1999 TOYOTA AVENSIS Supplement

B02402
Example:
Correct
Wrong
B02404
Example: IN–12
– INTRODUCTIONFOR ALL OF VEHICLES
(e) FRONT PASSENGER AIRBAG ASSEMBLY
(1) Always store a removed or new front passenger air-
bag assembly with the airbag deployment direction
facing up.
Storing the airbag assembly with the airbag deploy-
ment direction facing down could cause a serious
accident if the airbag inflates.
(2) Never measure the resistance of the airbag squib.
(This may cause the airbag to deploy, which is very
dangerous.)
(3) Grease should not be applied to the front passen-
ger airbag assembly and the airbag door should not
be cleaned with detergents of any kind.
(4) Store the airbag assembly where the ambient tem-
perature remains below 93
C (200
F), without high
humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) installed on
the assembly before starting work.
(6) When disposing of a vehicle or the airbag assembly
alone, the airbag should be deployed using an SST
before disposal (See Pub. No. RM599E, page
RS–30).
Perform the operation in a safe place away from
electrical noise.

B02129
Example:
Correct Wrong
B01546
Example:
– INTRODUCTIONFOR ALL OF VEHICLES
IN–13
(f) SIDE AIRBAG ASSEMBLY
(1) Always store a removed or new side airbag assem-
bly with the airbag deployment direction facing up.
Storing the airbag assembly with the airbag deploy-
ment direction facing down could cause a serious
accident if the airbag inflates.
(2) Never measure the resistance of the airbag squib.
(This may cause the airbag to deploy, which is very
dangerous.)
(3) Grease should not be applied to the side airbag as-
sembly and the surface should not be cleaned with
detergents of any kind.
(4) Store the airbag assembly where the ambient tem-
perature remains below 93
C (200
F), without high
humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) under the
seat before starting work.
(6) When disposing of a vehicle or the side airbag as-
sembly alone, the airbag should be deployed using
an SST before disposal (See page RS–12).
Perform the operation in a safe place away from
electrical noise.



B08604
Example:
CorrectWrong Clear Plastic Bag

B08605
Example:
IN–14
– INTRODUCTIONFOR ALL OF VEHICLES
(g) CURTAIN SHIELD AIRBAG ASSEMBLY
(1) Always store a removed or new curtain shield air-
bag assembly in a clear plastic bag, and keep it in
a safe place.
NOTICE:
Protection bag is not reuse.
CAUTION:
Never disassemble the curtain shield airbag assembly
(2) Never measure the resistance of the airbag squib.
(This may cause the airbag to deploy, which is very
dangerous.)
(3) Grease should not be applied to the curtain shield
airbag assembly and the surface should not be
cleaned with detergents of any kind.
(4) Store the airbag assembly where the ambient tem-
perature remains below 93
C (200
F), without high
humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) into the in-
trument panel before starting work.
(6) When disposing of a vehicle or the curtain shield air-
bag assembly alone, the airbag should be deployed
using an SST before disposal (See page RS–26).
Perform the operation in a safe place away from
electrical noise.

– INTRODUCTIONFOR ALL OF VEHICLES
IN–15
(h) SEAT BELT PRETENSIONER
(1) Never measure the resistance of the seat belt pre-
tensioner. (This may cause the pretensioner oper-
ates, which is very dangerous.)
(2) Oil or water should not be put on the front seat outer
belt and the front seat outer belt should not be
cleaned with detergents of any kind.
(3) Store the front seat outer belt where the ambient
temperature remains below 80
C (176
F), without
high humidity and away from electrical noise.
(4) When using electric welding, first disconnect the
connector (yellow color and 2 pins) installed at the
center pillar lower garnish before starting work.
(5) When disposing of a vehicle or a front seat outer
belt alone, the seat belt pretensioner should be acti-
vated before disposal (See Pub. No. RM599E,
page BO–153). Perform the operation in a safe
place away from electrical noise.
(i) AIRBAG SENSOR ASSEMBLY
(1) Never reuse the airbag sensor assembly involved
in a collision when the SRS has deployed.
(2) The connectors to the airbag sensor assembly
should be connected or disconnected with the sen-
sor mounted on the floor. If the connectors are con-
nected or disconnected while the airbag sensor as-
sembly is not mounted to the floor, it could cause
undesired ignition of the supplemental restraint sys-
tem.
(3) Work must be started after 90 seconds from the
time the ignition switch is turned to the ”LOCK” posi-
tion and the negative (–) terminal cable is discon-
nected from the battery, even if only loosing the set
bolts of the airbag sensor assembly.
(j) WIRE HARNESS AND CONNECTOR
The SRS wire harness is integrated with the instrument
panel wire harness and the cowl wire harness assembly
and floor wire harness assembly. The wires for the SRS
wire harness are encased in a yellow corrugated tube. All
the connectors for the system are also a standard yellow
color. If the SRS wire harness becomes disconnected or
the connector becomes broken due to an accident, etc.,
repair or replace it as shown on Pub. No. RM599E, page
RS–65.

IN–16
– INTRODUCTIONFOR ALL OF VEHICLES
2. FOR VEHICLES EQUIPPED WITH A CATALYTIC CONVERTER
CAUTION:
If large amount of unburned gasoline flows into the converter, it may overheat and create a fire haz-
ard. To prevent this, observe the following precautions and explain them to your customer.
(a) Use only unleaded gasoline.
(b) Avoid prolonged idling.
Avoid running the engine at idle speed for more than 20 minutes.
(c) Avoid spark jump test.
(1) Perform spark jump test only when absolutely necessary. Perform this test as rapidly as possible.
(2) While testing, never race the engine.
(d) Avoid prolonged engine compression measurement.
Engine compression tests must be done as rapidly as possible.
(e) Do not run engine when fuel tank is nearly empty.
This may cause the engine to misfire and create an extra load on the converter.
(f) Avoid coasting with ignition turned off and prolonged braking.
(g) Do not dispose of used catalyst along with parts contaminated with gasoline or oil.
3. IF VEHICLE IS EQUIPPED WITH MOBILE COMMUNICATION SYSTEM
For vehicles with mobile communication systems such as two–way radios and cellular telephones, observe
the following precautions.
(a) Install the antenna as far as possible away from the ECU and sensors of the vehicle’s electronic sys-
tem.
(b) Install the antenna feeder at least 20 cm (7.87 in.) away from the ECU and sensors of the vehicle’s
electronic systems. For details about ECU and sensors locations, refer to the section on the applicable
component.
(c) Do not wind the antenna feeder together with the other wiring as much as possible, also avoid running
the antenna feeder parallel with other wire harnesses.
(d) Check that the antenna and feeder are correctly adjusted.
(e) Do not install powerful mobile communications system.
4. FOR USING HAND–HELD TESTER
CAUTION:
Observe the following items for safety reasons:
Before using the hand–held tester, the hand–held tester’s operator manual should be read thor-
oughly.
Be sure to route all cables securely when driving with the hand–held tester connected to the
vehicle. (i.e. Keep cables away from feet, pedals, steering wheel and shift lever.)
Two persons are required when test driving with the hand–held tester, one person to drive the
vehicle and the other person to operate the hand–held tester.

B07465
New
Previous
– INTRODUCTIONFOR ALL OF VEHICLES
IN–17
5. FOR VEHICLES EQUIPPED WITH POWER WINDOW CONTROL SYSTEM
When the battery is disconnected or the power to the window regulator motor is cut, the power window con-
trol system does not operate. It is necessary to initialize the system in the following procedures. Otherwise
window cannot be operated normally.
(1) Close window to the highest position.
(2) Keep holding the switch for 5 seconds.
(3) Check that automatic operation works. If not, repeat the above procedures.
6. FOR VEHICLES EQUIPPED WITH SLIDING ROOF SYSTEM
Sliding roof stop position might be required to be initialized when battery failures (such as battery disconnec-
tion, connector disconnection and the voltage drop) are detected while the system is in operation. This also
occurs when rotating the motor with the battery disconnected. Sliding roof initialization can be done by the
following procedures.
(1) Operate the roof up to the maximum tilt position.
(2) Release the switch, and push it again in the same direction. (After 10 seconds have elapsed,
initialization begins.)
(3) The roof starts automatic operation if holding the switch, completes full one cycle (tilt down, slide
open, slide close and tilt up) of travel. Do not release the switch until the roof stops.
(4) Check that the roof stops at the correct position.
7. FOR VEHICLES EQUIPPED WITH BRAKE PIPE FIT-
TING OF NEW STANDARD
A flare shape of a new standard is used for the brake pipe fitting
from this changed models.
NOTICE:
When ordering or replacing the parts, please be sure
to check and use the fitting of the same flare type.
Do not over–tighten them more than the standard
torque.
Torque: 15 N·m (155 kgf·cm, 11 ft·lbf)

IN00Z–24
IN–18– INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMS
HOW TO TROUBLESHOOT ECU CONTROLLED SYSTEMS
GENERAL INFORMATION
A large number of ECU controlled systems are used in the AVENSIS/CORONA. In general, the ECU con-
trolled system is considered to be a very intricate system requiring a high level of technical knowledge and
expert skill to troubleshoot. However, the fact is that if you proceed to inspect the circuits one by one, trouble-
shooting of these systems is not complex. If you have adequate understanding of the system and a basic
knowledge of electricity, accurate diagnosis and necessary repair can be performed to locate and fix the
problem. This manual is designed through emphasis of the above standpoint to help service technicians
perform accurate and effective troubleshooting, and is compiled for the following major ECU controlled sys-
tems:
The troubleshooting procedure and how to make use of it are described on the following pages.
SystemPage
Supplemental Restraint SystemDI–1
FOR USING HAND–HELD TESTER
Before using the hand–held tester, the hand–held tester’s operator manual should be read thoroughly.
If the hand–held tester cannot communicate with ECU controlled systems when you have connected
the cable of the hand–held tester to DLC3, turned the ignition switch ON and operated the scan tool,
there is a problem on the vehicle side or tool side.
(1) If communication is normal when the tool is connected to another vehicle, inspect the diagnosis
data link line (Busline) or ECU power circuit of the vehicle.
(2) If communication is still not possible when the tool is connected to another vehicle, the problem
is probably in the tool itself, so perform the Self Test procedures outline in the Tester Operator’s
Manual.

IN06D–07
Vehicle Brought to Workshop
Customer Problem
Analysis
Symptom Confirmation
and Diagnostic Trouble
Code Check
Symptom Simulation
Diagnostic Trouble
Code Chart
Problem Symptoms Table
Circuit Inspection or Parts
Inspection
Repair
Confirmation Test
End 1
2
43
5
6
7
8Ask the customer about the conditions and the
environment when the problem occurred.1
Confirm the symptoms and the problem conditions,
and check the diagnostic trouble codes.
(When the problem symptoms do not appear
during confirmation, use the symptom simulation
method described later on.)2, 3
Check the results obtained in Step 2, then confirm
the inspection procedure for the system or the part
which should be checked using the diagnostic
trouble code chart or the problem symptoms table.4, 5, 6
Check and repair the affected system or part in
accordance with the instructions in Step 6. 7
After completing repairs, confirm that the problem
has been eliminated.
(If the problem is not reproduced, perform the
confirmation test under the same conditions and
in the same environment as when it occurred for
the first time.)8
– INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMSIN–19
HOW TO PROCEED WITH TROUBLESHOOTING
Carry out troubleshooting in accordance with the procedure on the following page. Here, only the basic pro-
cedure is shown. Details are provided in DI section, showing the most effective methods for each circuit.
Confirm the troubleshooting procedures first for the relevant circuit before beginning troubleshooting of that
circuit.
