1999 TOYOTA AVENSIS Supplement

BO–10
– BODYWINDSHIELD
(e) Install the upper part of roof headlining.
(f) Install the assist grip.
(g) Install the map light assembly.
(h) Install the sun visors and holders.
(i) Install the cowl louver.
(j) Install the weatherstrip.
(k) Install the front wiper arms.
Torque: 20 N·m (205 kgf·cm, 15 ft·lbf)

BO199–02
H03711
H03642
H03643
– BODYSLIDING ROOF
BO–11
SLIDING ROOF
REMOVAL
1. REMOVE ROOF HEADLINING
(See page BO–23 , BO–28 or BO–33)
2. REMOVE SLIDING ROOF GLASS
(a) Using a torx wrench, remove the 4 screws.
(b) Pull the glass upward to remove it.
3. REMOVE DRIVE GEAR
(a) Disconnect the connector.
(b) Remove the 2 screws and drive motor.
4. REMOVE SLIDING ROOF HOUSING
(a) Disconnect the 4 drain hoses from the housing.
(b) Remove the 8 bolts and 4 brackets.
(c) Remove the 2 bolts, 5 nuts and housing.

BO2J2–01
H03643
H03642
H03711
BO–12
– BODYSLIDING ROOF
INSTALLATION
1. INSTALL SLIDING ROOF HOUSING
(a) Install the housing with the 2bolts and 5nuts.
(b) Install the 4 brackets with the 8 bolts.
(c) Connect the 4 drain hoses to the housing.
2. INSTALL DRIVE GEAR
(a) Install the drive motor with 2 screws.
(b) Connect the connector.
3. INSTALL SLIDING ROOF GLASS
(a) Push the glass upward to remove it.
(b) Install the 4 screws.
4. INSTALL ROOF HEADLINING
(See page BO–23, BO–28 or BO–33)

BO19J–02
I12662
Reinforcement
No.1 BraceFront Pillar Garnish
Instrument Panel
Front Door Opening Trim
Rear Door
Scuff Plate
Glove Compartment Door Heater Control
Assembly
No.1 Under Cover
Rear Console Box
Parking Brake Hole Cover Steering Wheel Pad Steering Wheel Combination Switch Column CoverLower Finish Panel Cluster Finish Panel Combination Meter No.1 Register
Center Cluster
Finish Panel
Front Door Scuff Plate Cowl Side Trim
Center Pillar Lower GarnishRear Door Opening Trim
B C
D
F G
A
A
B
CC
D
E
E
E
EE
E
E
EE
F
G
G
G
HHH
x 4Front Ash Receptacle
34 (350, 25)
18 (185, 13)
: Specified torqueN·m (kgf·cm, ft·lbf)
Curtain Shield Airbag
F
F
w/ Curtain shield air bag:
Front Pillar Garnish
– BODYINSTRUMENT PANEL
BO–13
INSTRUMENT PANEL
COMPONENTS

H03670
Defroster NozzleNo.2 Side Defroster Duct
No.1 Side
Defroster Duct
No.3 Heater to Register Duct
No.4 Heater to Register Duct
No.1 Heater to
Register DuctNo.1 PinNo.1 PinFront Passenger
Airbag Assembly
No.2 Side Defroster
Nozzle
No.2 Register
Center Bracket
Front Ash
Receptacle Retainer
Wire Harness
E
E
EEEE
E
E
E
E
E
EE
E
E
E
E
EE
EE
E BO–14
– BODYINSTRUMENT PANEL

H03703
Shape Size
ø = 8
(0.31)
L = 16
(0.63)mm (in.)
Shape Size
Shape Size
ø = 6
(0.24)
L = 20
(0.79)ø = 6
(0.24)
L = 18
(0.71)
ø = 6
(0.24)
L = 16
(0.63)ø = 5.22
(0.2055)
L = 16
(0.63)ø = 5
(0.20)
L = 18.5
(0.728)
ø = 8
(0.31)ø = 6
(0.24)
– BODYINSTRUMENT PANEL
BO–15
HINT:
Screw shapes and size are indicated in the table below. The codes (A – H) correspond to those indicated
on the previous page.

BO2J3–01
I12491
H03659
H03660
: 4 Clips BO–16
– BODYINSTRUMENT PANEL
REMOVAL
1. REMOVE THESE PARTS:
(a) Remove the front door opening trims.
(b) Remove the front pillar garnishes.
(c) w/ Curtain Shield Airbag:
(1) Remove the 2 bolts.
(2) Pack the airbag with protection cover.
(3) Using a screwdriver, raise the pillar garnish cover.
(4) Remove the bolt, pillar garnish cover and front pillar
garnish.
NOTICE:
Protection rang is from instrument panel to ceiling.
(d) Remove the front door scuff plates.
(e) Remove the cowl side trims.
(f) Remove the rear door opening trims.
(g) Remove the rear door scuff plates.
(h) Remove the center pillar lower covers.
(i) Remove the front seats.
2. REMOVE STEERING WHEEL
(See Pub. No.RM599E on page SR–13)
3. REMOVE LOWER FINISH PANEL
(a) Remove the 2 screws and hood lock control lever.
(b) Remove the 2 screws and lower finish panel.
4. REMOVE THESE PARTS:
(See Pub. No.RM599E on page SR–13)
(a) Remove the column cover.
(b) Remove the combination switch.
(c) Remove the steering column.
5. REMOVE CLUSTER FINISH PANEL
(a) Remove the 2 screws.
(b) Using a screwdriver, remove the cluster finish panel, then
disconnect the connector.
HINT:
Tape the screwdriver tip before use.
6. REMOVE COMBINATION METER

H03661
: 4 Clips
H03662
: 3 Clips
H03663
H03664
H03665
: 6 Clips
– BODYINSTRUMENT PANEL
BO–17
7. REMOVE NO.1 REGISTER
Using a screwdriver, remove the No.1 register.
HINT:
Tape the screwdriver tip before use.
8. REMOVE NO.1 UNDER COVER
Using a screwdriver, remove the No.1 under cover.
HINT:
Tape the screwdriver tip before use.
9. REMOVE GLOVE COMPARTMENT DOOR
Remove the 2 glove shaft and glove compartment door.
10. REMOVE PARKING BRAKE HOLE COVER
11. REMOVE REAR CONSOLE BOX
(a) M/T:
Remove the shift lever knob.
(b) Remove the 2 bolts, 4 caps, 4 screws and rear console
box.
12. REMOVE CENTER CLUSTER FINISH PANEL
Using a screwdriver, remove the panel, then disconnect the
connectors.
13. REMOVE HEATER CONTROL ASSEMBLY
(See Pub. No.RM599E on page AC–106)
