1999 TOYOTA AVENSIS Supplement

AC2A6–01
I02286
Drive Belt
Adjusting Bolt
Idle Pulley Lock Nut
– AIR CONDITIONINGDRIVE BELT (1CD–FTV)
AC–3
INSTALLATION
INSTALL DRIVE BELT
(a) Tighten the idle pulley lock nut temporarily.
Torque: 2.5 N·m (25 kgf·cm, 22 in.·lbf)
(b) Install the drive belt.
(c) Using a adjusting bolt, adjust drive belt tension.
Drive belt tension:
New belt: 520 – 755 N (53 – 77 kgf)
Used belt: 196 – 392 N (20 – 40 kgf)
(d) Tighten the idle pulley lock nut at regular torque.
Torque: 39 N·m (390 kgf·cm, 29 ft·lbf)

I12471
A
B
: Low Pressure Charging Hose
: High Pressure Charging HoseA
B
AC2A7–02
N04392
Sleeve AC–4
– AIR CONDITIONINGMANIFOLD GAUGE SET (1CD–FTV)
MANIFOLD GAUGE SET
(1CD–FTV)
SET ON
1. CONNECT CHARGE HOSE TO MANIFOLD GAUGE
SET
Tighten the nuts by hand.
CAUTION:
Do not connect the wrong hoses.
2. CONNECT QUICK DISCONNECT ADAPTERS TO
CHARGING HOSES
Tighten the nuts by hand.
3. CLOSE BOTH HAND VALVES OF MANIFOLD GAUGE
SET
4. REMOVE CAPS FROM SERVICE VALVE ON REFRIG-
ERANT LINE
5. CONNECT QUICK DISCONNECT ADAPTER TO SER-
VICE VALVES
HINT:
Push the quick disconnect adapter onto the service valve, slide,
then slide the sleeve of the quick disconnect adapter downward
to lock it.

AC2A8–01
N06553
– AIR CONDITIONINGMANIFOLD GAUGE SET (1CD–FTV)
AC–5
SET OFF
1. CLOSE BOTH HAND VALVES OF MANIFOLD GAUGE
SET
2. DISCONNECT QUICK DISCONNECT ADAPTERS
FROM SERVICE VALVES ON REFRIGERANT LINE
HINT:
Slide the sleeve of the quick disconnect adapter upward to un-
lock the adapter and remove it from the service valve.
3. INSTALL CAPS TO SERVICE VALVES ON REFRIGER-
ANT LINE

AC1A5–02
AC–6
– AIR CONDITIONINGREFRIGERANT LINE
REFRIGERANT LINE
ON–VEHICLE INSPECTION (1CD–FTV Engine Models)
1. INSPECTION HOSE AND TUBE CONNECTIONS FOR LOOSENESS
2. INSPECT HOSES AND TUBES FOR LEAKAGE
Using a gas leak detector, check for leakage of refrigerant.

AC1A6–03
I12749
LHD:
RHD:Piping Clamp
Liquid Tube
Suction Hose
Discharge Hose
Compressor
Condenser
10 (100, 7)
10 (100, 7)
32 (330, 24)
4A–FE and 7A–FE
Engine Models:
Piping ClampLiquid Tube
Suction Hose
Condenser
Discharge Hose Compressor
10 (100, 7)
10 (100, 7)
N·m (kgf·cm, ft·lbf) : Specified torque
10 (100, 7)
10 (100, 7)
9.8 (100, 7)
1CD–FTV Engine Models
– AIR CONDITIONINGREFRIGERANT LINE
AC–7
COMPONENTS

AC1A7–01
AC–8
– AIR CONDITIONINGREFRIGERANT LINE
REPLACEMENT
1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM
2. REPLACE FAULTY TUBE OR HOSE
NOTICE:
Cap the open fittings immediately to keep moisture or dirt out of the system.
3. TIGHTEN JOINT OF BOLT OR NUT AT SPECIFIED TORQUE
NOTICE:
Connections should not be torqued tighter than the specified torque.
Part tightenedN·mkgf·cmft·lbf
Compressor x Discharge hose101007
Compressor x Suction hose101007
Condenser x Discharge hose101007
Condenser x Liquid tube101007
Liquid line (Block joint)101007
Suction line (Piping joint)3233024
4. EVACUATE AIR FROM REFRIGERATION SYSTEM AND CHARGE SYSTEM WITH REFRIGERANT
Specified amount: 450
50 g (15.87
1.76 oz.)
5. INSPECT FOR LEAKAGE OF REFRIGERANT
Using a gas leak detector, check for leakage of refrigerant.
6. INSPECT AIR CONDITIONING OPERATION

AC29V–02



I12508
DTC Check Harness
Current DisplayControl PanelPast Record DTC Display
In Normal
In Malfuction
”Heating”
Symbol
Memory Clear Button
DTC Calling ButtonDTC Calling Button
Connector BConnector A
– AIR CONDITIONINGCOMBUSTION TYPE POWER HEATER
AC–9
COMBUSTION TYPE POWER HEATER
ON–VEHICLE INSPECTION
NOTICE:

If the glow plug breaks, the ECU detects the breakage and stops the automatic operation, so
the burner heater does not activate. (For other failures, similarly activated.)

The cause of failures (such as voltage malfunction, overheating malfunction, short–circuit or
breakage of functional componects, etc.) and how to remedy are shown by connecting the DTC
tester and reading the DTC.
1. OPERATION
(a) Connect the DTC tester between the connector A (Vehicle harness) of DTC check harness and con-
nector B (Power heater harness).
(b) Start the engine.
(c) Pressing the DTC calling button displays a 3–digit number DTC.






I12758
Buner Motor
Glow Plug
Overheating Sensor
Temp. Sensor
Flame SensorBR
B
BR
W
R
L R
L
BR
L
Connector B14
7 135
6 3 9
8 1
Power
Heater
ECUR
BR
B–R
G
G–W
L
Y
B–WConnector A 8
2
51
3
6
47R
BR
GTerminal L
of AlternatorBattery
Metering Pump
SWIG
Vehicle Side
14 13 10 9 825 13 647
11 1 2
12Fuse (20 A) B–R
G–W AC–10
– AIR CONDITIONINGCOMBUSTION TYPE POWER HEATER
2. DESCRIPTION OF DISPLAY AND BUTTONS
AF: Current Value Malfunction (Blinking at current failure)
Diag: DTC (Example: 064 Flame sensor break)
Mamory Clear button: Deletion of faulty memory (Press both buttons together for longer than 2 sec.)
> Button: Scroll up of faulty memory (The past 5 codes can be stored.)
< Button: Scroll down of faulty memory (The past 5 codes can be stored.)
3. FAULTY MEMORY
The ECU is able to store up to 5 pieces of faulty memory. If it is full, the new data is written over F5.
4. WIRING DIAGRAM
Wire colors are indicated by an alphabetical code.
B=Black W=White BR=Brown L=Blue R=Red G=Green Y=Yellow
The first letter insicates the basic wire color and the seconk letter indicates the color of the stripe.
