39 Getting started
Unlocking
Unlocking with KEYLESS-GO*
With the KEYLESS-GO function, you can
lock or unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without
inserting the SmartKey into the starter
switch.Grasp an outside door handle or the
tailgate handle.
All turn signal lamps flash once. The
vehicle unlocks. The locking knobs in
the doors move up. The anti-theft alarm
system is disarmed. The locator light-
ing comes on if the feature is enabled
in the control system (
page 184).
Enter the vehicle.
For more information, see “SmartKey with
KEYLESS-GO*” (
page 116).
Starter switch positions
iTo unlock the vehicle, the SmartKey with
KEYLESS-GO must be outside the vehicle, no
further than approximately 3 feet (1 meter) away
from the respective door.
Warning!G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you, and
lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment may cause an accident
and/or serious personal injury.
i If the vehicle has been parked for more than
72 hours, you must pull an outside door handle
in order to activate the KEYLESS-GO function.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment may cause an accident
and/or serious personal injury.

112 Controls in detail
In the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed in your vehicle.
If you are already familiar with the basic
functions of your vehicle, this section will
be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are
given at the beginning of each segment.
Locking and unlocking
For more information on locking and un-
locking, see the “Getting started” section
(
page 38) and (page 68).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are a differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors

the tailgate

the fuel filler flap
SmartKey with remote control
1‹Lock button
2ŠUnlock button* for tailgate
3Locking tab for mechanical key
4ŒUnlock button
5Battery check lamp
6ÂPanic button (
page 99)

125 Controls in detail
Locking and unlocking
Limiting opening height of tailgate*
Vehicles with power tailgate*:
The tailgate opening height can be limited
when transporting goods on a roof rack*
(e.g. presence of an MB sport luggage con-
tainer*). When activated, the tailgate
opens to approximately 6.4 ft (1.95 m).
Activate the limiting opening height of
tailgate using the control system
(
page 189).
Closing the tailgate
Closing the tailgate from the inside
electrically*
In vehicles with power tailgate* you can
close the tailgate from the inside using the
remote tailgate switch.
Press remote tailgate switch1
(
page 124) until tailgate begins to
close.
The tailgate closes. The indicator lamp
in the remote tailgate switch goes out.
While the tailgate is closing an acoustic
signal sounds.
To interrupt the closing procedure:
Press or pull remote tailgate switch1
(
page 124).
!The tailgate swings open upwards automat-
ically. Always make sure there is sufficient over-
head clearance. To stop the opening procedure,
press or pull remote tailgate switch1 or press
theŠ button on the SmartKey or SmartKey
with KEYLESS-GO*. The tailgate stops moving.
iThe tailgate can also be opened using
theŠ button on the SmartKey (
page 115)
or SmartKey with KEYLESS-GO* (
page 121).
Warning!G
Maintain sight of the area around the rear of
the vehicle while operating the tailgate with
the door mounted switch. Monitor the
closing procedure carefully to make sure no
one is in danger of being injured.
To interrupt the closing procedure, press or
pull the door mounted remote tailgate
switch.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the
starter switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the remote tailgate switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.


128 Controls in detail
Locking and unlocking
Closing the tailgate and locking the
vehicle from the outside (vehicles with
KEYLESS-GO*)
In vehicles with power tailgate* and
KEYLESS-GO*, you can close the tailgate
and lock the vehicle simultaneously from
the outside using the KEYLESS-GO* lock-
ing/closing switch or the Šbutton on
the SmartKey with KEYLESS-GO*.
1Tailgate closing switch
2KEYLESS-GO* locking/closing switchEven with the SmartKey removed from the
starter switch, the tailgate closing switch
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.
Warning!G
Only drive with the tailgate closed as,
among other dangers such as blocked
visibility, exhaust fumes may enter the vehi-
cle interior.
iDo not place the SmartKey in the open car-
go compartment. You may lock yourself out.
iIf the vehicle was previously centrally
locked, the tailgate will lock automatically after
closing it. The turn signals will flash three times
to confirm locking.
Warning!G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the cargo compartment opening when clos-
ing the tailgate. Be especially careful when
small children are around. To stop the clos-
ing procedure, do one of the following:

Press tailgate closing switch1.

Press KEYLESS-GO* locking/closing
switch* 2.

Press the Šbutton on the SmartKey
with KEYLESS-GO* (
page 116).

Press or pull the remote tailgate switch
on the driver’s door (
page 125).


339 Controls in detail
Useful features
Step 3:
Hold the end of the hand-held remote
control5 of the device you wish to
train approximately 2 to 5 in
(5 to12 cm) away from the signal trans-
mitter button (2, 3 or4) to be pro-
grammed, while keeping indicator
lamp1 in view.
Step 4:
Using both hands, simultaneously
press hand-held remote control
button6 and the desired signal trans-
mitter button (2, 3 or4). Do not
release the buttons until step 5 is com-
pleted.
Indicator lamp1 will flash, first slowly
and then rapidly.Step 5:
After indicator lamp1 changes from a
slow to a rapidly flashing light, release
the hand-held remote control button
and the signal transmitter button.
Step 6:
Press and hold the just-trained signal
transmitter button (2, 3 or4) and
observe indicator lamp1.
If indicator lamp1 stays on
constantly, programming is complete
and your device should activate when
the respective signal transmitter
button (2, 3 or4) is pressed and
released.
Step 7:
To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.Rolling code programming
To train a garage door opener (or other
rolling code devices) with the rolling code
feature, follow these instructions after
completing the “Programming” portion
(steps 1 through 6) of this text. (A second
person may make the following training
procedures quicker and easier.)
Step 8:
Locate “training” button on the garage
door opener motor head unit.
Exact location and color of the button
may vary by garage door opener brand.
Depending on manufacturer, the
“training” button may also be referred
to as “learn”or “smart” button. If there
is difficulty locating the transmitting
button, refer to the garage door opener
Operator’s Manual.
iIndicator lamp1 flashes immediately the
first time the signal transmitter button is
programmed. If this button has already been
programmed, the indicator lamp will only start
flashing after 20 seconds.
iIf indicator lamp1 flashes rapidly for about
2 seconds and then turns to a constant light,
continue with programming steps 8 through 12
as your garage door opener may be equipped
with the “rolling code” feature.


340 Controls in detail
Useful features
Step 9:
Press the “training” button on the
garage door opener motor head unit.
The “training light” is activated.
You have 30 seconds to initiate the
following step.
Step 10:
Return to the vehicle and firmly
press, hold for 2 seconds and release
the programmed signal transmitter
button (2, 3 or4).
Step 11:
Press, hold for 2 seconds and release
same signal transmitter button a
second time to complete the training
process.Step 12:
Confirm the garage door operation by
pressing the programmed signal trans-
mitter button (2, 3 or4).
Step 13:
To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Gate operator/Canadian programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
which may not be long enough for the
integrated signal transmitter to pick up the
signal during programming. Similar to this
Canadian law, some U.S. gate operators
are designed to “time-out” in the same
manner.
If you live in Canada or if you are having
difficulties programming a gate operator
(regardless of where you live) by using the
programming procedures, replace step 4
with the following:Step 4:
Press and hold the signal transmitter
button (2, 3 or4). Do not release
this button until it has been successful-
ly trained.
While still holding down the signal
transmitter button (2, 3 or4),
“cycle” your hand-held remote control
button6 as follows: Press and hold
button6 for 2 seconds, then release
it for 2 seconds, and again press and
hold it for 2 seconds. Repeat this
sequence on the hand-held remote
control until the frequency signal has
been learned. Upon successful train-
ing, indicator lamp1 will flash slowly
and then rapidly after several seconds.
Proceed with programming step 5 and
step 6 to complete.
iSome garage door openers (or other rolling
code equipped devices) may require you to
press, hold for 2 seconds and release the same
signal transmitter button a third time to com-
plete the training process.


341 Controls in detail
Useful features
Reprogramming a single signal
transmitter button
To program a device using a signal trans-
mitter button previously trained, follow
these steps:
Switch on the ignition (page 39).
Press and hold the desired signal
transmitter button (2, 3 or4).
Do not release the button.
Indicator lamp1 will begin to flash
after 20 seconds. Without releasing
the signal transmitter button, proceed
with programming starting with step 3.Operation of integrated remote control
Switch on the ignition (page 39).
Select and press the appropriate
integrated signal transmitter
button (2, 3 or4) to activate the
remote controlled device.
The integrated remote control trans-
mitter continues to send the signal as
long as the button is pressed – up to
20 seconds.
Erasing the integrated remote control
memory
Switch on the ignition (page 39).
Simultaneously press and hold outer
signal transmitter buttons2 and 4,
for approximately 20 seconds, until the
indicator lamp1 flashes rapidly. Do
not hold for longer than 30 seconds.
The codes of all three channels are
erased.Programming tips
If you are having difficulty programming
the integrated remote control, here are
some helpful tips:

Check the frequency of the hand-held
remote control5 (typically located on
the reverse side of the remote).
The integrated remote control is com-
patible with radio-frequency devices
operating between 280-390 MHz.

Put a new battery in hand-held remote
control5. This will increase the likeli-
hood of the hand-held remote control
sending a faster and more accurate sig-
nal to the integrated remote control.

While performing step 3, hold
hand-held remote control5 at differ-
ent lengths and angles from the signal
transmitter button (2, 3 or4) you
are programming. Attempt varying
angles at the distance of 2 to 5 inches
(5 to 12 cm) away or the same angle at
varying distances.
iUpon completion of programming the
integrated remote control, make sure you retain
the hand-held remote control that came with the
garage door opener, gate operator or other
device. You may need it for use in other vehicles,
for future programming of an integrated
remote control, or simply for continued use as a
hand-held remote control to operate the respec-
tive device in other situations.
iIf you sell your vehicle, erase the codes of all
three channels.

551 Index
D
Date display, Setting 181
Daytime running lamp mode 148
Setting 183
Deep water see Standing water
Defogging windshield 225, 240
Defrosting, Front 224, 239
Defrosting, Rear 217
Delayed shut-off
Exterior lamps 185
Interior lighting 186
Department of Transportation see DOT
Diesel engine
Bleeding fuel system 505
Preglow indicator lamp 29
Diesel fuel see Fuel
Difficulties
While driving 63
With starting 57
Digital speedometer 159, 167
Dimensions, Vehicle 536
Direction of rotation (tires) 375Displays
Digital speedometer 159, 167
Distronic* 174, 274
Maintenance service indicator
message 407
Messages in the multifunction
display 433–471
Multifunction display 159
Outside temperature 158, 159, 167
Selecting 180
Showing malfunctions 175
Symbol messages 451
Text messages 435
Vehicle status message memory 174
Vehicle system settings,
Control system 163, 165, 176
Distance to empty (range), Trip
computer 191
Distance warning function* 191Distronic* 271
Activating 277
Cleaning system sensor 414
Control system 276
Deactivating 280
Distance warning function* 284
Driving hints 282
Messages in the multifunction
display 437
Warning and indicator lamps 274
Door
Entry lamps 155
Locking, In an emergency 479
Locking/unlocking,
KEYLESS-GO* 116
Locking/unlocking, SmartKey 112
Messages in the multifunction
display 460
Opening from the inside 122
Opening from the outside 113
Remote door unlock (Tele Aid*) 336
Unlocking, Mechanical key 478
