehicles only) 350
Warning lamp 421
Break-in the vehicle 346
Bulbs, replacing see Replacing bulbsC
California retail buyers and lessees,
Important notice for 11
Call priority, Tele Aid* 336
Can holder see Cup holder
Capacities and recommended
fuel/lubricants 538
Card holder 32, 317
Cargo compartment
Tie-down rings 299
Cargo compartment cover blind* 306
Cargo tie-down rings 299
Carpets, Cleaning 417
Catalytic converter
(gasoline engine) 357
CD changer* 172, 311
CD player 172
Center console 31
Central locking 189
Automatic 130
Locking/unlocking from the
inside 130
Central locking switch 130Certification label 526, 527
CHECK ENGINE malfunction
indicator lamp 423, 424
Checking tire pressure electronically
Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 388
Tire Pressure Monitoring System
(TPMS), (USA only) 385
Child safety
Infant and child restraint systems 85
Children in the vehicle 84
Air bags 75, 86
Blocking rear door window
operation 97
Indicator lamp, Front passenger front
air bag 92
Infant and child restraint
systems 93, 95
LATCH-type child seat anchors 93
Occupant Classification System
(OCS) 88
Cigarette lighter* 321

550 Index
Climate control 218
Air conditioning, Cooling 228
Air conditioning refrigerant 540
Air distribution 223
Air recirculation mode 226
Air vents, Front 218, 224
Air vents, Rear 230
Air volume 224
Control panel, Front 220
Control panel, Rear 230
Deactivating system 222
Defogging 225
Defrosting 224
Rear passenger compartment 229
Residual heat utilization (REST) 229
Clock 26, 181
Cockpit 24
Cold tire inflation pressure 401
Collapsible tire 475, 534
Collapsible wheel chock 475
Combination switch 59, 60, 62, 150
Compass 342
Control system 186
Control and operation of radio
transmitters 357Control system 159
Multifunction display 159
Multifunction steering wheel 160
Resetting to factory default 176
Control system menus 162
AIRMATIC*/Compass 174
AMG Menu 168
AUDIO 171
Distance warning function* 191
Distronic* 174
Navi* 173
Settings 176
Standard display 166
TEL* 193
Trip computer 191
Vehicle status message memory 174
Control system submenus 163, 165
Comfort* 189
Instrument cluster 179
Lighting 183
Time/Date 181
Vehicle 186Coolant 370, 539, 543
Anticorrosion/antifreeze mixing ratio
and quantity 543
Capacities 539
Checking coolant level 370
Messages in the multifunction
display 455–457
Temperature 359
Corner-illuminating front fog lamps* 151
Fog lamps, Front 149
Messages in the multifunction
display 464
Replacing bulbs 484, 485
Cruise control 266
Activating 267
Messages in the multifunction
display 436
Cup holders 316
Front center console 316
Rear center console 318
Curb weight 401

551 Index
D
Date display, Setting 181
Daytime running lamp mode 148
Setting 183
Deep water see Standing water
Defogging windshield 225, 240
Defrosting, Front 224, 239
Defrosting, Rear 217
Delayed shut-off
Exterior lamps 185
Interior lighting 186
Department of Transportation see DOT
Diesel engine
Bleeding fuel system 505
Preglow indicator lamp 29
Diesel fuel see Fuel
Difficulties
While driving 63
With starting 57
Digital speedometer 159, 167
Dimensions, Vehicle 536
Direction of rotation (tires) 375Displays
Digital speedometer 159, 167
Distronic* 174, 274
Maintenance service indicator
message 407
Messages in the multifunction
display 433–471
Multifunction display 159
Outside temperature 158, 159, 167
Selecting 180
Showing malfunctions 175
Symbol messages 451
Text messages 435
Vehicle status message memory 174
Vehicle system settings,
Control system 163, 165, 176
Distance to empty (range), Trip
computer 191
Distance warning function* 191Distronic* 271
Activating 277
Cleaning system sensor 414
Control system 276
Deactivating 280
Distance warning function* 284
Driving hints 282
Messages in the multifunction
display 437
Warning and indicator lamps 274
Door
Entry lamps 155
Locking, In an emergency 479
Locking/unlocking,
KEYLESS-GO* 116
Locking/unlocking, SmartKey 112
Messages in the multifunction
display 460
Opening from the inside 122
Opening from the outside 113
Remote door unlock (Tele Aid*) 336
Unlocking, Mechanical key 478
