• Press the brake pedal with moreforce than normal since you will have
reduced brake performance.
• More steering effort will be required because the power steering system
will be disabled.
• If you are driving down a long hill, the brakes may overheat and brake per‐
formance will be reduced. Stop often
and let the brakes cool off.
CAUTION
nAutomatic transaxle
•If the car is being towed with allfour wheels on the ground, it canbe towed only from the front. Besure that the transaxle is in neu‐tral. Be sure the steering is un‐locked by placing the ignitionswitch in the ACC position. A drivermust be in the towed vehicle tooperate the steering and brakes.
•To avoid serious damage to theautomatic transaxle, limit the ve‐hicle speed to 15 km/h (10 mph)and drive less than 1.5 km (1 mile)when towing.
(Continued)
(Continued)
•Before towing, check the auto‐matic transaxle for fluid leaks un‐der your vehicle. If the automatictransaxle fluid is leaking, flatbedequipment or a towing dolly mustbe used.

7-29
7
What to do in an emergency

EMERGENCY COMMODITY (IF EQUIPPED)
There are some emergency commodi‐ ties in the vehicle to help you respond
to the emergency situation.
Fire extinguisher
If there is a small fire and you know
how to use the fire extinguisher, take the following steps carefully. 1. Pull the pin at the top of the extin‐ guisher that keeps the handle from
being accidentally pressed.
2. Aim the nozzle toward the base of the fire.
3. Stand approximately 2.5 m (8 ft) away from the fire and squeeze
the handle to discharge the extin‐
guisher. If you release the handle,
the discharge will stop.
4. Sweep the nozzle back and forth at the base of the fire. After the fire
appears to be out, watch it careful‐
ly since it may re-ignite.
First aid kit
There are some items such as scissors,
bandage and adhesive tape etc. in the kit to give first aid to an injured person.
Triangle reflector
Place the triangle reflector on the roadto warn oncoming vehicles during
emergencies, such as when the vehicle
is parked by the roadside due to any problems.
Tire pressure gauge (if
equipped)
Tires normally lose some air in day-to-
day use, and you may have to add a
few pounds of air periodically and it is
not usually a sign of a leaking tire, but
of normal wear. Always check tire pres‐
sure when the tires are cold because
tire pressure increases with tempera‐
ture.
To check the tire pressure, take the fol‐ lowing steps; 1. Unscrew the inflation valve cap that is located on the rim of the
tire.
2. Press and hold the gauge against the tire valve. Some air will escape
as you begin and more will escape
if you don't press the gauge in
firmly.
3. A firm non-leaking push will acti‐ vate the gauge. 4. Read the tire pressure on the
gauge to know whether the tire
pressure is low or high.
5. Adjust the tire pressures to the specified pressure. Refer to L
