1999 TOYOTA AVENSIS Supplement

I12491
BO–26
– BODYROOF HEADLINING (Sedan)
(f) w/ Curtain Shield Airbag:
(1) Remove the protection cover.
(2) Install the 2 bolts.
Torque: 5 N·m (51 kgf·cm, 44 in.·lbf)
(3) Install the front pillar garnish.
(4) Install the pillar garnish cover and bolt.
NOTICE:
Be sure to tighten the bolt.
(5) Fell the pillar garnish cover.
(g) Install the front pillar garnishes.
(h) Install the front door opening trims.

BO19R–02
I12750
Roof Headlining Assist Grip
Map LightRoof
Headlining
Sliding Roof
Opening Trim Room Light Sun Visor
Holder
Front Pillar GarnishCenter Pillar
Upper Garnish
Rear Door
Opening Trim
Front Door Scuff Plate
Front Door
Scuff PlateCenter Pillar
Lower GarnishRear Door
Scuff Plate w/ Sliding Roof:
: Specified torqueN·m (kgf·cm, ft·lbf)
42 (430, 31)
Assist Grip
Rear Side Seatback
21 (214, 15)
Front Pillar Garnish
42 (430, 31)
Roof Side Inner Garnish
21 (214, 15)
w/ Curtain shield air bag:
Front Pillar Garnish
– BODYROOF HEADLINING (Liftback)
BO–27
ROOF HEADLINING (Liftback)
COMPONENTS

BO2J7–01
H11626
I12491
H03637
: Clip
H03625
BO–28
– BODYROOF HEADLINING (Liftback)
REMOVAL
1. REMOVE THESE PARTS:
(a) Remove the front door opening trims.
(b) w/ Curtain Shield Airbag:
(1) Using a screwdriver,raise the pillar garnish cover.
(2) Remove the bolt, pillar garnish cover and front pillar
garnish.
(3) Remove the 2 bolts.
(4) Pack the air bag with protection cover.
(c) Remove the front pillar garnishes.
(d) Remove the front door scuff plates.
(e) Remove the rear door opening trims.
(f) Remove the rear door scuff plates.
(g) Remove the center pillar lower garnishes.
2. REMOVE CENTER PILLAR UPPER GARNISH
(a) Remove the front seat outer belt shoulder anchor.
(b) Remove the screw and center pillar upper garnish.
3. REMOVE REAR SIDE SEATBACK
Remove the bolt and rear side seatback.

H03647
: 5 Clips
H11613
(1)
(5)
(4)
(3)(2)
H11614
– BODYROOF HEADLINING (Liftback)
BO–29
4. REMOVE ROOF SIDE INNER GARNISH
Remove the garnish.
5. REMOVE THESE PARTS:
(a) Remove the assist grips.
(b) Remove the sun visors and holders.
(c) Remove the room light.
(d) Remove the map light.
(e) w/ Sliding Roof:
Remove the sliding roof opening trim.
6. REMOVE ROOF HEADLINING
Using a clip remover, remove the 3 clips and roof headlining.
7. w/ Curtain Shield Airbag:
REMOVE CURTAIN SHIELD AIRBAG
(a) In the oder shown in the illustration, remove the bolts and
grommets, then, remove the deployment section of the
curtain shield airbag.
(b) Put the removed airbag in the clear plastic bag and put it
on the instrument panel.

BO2J8–01
H11613
(2)
(3)(4)(1)
(5)
H03647
: Clip
H12072
: Clip
H03625
BO–30
– BODYROOF HEADLINING (Liftback)
INSTALLATION
1. w/ Curtain Shield Airbag:
INSTALL CURTAIN SHIELD AIRBAG
In order shown in the illustration, install the deployment section
of the curtain shield airbag with the bolts and grommet.
Torque: 9.8 N·m (100 kgf·cm, 7 ft·lbf)
2. INSTALL ASSIST GRIP CUSHION
3. INSTALL ROOF HEAD LINING
Install the 3 clips and roof headlining.
4. INSTALL THESE PARTS:
(a) w/ Sliding Roof:
Install the sliding roof opening trim.
(b) Install the map light.
(c) Install the room light.
(d) Install the sun visors and holders.
(e) Install the assist grips.
5. INSTALL ROOF SIDE INNER GARNISH
6. INSTALL CENTER PILLAR UPPER GARNISH
(a) Install the center pillar upper garnish with the screw.
(b) Install the front seat outer belt shoulder anchor with the
bolts.
Torque: 42 N·m (430 kgf·cm, 31 ft·lbf)
7. INSTALL REAR SIDE SEATBACK
Install the rear side seatback with the bolt.
Torque: 21 N·m (214 kgf·cm, 15 ft·lbf)
8. INSTALL THESE PARTS:
(a) Install the center pillar lower garnishes.
Torque: 21 N·m (214 kgf·cm, 15 ft·lbf)
(b) Install the rear door scuff plates.
(c) Install the rear door opening trims.
(d) Install the front door scuff plates.

I12491
– BODYROOF HEADLINING (Liftback)
BO–31
(e) w/ Curtain Shield Airbag:
(1) Remove the protection cover.
(2) Install the 2 bolts.
Torque: 5 N·m (51 kgf·cm, 44 in.·lbf)
(3) Install the front pillar garnish.
(4) Install the pillar garnish cover and bolt.
NOTICE:
Be sure to tighten the bolt.
(5) Fell the pillar garnish cover.
(f) Install the front pillar garnishes.
(g) Install the front door opening trims.

BO19U–02
I12753
Roof Headlining Rear Room Partition
Net Hook
Assist Grip
Map Light
No.2 Room LightAssist GripRoof
Headlining
Sliding Roof Opening Trim Room Light Sun Visor
Holder
Front Pillar GarnishCenter Pillar
Upper GarnishRear Door
Opening Trim
Roof Side Inner Garnish
Deck Side Trim Cover
and Panel
Deck Trim Side Board
Rear Seat Outer Belt
Tonneau Cover
Rear Floor Finish Plate
Roof Side
Inner Garnish
Deck Side Trim Cover
and Panel
Deck Trim Side Board Rear Seatback
AssemblyRear Floor CarpetRoom Partition Net
Rear Side SeatbackFront Door Scuff Plate
Front Pillar Garnish
Front Door
Scuff PlateCenter Pillar
Lower GarnishRear Door
Scuff Plate w/ Sliding Roof:
: Specified torqueN·m (kgf·cm, ft·lbf)
42 (430, 31)
37 (378, 27)
42 (430, 31)
21 (214, 15)
21 (214, 15)
w/ Curtain shield air bag:
Front Pillar Garnish
BO–32
– BODYROOF HEADLINING (Wagon)
ROOF HEADLINING (Wagon)
COMPONENTS

BO2J9–01
H11626
I12491
H03637
: Clip
H03624
: 4 Clips
– BODYROOF HEADLINING (Wagon)
BO–33
REMOVAL
1. REMOVE THESE PARTS:
(a) Remove the front door opening trims.
(b) w/ Curtain Shield Airbag:
(1) Using a screwdriver,raise the pillar garnish cover.
(2) Remove the bolt, pillar garnish cover and front pillar
garnish.
(3) Remove the 2 bolts.
(4) Pack the air bag with protection cover.
(c) Remove the front pillar garnishes.
(d) Remove the front door scuff plates.
(e) Remove the rear door opening trims.
(f) Remove the rear door scuff plates.
(g) Remove the center pillar lower garnishes.
2. REMOVE CENTER PILLAR UPPER GARNISH
(a) Remove the front seat outer belt shoulder anchor.
(b) Remove the screw and center pillar upper garnish.
3. REMOVE THESE PARTS:
(a) Remove the rear floor carpet.
(b) Remove the rear seatback assembly.
(c) w/ Tonneau Cover:
Remove the tonneau cover.
(d) w/ Room Partition Net:
Remove the room partition net.
4. REMOVE REAR FLOOR FINISH PLATE
Using a screwdriver, remove the rear floor finish plate.
HINT:
Tape the screwdriver tip before use.
5. REMOVE REAR ROOM PARTITION NET HOOK
Remove the screw and hook.
