1999 TOYOTA AVENSIS Supplement

RS0J2–01
H11591
Spiral Cable Combination Meter
(Warning Light)
Front Passenger Airbag Assembly
Side Airbag Assembly (RH)
Side and Curtain Shield Airbag
Sensor Assembly (RH)
Seat Belt Pretensioner (RH) Steering Wheel Pad
(with Airbag)
Side and Curtain Shield Airbag
Sensor Assembly (LH)Seat Belt
Pretensioner (LH)
Side Airbag Assembly (LH)
Airbag Sensor Assembly Front Airbag Sensor (RH)
Front Airbag
Sensor (LH)Curtain Shield Airbag Assembly (RH) Curtain Shield Airbag Assembly (LH)
– SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS–39
WIRE HARNESS AND CONNECTOR
LOCATION

RS0J3–01
RS–40
– SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
INSPECTION
HINT:
The SRS wire harness is integrated with the instrument panel wire harness assembly. The wires for the SRS
wire harness are encased in a yellow corrugated tube and all the connectors in the system are a standard
yellow color.
1. VEHICLES NOT INVOLVED IN COLLISION
Do a diagnostic system check. (See Pub. No. RM599E on page DI–152)
2. VEHICLES INVOLVED IN COLLISION
(a) Do a diagnostic system check. (See Pub. No. RM599E on page DI–152)
(b) Check breaks in all wires of the SRS wire harness, and exposed conductors.
(c) Check to see if the SRS wire harness connectors are cracked or chipped.

RS0J4–01
– SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS–41
REPLACEMENT
In the following cases, replace the wire harness or connector.

If any part of the SRS wire harness or any connector has been found to be faulty in troubleshoot-
ing.

If any part of the SRS wire harness or any connector has been found to be faulty during checking
items. (See page RS–40)
CAUTION:
If the wire harness used in the SRS is damaged, replace the whole wire harness assembly.

BODY ELECTRICAL
FOG LIGHT SYSTEM BE–1. . . . . . . . . . . . . . . . . . . .
COMBINATION METER BE–2. . . . . . . . . . . . . . . . . .
REFER TO AVENSIS/CORONA REPAIR MANUAL FOR
CHASSIS AND BODY (Pub. No. RM599E)
NOTE: The above pages contain only the points which differ
from the above listed manual.

I12428
ON
OFF
10 11
16
BE196–02
I12429
ON
OFF
10
16
– BODY ELECTRICALFOG LIGHT SYSTEM
BE–1
FOG LIGHT SYSTEM
INSPECTION
1. INSPECT FRONT/REAR FOG LIGHT SWITCH CONTI-
NUITY
Switch positionTester connectionSpecified condition
OFF–No continuity
ON (FRONT)11 – 16Continuity
ON (FRONT/REAR)10 – 11 – 16Continuity
If continuity is not as specified, replace the switch.
2. INSPECT REAR FOG LIGHT SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF–No continuity
ON10 – 16Continuity
If continuity is not as specified, replace the switch.

BE197–02
I12456
1CD–FTV Engine
Vehicle Speed Sensor Low Oil Pressuer Warning Switch
BE–2
– BODY ELECTRICALCOMBINATION METER
COMBINATION METER
LOCATION

BE198–02
I04817
Connector ”A” Connector ”B”
– BODY ELECTRICALCOMBINATION METER
BE–3
CIRCUIT
