– INTRODUCTIONREPAIR INSTRUCTIONS
REPAIR INSTRUCTIONS
GENERAL INFORMATION
BASIC REPAIR HINT
(a) Use fender, seat and floor covers to keep the vehicle
clean and prevent damage.
(b) During disassembly, keep parts in the appropriate order
to facilitate reassembly.
(c) Installation and removal of battery terminal:
(1) Before performing electrical work, disconnect the
negative (–) terminal cable from the battery.
(2) If it is necessary to disconnect the battery for in-
spection or repair, first disconnect the negative (–)
terminal.
(3) When disconnecting the terminal cable, to prevent
damage to the battery terminal, loosen the cable
nut and raise the cable straight up without twisting
or prying it.
(4) Clean the battery terminals and cable ends with a
clean shop rag. Do not scrape them with a file or oth-
er abrasive objects.
(5) Install the cable ends to the battery terminals after
loosening the nut and tighten the nut after installa-
tion. Do not use a hammer to tap the cable ends
onto the terminals.
(6) Be sure the cover for the positive (+) terminal is
properly in place.
(d) Check hose and wiring connectors to make sure that they
are connected securely and correctly.
(e) Non–reusable parts
(1) Always replace cotter pins, gaskets, O–rings and oil
seals, etc. with new ones.
(2) Non–reusable parts are indicated in the component
illustrations by the ”
” symbol.
(f) Precoated parts
Precoated parts are bolts and nuts, etc. that are coated
with a seal lock adhesive at the factory.
(1) If a precoated part is retightened, loosened or
caused to move in any way, it must be recoated with
the specified adhesive.
(2) When reusing precoated parts, clean off the old
adhesive and dry with compressed air. Then apply
the specified seal lock adhesive to the bolt, nut or
threads.
(3) Precoated parts are indicated in the component il-
lustrations by the ”” symbol.
(g) When necessary, use a sealer on gaskets to prevent
leaks.

BE1367
Medium Current Fuse and High Current Fuse
Equal Amperage Rating
V00076
Abbreviation Part Name Symbol Illustration
FUSE
MEDIUM CURRENT FUSE
HIGH CURRENT FUSE
FUSIBLE LINK
CIRCUIT BREAKERFUSE
M–FUSE
H–FUSE
FL
CB
– INTRODUCTIONREPAIR INSTRUCTIONS
IN–5
(h) Carefully observe all specifications for bolt tightening
torques. Always use a torque wrench.
(i) Use of special service tools (SST) and special service ma-
terials (SSM) may be required, depending on the nature
of the repair. Be sure to use SST and SSM where speci-
fied and follow the proper work procedure. A list of SST
and SSM can be found in Preparation section in this
manual.
(j) When replacing fuses, be sure the new fuse has the cor-
rect amperage rating. DO NOT exceed the rating or use
one with a lower rating.
(k) Care must be taken when jacking up and supporting the
vehicle. Be sure to lift and support the vehicle at the prop-
er locations (See page IN–7).
(1) If the vehicle is to be jacked up only at the front or
rear end, make sure to place the stopper under the
wheels at the opposite end to block them in order to
ensure safety.

IN0253
WRONG CORRECT
IN0252
WRONG CORRECT
IN0002
Example IN–6
– INTRODUCTIONREPAIR INSTRUCTIONS
(2) After the vehicle is jacked up, be sure to support it
on stands. It is extremely dangerous to do any work
on a vehicle raised on a jack alone, even for a small
job that can be finished quickly.
(l) Observe the following precautions to avoid damage to the
following parts:
(1) Do not open the cover or case of the ECU unless
absolutely necessary. (If the IC terminals are
touched, the IC may be destroyed by static electric-
ity.)
(2) To disconnect vacuum hoses, pull off the end, not
the middle of the hose.
(3) To pull apart electrical connectors, pull on the con-
nector itself, not the wires.
(4) Be careful not to drop electrical components, such
as sensors or relays. If they are dropped on a hard
floor, they should be replaced and not reused.
(5) When steam cleaning an engine, protect the elec-
tronic components, air filter and emission–related
components from water.
(6) Never use an impact wrench to remove or install
temperature switches or temperature sensors.
(7) When checking continuity at the wire connector, in-
sert the tester probe carefully to prevent terminals
from bending.
(8) When using a vacuum gauge, never force the hose
onto a connector that is too large. Use a step–down
adapter for adjustment. Once the hose has been
stretched, it may leak air.
(m) Installation and removal of vacuum hose:
(1) When disconnecting vacuum hoses, use tags to
identify where they should be reconnected to.
(2) After completing a job, double check that the vacu-
um hoses are properly connected. A label under the
hood shows the proper layout.
(n) Unless otherwise stated, all resistance is measured at an
ambient temperature of 20
C (68
F). Because the resis-
tance may be outside specifications if measured at high
temperatures immediately after the vehicle has been run-
ning, measurement should be made when the engine has
cooled down.

IN040–02
B02394
Front
JACK POSITION
PANTOGRAPH JACK POSITION
SUPPORT POSITIONFront
RearFront center member
Rear suspension member
CAUTION : When jacking–up the rear and front, make sure the car is not
carrying any extra weight.
Safety stand and swing arm type lift
– INTRODUCTIONREPAIR INSTRUCTIONS
IN–7
VEHICLE LIFT AND SUPPORT LOCATIONS

B02395
PLATE TYPE LIFT
HINT :

Attachment
AB
Left and right set position Place the vehicle over the center of the lift.
Front and rear set positionAlign the cushion gum ends of the plate
with the attachment lower ends (A, C).
Align the attachment upper end (B) with the
front jack supporting point
Attachment dimensions
85 mm (3.35 in)
70 mm (2.76 in)
200 mm (7.87 in) 100 mm (3.94 in)C
(
).
IN–8
– INTRODUCTIONREPAIR INSTRUCTIONS

IN0EA–01
BO4111
Negative Cable
– INTRODUCTIONFOR ALL OF VEHICLES
IN–9
FOR ALL OF VEHICLES
PRECAUTION
1. FOR VEHICLES EQUIPPED WITH SRS AIRBAG AND
SEAT BELT PRETENSIONER
(a) The AVENSIS/ CORONA is equipped with an SRS (Sup-
plemental Restraint System), such as the driver airbag,
front passenger airbag, side airbags, curtain shield airbag
and seat belt pretensioners.
Failure to carry out service operations in the correct se-
quence could cause the supplemental restraint system to
unexpectedly deploy during servicing, possibly leading to
a serious accident.
Further, if a mistake is made in servicing the supplemental
restraint system, it is possible the SRS may fail to operate
when required. Before servicing (including removal or
installation of parts, inspection or replacement), be sure
to read the following items carefully, then follow the cor-
rect procedure described in this manual.
(b) GENERAL NOTICE
(1) Malfunction symptoms of the supplemental re-
straint system are difficult to confirm, so the diag-
nostic trouble codes become the most important
source of information when troubleshooting. When
troubleshooting the supplemental restraint system,
always inspect the diagnostic trouble codes before
disconnecting the battery (See Pub. No. RM599E,
page DI–152).
(2) Work must be started after 90 seconds from the
time the ignition switch is turned to the ”LOCK” posi-
tion and the negative (–) terminal cable is discon-
nected from the battery.
(The supplemental restraint system is equipped
with a back–up power source so that if work is
started within 90 seconds of disconnecting the neg-
ative (–) terminal cable from the battery, the SRS
may deploy.)
When the negative (–) terminal cable is discon-
nected from the battery, memory of the clock and
audio systems will be cancelled. So before starting
work, make a record of the contents memorized by
the each memory system. Then when work is fin-
ished, reset the clock and audio systems as before.
To avoid erasing the memory of each memory sys-
tem, never use a back–up power supply from out-
side the vehicle.

R11910Match marks
IN–10
– INTRODUCTIONFOR ALL OF VEHICLES
(3) Even in cases of a minor collision where the SRS
does not deploy, the steering wheel pad (See Pub.
No. RM599E, page RS–15), front passenger airbag
assembly (See Pub. No. RM599E, page RS–28),
side airbag assemblies (See page RS–11), curtain
shield airbag assemblies (See page RS–25) and
seat belt pretensioners (See Pub. No. RM599E,
page BO–152) should be inspected.
(4) Never use SRS parts from another vehicle. When
replacing parts, replace them with new parts.
(5) Before repairs, remove the airbag sensor if shocks
are likely to be applied to the sensor during repairs.
(6) Never disassemble and repair the airbag sensor as-
sembly, side airbag sensor assembly, steering
wheel pad, front passenger airbag, side airbag or
seat belt pretensioner in order to reuse them.
(7) If the airbag sensor assembly, side airbag sensor
assembly, steering wheel pad, front passenger air-
bag, side airbag or seat belt pretensioner have
been dropped, or if there are cracks, dents or other
defects in the case, bracket or connector, replace
them with new ones.
(8) Do not directly expose the airbag sensor assembly,
side airbag sensor assembly, steering wheel pad,
front passenger airbag, side airbag or seat belt pre-
tensioner to hot air or flames.
(9) Use a volt/ohmmeter with high impedance (10 kΩ/V
minimum) for troubleshooting of the electrical cir-
cuit.
(10) Information labels are attached to the periphery of
the SRS components. Follow the instructions on the
notices.
(11) After work on the supplemental restraint system is
completed, check the SRS warning light (See Pub.
No. RM599E, page DI–152).
(c) SPIRAL CABLE (in Combination Switch)
The steering wheel must be fitted correctly to the steering
column with the spiral cable at the neutral position, other-
wise cable disconnection and other troubles may result.
Refer to Pub. No. RM599E, page SR–18 of this manual
concerning correct steering wheel installation.

B02401
Example:
Correct Wrong
Z13950
Example:
– INTRODUCTIONFOR ALL OF VEHICLES
IN–11
(d) STEERING WHEEL PAD (with Airbag)
(1) When removing the steering wheel pad or handling
a new steering wheel pad, it should be placed with
the pad top surface facing up.
Storing the pad with its metallic surface facing up-
ward may lead to a serious accident if the airbag in-
flates for some reason. In addition do not store a
steering wheel pad on top of another one.
(2) Never measure the resistance of the airbag squib.
(This may cause the airbag to deploy, which is very
dangerous.)
(3) Grease should not be applied to the steering wheel
pad and the pad should not be cleaned with deter-
gents of any kind.
(4) Store the steering wheel pad where the ambient
temperature remains below 93
C (200
F), without
high humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) under the
steering column near the combination switch con-
nector before starting work.
(6) When disposing of a vehicle or the steering wheel
pad alone, the airbag should be deployed using an
SST before disposal (See Pub. No. RM599E, page
RS–17).
Carry out the operation in a safe place away from
electrical noise.
