2018 SUBARU CROSSTREK Owners Manual

(116,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
warning indicator of the keyless access
with push-button start system”F3-25.&When access key fob does
not operate properlyRefer to“Access key fob–if access key
fob does not operate properly”F9-17.&Replacing battery of access
key fobRefer to“Replacing battery of access key
fob”F11-43.&Replacing access key fobAccess key fobs can be replaced at
SUBARU dealers. For more details, con-
tact a SUBARU dealer.
&Certification for keyless ac-
cess with push-button start
system.U.S.-spec. models
FCC ID: HYQ14AHK
FCC ID: Y8PFJ16-1
FCC ID: Y8PSSPIMB02
CAUTION
FCC WARNING
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.NOTEThis device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This de-
vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation..Canada-spec. models
Keys and doors/Keyless access with push-button start system
2-14

(117,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
.Mexico-spec. modelsIFT
RLVDE1415-1661
14AHK
DENSO
ImmobilizerThe immobilizer system is designed to
prevent an unauthorized person from
starting the engine. Only keys registered
with your vehicle’s immobilizer system can
be used to operate your vehicle. If engine
start is attempted with an unregistered
access key fob or key, the engine will not
start. Even if the engine does start, it will
stop after a few seconds. This system,
however, is not a 100% anti-theft guaran-
tee.
CAUTION
.Do not place the key under direct
sunlight or anywhere it may be-
come hot.
.Do not get the key wet. If the key
gets wet, wipe it dry with a cloth
immediately.
.Do not modify or remove the
system. If modified or removed,
the proper operation of the sys-
tem cannot be guaranteed.
NOTE.To protect your vehicle from theft,
please pay close attention to the follow-
ing security precautions:
–Never leave your vehicle unat-
tended with its keys inside.
–Before leaving your vehicle,
close all windows and the moon-
roof, and lock the doors and rear
gate.
–Do not leave spare keys or any
record of your key number in the
vehicle.
.The vehicle has a maintenance-free
type immobilizer system.&Security indicator lightRefer to“Security indicator light”F3-29.&Key replacementYour key number plate will be required if
you ever need a replacement key made.
Any new key must be registered for use
with your vehicle’s immobilizer system
before it can be used. The maximum
number of keys that can be registered for
use with one vehicle is as follows.
.Four (models without“keyless access
with push-button start system”)
.Seven (models with“keyless access
–CONTINUED–
Keys and doors/Immobilizer
2-15
2

(118,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
with push-button start system”)
One key that has already been registered
is required in order to register a new key.NOTEIf you lose a key, the lost key’s ID code
still remains in the memory of the
vehicle’s immobilizer system. For se-
curity reasons, the lost key’s ID code
should be erased from the memory. To
erase the lost key’s ID code, all keys
that will be used are required.
For details about new key registration
and erasing the lost key’s ID code,
contact your SUBARU dealer.&Certification for immobilizer
system.For models with“keyless access
with push-button start system”:
Refer to“Certification for keyless access
with push-button start system”F2-14..For models without“keyless access
with push-button start system”:
–U.S.-spec. models
FCC ID: Y8PFJ16-2
CAUTION
FCC WARNING
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.NOTEThis device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This de-
vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.–Canada-spec. models
Keys and doors/Immobilizer
2-16

(119,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
–Mexico-spec. models
Remote keyless entry system
CAUTION
.Do not expose the remote trans-
mitter to severe shocks, such as
those experienced as a result of
dropping or throwing.
.Do not take the remote transmit-
ter apart except when replacing
the battery.
.Do not get the remote transmitter
wet. If it gets wet, wipe it dry with
a cloth immediately.
.When you carry the remote trans-
mitter on an airplane, do not
press the button of the remote
transmitter while in the airplane.
When any button of the remote
transmitter is pressed, radio
waves are sent and may affect
the operation of the airplane.
When you carry the remote trans-
mitter in a bag on an airplane,
take measures to prevent the
buttons of the remote transmitter
from being pressed.
Access key fob
1) Lock/arm button
2) Unlock/disarm button
3) Rear gate unlock button
4) PANIC button
–CONTINUED–
Keys and doors/Remote keyless entry system
2-17
2

(120,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Transmitter
1) Lock/arm button
2) Unlock/disarm button
3) Rear gate unlock button
4) PANIC buttonThe remote keyless entry system has the
following functions.
.Locking and unlocking the doors (and
rear gate)
.Unlocking the rear gate
.Sounding a panic alarm
.Arming and disarming the alarm sys-
tem. For detailed information, refer to
“Alarm system”F2-24.
The operable distance of the remote key-
less entry system is approximately 30 feet
(10 meters). However, this distance will
vary depending on environmental condi-tions. The system’s operable distance will
be shorter in areas near a facility or
electronic equipment emitting strong radio
waves such as a power plant, broadcast
station, TV tower, or remote controller of
home electronic appliances.
NOTE.For models with“keyless access
with push-button start system”,the
remote keyless entry system will not
be activated when the push-button
ignition switch is in any position other
than the“OFF”position.
.For models without“keyless access
with push-button start system”,the
remote keyless entry system will not
be activated when the key is inserted in
the ignition switch.
.The hazard warning flashers will
flash once or twice when the access
key fob/transmitter button is pressed in
the following cases.
–When locking the doors
–When unlocking the doors
–When unlocking the rear gate
Operation of the hazard warning
flashers in the above cases can be set
to“On”or“Off”by a SUBARU dealer.
Consult your SUBARU dealer for de-
tails.
&Locking the doorsPress the lock/arm button to lock all doors
and rear gate. An electronic chirp will
sound once and the hazard warning
flashers will flash once.
If any of the doors (or the rear gate) are not
fully closed, the following will occur to alert
you that the doors (or the rear gate) are not
properly closed.
.an electronic chirp sounds five times.
.the hazard warning flashers flash five
times.
When you close the door, it will automati-
cally lock and then the following will occur.
.an electronic chirp sounds once.
.the hazard warning flashers flash once.&Unlocking the doorsPress the unlock/disarm button to unlock
the driver’s door. An electronic chirp will
sound twice and the hazard warning
flashers will flash twice. To unlock all doors
and the rear gate, briefly press the unlock/
disarm button a second time within 5
seconds.NOTEIf the interval between the first and
second presses of the unlock/disarm
button (for unlocking of all of the doors
Keys and doors/Remote keyless entry system
2-18

(121,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
and the rear gate) is extremely short,
the system may not respond.&Unlocking the rear gatePress the rear gate unlock button to unlock
the rear gate.
An electronic chirp will sound twice and the
hazard warning flashers will flash twice.&Vehicle finder functionUse this function to find your vehicle
parked among many vehicles in a large
parking lot. Provided you are within 30 feet
(10 meters) of the vehicle, pressing the
lock/arm button three times in a 5-second
period will cause your vehicle’s horn to
sound once and its hazard warning
flashers to flash three times.NOTEIf the interval between presses is too
short when you press the lock/arm
button three times, the system may
not respond to the signals from the
remote transmitter.
&Sounding a panic alarmTo activate the alarm, press the“PANIC”
button once.
The horn will sound and the hazard
warning flashers will flash.
To deactivate the panic alarm, press any
button on the remote transmitter. Unless a
button on the remote transmitter is
pressed, the alarm will be deactivated
after approximately 30 seconds.&Setting audible signal opera-
tion (models without“keyless
access with push-button start
system”)Using an electronic chirp, the system will
give you an audible signal when the doors
lock and unlock. If desired, you may turn
the audible signal off.
Perform the following steps to deactivate
the audible signal. You can also use the
same steps to restore the function.
1. Sit in the driver’s seat and shut all
doors and the rear gate.
2. Hold down“
”of the power door
locking switch.
3. While holding down“
”of the power
door locking switch, pull the key out and re-
insert it into the ignition switch at least 6
times within 10 seconds after Step 2.
4. Open and close the driver’s door once
within 10 seconds after Step 3.
5. The hazard warning flashers flash 3
times to indicate completion of the setting.
Your SUBARU dealer can perform the
above procedure for you. Also, for models
with a combination meter display (color
LCD), the setting can be changed using
the display. For details, refer to“Vehicle
Setting”F3-41.–CONTINUED–
Keys and doors/Remote keyless entry system
2-19
2

(122,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Replacing the batteryRefer to“Replacing key battery”F11-42.&Replacing lost transmittersIf you lose a transmitter or want to
purchase additional transmitters (up to
four can be programmed), your transmit-
ters should be reprogrammed for security
reasons. For details, contact your
SUBARU dealer and have the transmitters
programmed into the remote keyless entry
system.&Certification for remote key-
less entry system!U.S.-spec. models
FCC ID: CWTB1G077
FCC ID: CWTD1G049
CAUTION
FCC WARNING
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.
NOTEThis device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This de-
vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.!Canada-spec. models
Keys and doors/Remote keyless entry system
2-20

(123,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
!Mexico-spec. modelsIFETEL RLVSUTB15-1814
SUBARU
MODEL: TB1G077
IFETEL RLVSUTD15-1815
SUBARU
MODEL: TD1G049
Door locks&Locking and unlocking from
the outside
NOTEIf you unlock the driver’s door with a
key (including an emergency key) and
open the door while the alarm system is
armed, the alarm system is triggered
and the vehicle’s horn sounds. In this
case, perform any of the following
operations:
.Models with“keyless access with
push-button start system”:
–Press any button on the access
key fob (except when the access
key fob battery is discharged).
–Press the push-button ignition
switch to“ACC”.
–Carry the access key fob and
perform either of the following pro-
cedures.
–
Grip the front door handle
–
Press the rear gate opener
button
.Models without“keyless access
with push-button start system”:
–Press any button on the remote
transmitter (except when the trans-
mitter battery is discharged).–Insert the key into the ignition
switch and turn the ignition switch
to“ON”.
For details about the alarm system,
refer to“Alarm system”F2-24.
!How to lock and unlock the vehicle
by using the key
1) Rotate the key toward the front to lock.
2) Rotate the key toward the rear to unlock.In this case, only the driver’s side door is
locked.NOTEModels with“keyless access with
push-button start system”:
The emergency key is directional. If the
key cannot be inserted, change the
–CONTINUED–
Keys and doors/Door locks
2-21
2
