1999 TOYOTA AVENSIS Supplement


I12497
–50
Resistance kΩ
0 50 150100 450 500 550 2
1.75 2.25
0.5 0.751 1.251.5
350 300 250 200 400 2.5 2.753
7 14
Ohmmeter
– AIR CONDITIONINGCOMBUSTION TYPE POWER HEATER
AC–19
4. INSPECT FLAME SENSOR
Measur the resistance between the terminal 7, 14.

AC2A0–01
I12452
I12451
I12449
New Gasket
I12447
Control Unit
Cover
I12446
AC–20
– AIR CONDITIONINGCOMBUSTION TYPE POWER HEATER
REASSEMBLY
1. INSTALL HEAT EXCHAMBER
Align slot on heat exchanger (arrow) with lug in jacket.
2. INSTALL COMBUSTION CHAMBER WITH FLAME
TUBE
Install a new gasket and the combustion chamber.
3. INSTALL ELECTRIC MOTOR
(a) Install a new gasket.
(b) Install the electric motor with the 3 screws.
4. INSTALL CABLE HARNESS
(a) Install the water temperature sensor and over heat sen-
sor.
(b) Install the plate with the screw.
5. INSTALL COVER AND CONTROL UNIT
(a) Install the cover and control unit.
(b) Install the 2 hexagon screws.
(c) Install the 2 screws.
6. INSTALL BLOWER COVER
Install the blower cover with the 4 screws.

I12445
– AIR CONDITIONINGCOMBUSTION TYPE POWER HEATER
AC–21
7. INSTALL JACKET COVER
Install the jacket cover with the 4 screws.

AC2A1–01
I12476
I12475
I12474
AC–22
– AIR CONDITIONINGCOMBUSTION TYPE POWER HEATER
INSTALLATION
1. INSTALL COMBUSTION TYPE POWER HEATER
Install the combustion type power heater with the 2 bolts.
2. CONNECT COMBUSTION TYPE POWER HEATER
CONNECTOR
3. CONNECT FUEL PUMP CONNECTOR
4. CONNECT FUEL LINE
Connect the fuel line to the fuel pump.
5. CONNECT HEATER HOSES
(a) Connect the inlet heater hose.
(b) Connect the outlet heater hose.
6. FILL ENGINE COOLANT
7. INSTALL RH UNDER COVER

AC29T–01
I12440
Glow Plug
Engine Block
Heater Bracket
Cap
– AIR CONDITIONINGELECTRICAL TYPE POWER HEATER
AC–23
ELECTRICAL TYPE POWER HEATER
COMPONENTS

AC29U–01
I12479
I12489
Ohmmeter AC–24
– AIR CONDITIONINGELECTRICAL TYPE POWER HEATER
INSPECTION
1. DRAIN ENGINE COOLANT
2. REMOVE AIR CLEANER ASSEMBLY
3. REMOVE GLOW PLUGS
(a) Remove the glow plug cap.
(b) Remove the 3 bolts.
(c) Remove the glow plug plate.
(d) Remove the glow plug stay.
(e) Remove the 3 glow plugs.
4. INSPECT GLOW PLUGS
Using an ohmmeter, check that there is continuity between the
glow plug terminal and ground.
Standard resistance at 20C (68F):
Approx. 0.22 Ω
If there is continuity, replace the glow plug.
Torque: 13 N·m (130 kgf·cm, 9 ft·lbf)
5. REINSTALL GLOW PLUGS
(a) Install the 3 glow plugs.
(b) Install the glow plug stay.
(c) Install the glow plug plate.
(d) Install the 3 bolts.
(e) Install the glow plug cap.
6. REINSTALL AIR CLEANER ASSEMBLY
7. FILL ENGINE COOLANT

AC2A9–01
I12482
3
I12483
1 2
– AIR CONDITIONINGCOMPRESSOR AND MAGNETIC CLUTCH (1CD–FTV)
AC–25
COMPRESSOR AND MAGNETIC
CLUTCH (1CD–FTV)
ON–VEHICLE INSPECTION
1. MAKE THESE VISUAL CHECKS:
(a) Leakage of grease from the clutch bearing
(b) Signs of oil on the pressure plate or rotor
2. INSPECT MAGNETIC CLUTCH BEARING FOR NOISE
(a) Start the engine.
(b) Check for abnormal noise from the compressor when the
A/C switch is OFF.
If abnormal noise is being emitted, replace the magnetic clutch.
3. INSPECT MAGNETIC CLUTCH OPERATION
(a) Disconnect the connector.
(b) Connect the positive (+) lead from the battery to the termi-
nal 3 on the magnetic clutch connector and the negative
(–) lead to the body ground.
(c) Check that the magnetic clutch is energized.
If operation is not as specified, replace the magnetic clutch.
4. INSPECT COMPRESSOR LOCK SENSOR RESIS-
TANCE
(a) Disconnect the connector.
(b) Measure resistance between terminals 1 and 2.
Standard resistance: 65 – 125 Ω at 20C (68F)

AC2AA–01
I12486
Suction Hose
Discharge Hose Spacer
 O–Ring
Engine Under Cover RH
10 (100,7)
25 (250, 18)
Drive Belt
N·m (kgf·cm, ft·lbf)
: Specified torque
 Non–reusable part
I12495
Pressure Plate
Snap Ring
 Snap RingCompressor Stator
Shim
Rotor
13.2 (135, 9)
N·m (kgf·cm, ft·lbf)
: Specified torque
 Non–reusable part AC–26
– AIR CONDITIONINGCOMPRESSOR AND MAGNETIC CLUTCH (1CD–FTV)
COMPONENTS
