Area View menus (modes)

Fig. 278 Display of the Area View: Full-screen bird's eye view (option A), enlarged off-road view (option B), partial view of perpendicular parking with modes menu (option C) and partial view of perpendicular parking with settings menu (option D).

Front camera views

View Screen display of front camera
Front cross-traffic I Area on left of screen: Left-hand side of intersection.
Area in center of screen: Area directly in front of vehicle.
Area on right of screen: Right-hand side of intersection.
Perpendicular parking J The area in front of the vehicle is displayed. Orientation lines are displayed for assistance. See Rear Assist Mode 1
Off-road N The area directly in front of the vehicle is shown in a bird's eye view. This can be used, for example, when driving across a slope so that the area directly in front of the vehicle can be seen more easily.
Side camera views

View Screen display of side cameras
Off-road, left and right side O Areas directly next to the vehicle are displayed in a bird's eye view so you can steer the vehicle accurately around obstacles. The red lines are displayed when an obstacle is about 16 inches (40 cm) from the vehicle.
Left side P Shows the driver or front passenger side D next to the vehicle separately as a bird's eye view. This helps you to see the blind spot along the side of the vehicle. Right side Q
Rear camera views

View Screen display of rear camera
Perpendicular parking K The area behind the vehicle is displayed. Orientation lines are displayed for assistance. See Rear Assist Mode 1
Parallel parking M The area directly behind the vehicle is displayed. The colored areas and lines are provided for orientation. See Rear Assist Mode 2
Trailer hitch R The rear of the vehicle is displayed. The red line and the green lines are used to indicate the distance. The distance between the green lines and the red line is about 12 inches (30 cm) each. The distance between the red line and the vehicle is also about 12 inches (30 cm). The yellow line indicates the extension of the trailer hitch towards the rear and shows the direction to the trailer hitch depending on the position of the steering wheel.
Rear cross-traffic H
Area on left of screen: Left-hand side of intersection.
Area in center of screen: Area directly behind the vehicle.
Area on right of screen: Right-hand side of intersection.
Settings on the Infotainment System screen
Tap the function key (5), to adjust the following settings:

Function key Action
Helligkeit Tap the function key - or + .

Function key Action
OR: Move the slider to set different brightness levels.
Kontrast Tap the function key - or + .
OR: Move the slider to set different contrast levels.
Farbe Tap the function key - or + .
OR: Move the slider to set different color levels.

Park Distance Control (PDC)

NOTICE
x Things like trailer draw bars, thin rods, fences, trees, and narrow painted vertical poles or posts may not be detected by the Park Distance Control and Optical Parking System sensors and could damage the vehicle.
x If you continue driving closer to an object that the Park Distance Control and Optical Parking Systems have already detected and reported, the object may disappear from the sensor range and may no longer be detected. This is especially true for low or high objects. The system will no longer sound warnings about these objects. Ignoring signals from the Park Distance Control system could result in serious damage to the vehicle.
x The sensors in the bumper can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report objects that might be within range of the PDC system
x To help make sure that the system works properly, always keep the sensors in the bumpers clean, free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for example, can prevent the Park Distance Control system from accurately detecting and reporting people and objects that may be within range of the system sensors.
x Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system.
Volkswagen recommends practicing with the Park Distance Control and the Optical Parking System in a location or parking space with no traffic in order to become familiar with the system and how it works.
Park Distance Control

Fig. 279 On the front and rear bumper: Park Distance Control system sensors.

Fig. 280 In the upper front center console: Different versions of the button for switching Park Distance Control on and off.

Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System ⇒ Automatic activation in the Infotainment System.
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is engaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an authorized Volkswagen Service Facility.
WARNING
Never rely completely on the PDC for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light in the button starts blinking, this means there is a malfunction in the Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Optical Parking System (OPS)

Fig. 281 OPS screen display: Small-screen display.

Fig. 282 OPS screen display: Full-screen display.
