2018 KIA STONIC Owners Manual

INSTRUMENT PANEL OVERVIEW
0:#
1. Instrument cluster.......................... .......................... p. 4-45
2. Horn...................................... ...................................... p. 4-39
3. Driver’s front air bag........................ ........................ p. 3-46
4. Light control............................... ............................... p. 4-81Turn signals................................ ................................ p. 4-84
5. Wiper/Washer.............................. .............................. p. 4-90
6. Ignition switch.............................. .............................. p. 6-06 ENGINE START/STOP button................. ................. p. 6-10
7. Hazard warning flasher switch............... ............... p. 7-02
8. Audio
9. Central door lock switch..................... ..................... p. 4-18
10. Climate control system............... ............... p. 4-99, 4-108
11. AUX-USB port.............................. .............................. p. 5-03
12. Shift lever............................ ............................ p. 6-20, 6-24
13. Parking brake lever.................................................... p. 6-31
14. Passenger’s front air bag.................... .................... p. 3-46
15. Power outlet.............................. .............................. p. 4-129
16. Glove box................................. ................................. p. 4-122
17. Steering wheel audio remote control
18. Cigarette lighter........................... ........................... p. 4-126
19. Seat warmer.............................. .............................. p. 4-128
20. Heated steering wheel switch................ ................ p. 4-39
21. Idle Stop and Go system OFF button.......... .......... p. 6-16
22. USB charger.............................................................. p. 4-130

2-05
2
Your vehicle at a glance

ENGINE COMPARTMENT
¥
(BTPMJOF
&OHJOF
-
¥
(BTPMJOF
&OHJOF
-

5IF
BDUVBM
FOHJOF
DPNQBSUNFOU
JO
UIF
WFIJDMF
NBZ
EJGGFS
GSPN
UIF
JMMVTUSBUJPO
1. Engine coolant reservoir..................... ..................... p. 8-48
2. Engine oil filler cap.......................... .......................... p. 8-45Changing the engine oil and filter............. ............. p. 8-46
3. Brake/clutch fluid reservoir.................. .................. p. 8-52
4. Air cleaner................................. ................................. p. 8-58
5. Fuse box................................... ................................... p. 8-77
6. Negative battery terminal................... ................... p. 8-63
7. Positive battery terminal.................... .................... p. 8-63
8. Engine oil dipstick........................... ........................... p. 8-44 Changing the engine oil and filter............. ............. p. 8-46
9. Radiator cap............................... ............................... p. 8-48
10. Windshield washer fluid reservoir............. ............. p. 8-55
11. Automatic transaxle fluid dipstick.......................... p. 8-53
Your vehicle at a glance
2-06

0:#0:#$
(BTPMJOF
&OHJOF
-

%JFTFM
&OHJOF
--

5IF
BDUVBM
FOHJOF
DPNQBSUNFOU
JO
UIF
WFIJDMF
NBZ
EJGGFS
GSPN
UIF
JMMVTUSBUJPO
1. Engine coolant reservoir..................... ..................... p. 8-48
2. Engine oil filler cap.......................... .......................... p. 8-45
Changing the engine oil and filter............. ............. p. 8-46
3. Brake/clutch fluid reservoir.................. .................. p. 8-52
4. Air cleaner................................. ................................. p. 8-58
5. Fuse box................................... ................................... p. 8-77
6. Negative battery terminal................... ................... p. 8-63
7. Positive battery terminal.................... .................... p. 8-63
8. Engine oil dipstick........................... ........................... p. 8-44 Changing the engine oil and filter............. ............. p. 8-46
9. Radiator cap............................... ............................... p. 8-48
10. Windshield washer fluid reservoir............. ............. p. 8-55

2-07
2
Your vehicle at a glance

Seats............................................................................................3-02Front seat adjustment......................................................... 3-05
Headrest................................................................................. 3-06
Seatback pocket ................................................................... 3-08
Rear seat adjustment.......................................................... 3-09
Seat belts....................................................................................3-13 Seat belt restraint system.................................................. 3-13
Pre-tensioner seat belt ...................................................... 3-20
Seat belt precautions........................................................... 3-23
Care of seat belts.................................................................. 3-25
Child Restraint System (CRS).................................................. 3-26 Selecting a Child Restraint System (CRS)......................... 3-26
Installing a Child Restraint System (CRS)......................... 3-28ISOFIX anchorage and top-tether anchorage
(ISOFIX anchorage system) for children............................3-29
Air bag - supplemental restraint system ............................ 3-38 How does the air bag system operate.............................. 3-39
Air bag warning light............................................................ 3-42
SRS components and functions.......................................... 3-43
Driver's and passenger's front air bag ............................. 3-46
Side air bag ............................................................................3-51
Curtain air bag ...................................................................... 3-53
SRS care.................................................................................. 3-60
Additional safety precautions............................................. 3-60Adding equipment to or modifying your air bag-
equipped vehicle.................................................................... 3-61
Air bag warning label ........................................................... 3-62
Safety features of your vehicle

3

SEATS
5IF
BDUVBM
TFBUT
JO
UIF
WFIJDMF
NBZ
EJGGFS
GSPN
UIF
JMMVTUSBUJPO
Driver’s seat
1. Forward and backward
2. Seatback angle3. Seat cushion height *
4. Headrest
Front passenger’s seat
5. Forward and backward
6. Seatback angle
7. Headrest
Rear seat
8. Headrest *
9. Seatback folding *
WARNING
nLoose objects
Loose objects in the driver’s footarea could interfere with the opera‐tion of the foot pedals, possiblycausing an accident. Do not placeanything under the front seats.
*
if equipped
Safety features of your vehicle
3-02

WARNING
nUprighting seat
When you return the seatback to itsupright position, hold the seatbackand return it slowly and be surethere are no other occupants aroundthe seat. If the seatback is returnedwithout being held and controlled,the back of the seat could springforward resulting in accidental injuryto a person struck by the seatback.
WARNING
nDriver responsibility for pas‐sengers
Riding in a vehicle with the seatbackreclined could lead to serious or fatalinjury in an accident. If a seat is re‐clined during an accident, the occu‐pant’s hips may slide under the lapportion of the seat belt, applyinggreat force to the unprotected abdo‐men. Serious or fatal internal injuriescould result. The driver must advisethe passenger to keep the seatbackin an upright position whenever thevehicle is in motion.
WARNING
Do not use a sitting cushion that re‐duces friction between the seat andpassenger. The passenger's hipsmay slide under the lap portion ofthe seat belt during an accident or asudden stop. Serious or fatal internalinjuries could result because the seatbelt can't operate normally.
WARNING
nDriver’s seat
•Never attempt to adjust the seatwhile the vehicle is moving. Thiscould result in loss of control, andan accident causing death, seriousinjury, or property damage.
•Do not allow anything to interferewith the normal position of theseatback. Storing items against aseatback or in any other way in‐terfering with proper locking of aseatback could result in serious orfatal injury in a sudden stop or col‐lision.
(Continued)
(Continued)
•Always drive and ride with yourseatback upright and the lap por‐tion of the seat belt snug and lowacross the hips. This is the bestposition to protect you in case ofan accident.
•In order to avoid unnecessary andperhaps severe air bag injuries, al‐ways sit as far back as possiblefrom the steering wheel whilemaintaining comfortable control ofthe vehicle. We recommend thatyour chest be at least 250 mm(10 inches) away from the steer‐ing wheel.
WARNING
nRear seatbacks
•The rear seatback must be secure‐ly latched. If not, passengers andobjects could be thrown forwardresulting in serious injury or deathin the event of a sudden stop orcollision.
(Continued)

3-03
3
Safety features of your vehicle

(Continued)
•Luggage and other cargo should belaid flat in the cargo area. If ob‐jects are large, heavy, or must bepiled, they must be secured. Underno circumstances should cargo bepiled higher than the seatbacks.Failure to follow these warningscould result in serious injury ordeath in the event of a suddenstop, collision or rollover.
•No passenger should ride in thecargo area or sit or lie on foldedseatbacks while the vehicle ismoving. All passengers must beproperly seated in seats and re‐strained properly while riding.
•When resetting the seatback tothe upright position, make sure itis securely latched by pushing itforward and backwards.
•To avoid the possibility of burns,do not remove the carpet in thecargo area. Emission control devi‐ces beneath this floor generatehigh temperatures.
WARNING
After adjusting the seat, alwayscheck that it is securely locked intoplace by attempting to move theseat forward or backward withoutusing the lock release lever. Suddenor unexpected movement of thedriver's seat could cause you to losecontrol of the vehicle resulting in anaccident.
WARNING
•Use extreme caution so that handsor other objects are not caught inthe seat mechanisms while theseat is moving.
•Do not put a cigarette lighter onthe floor or seat. When you oper‐ate the seat, gas may gush out ofthe lighter and cause fire.
•If there are occupants in the rearseats, be careful while adjustingthe front seat position.
(Continued)
(Continued)
•Use extreme caution when pickingsmall objects trapped under theseats or between the seat and thecenter console. Your hands mightbe cut or injured by the sharpedges of the seat mechanism.
Feature of Seat Leather
• Leather is made from the outer skin of an animal, which goes through a
special process to be available for use. Since it is a natural substance,
each part differs in thickness or den‐
sity.
Wrinkles may appear as a natural re‐
sult of stretching and shrinking de‐
pending on the temperature and hu‐ midity.
• The seat is made of stretchable fab‐ ric to improve comfort.
• The parts contacting the body are curved and the side supporting area
is high which provides driving comfort
and stability.
• Wrinkles may appear naturally from usage. It is not a fault of the product.
Safety features of your vehicle
3-04
