The copying progress indicator can be displayed again.
x In the Audio menu, press the Extras function key ⇒ fig. 160.
x In the pop-up window, press the Import function key.
Checking hard disk capacity of Media center
x In the Audio menu, press the Extras function key ⇒ fig. 160.
x In the pop-up window, press the HDD capacity function key.
The HDD capacity menu shows how much hard drive memory space is used and how much is still available for storage.
x Press the

x Touch the Extras function key.
x In the pop-up window, press the Delete function key.
x Next search through the media center for files that you want to delete.
x List entries (tracks and folders) can be selected individually by pressing =.
x If you press the Select all function key, all list entries will be selected =.
x Press the Delete function key to delete all selected entries.
x Accept the confirmation dialog by pressing the Delete function key.
The delete process may take some time, depending on the number of files being deleted.
For copyright reasons, all files stored in the media library need to be deleted before the unit is passed on.
Using the voice control, you can also record the name of an artist, album or track stored in the media center after the corresponding voice command
External audio source connected via AUX-IN

External audio source connected via Bluetooth®

Open settings menu
x Connect the external audio source.
x Press the SETUP Infotainment button ⇒ fig. 133.
x Press the Media function key.
x Press the AUX volume function key.
x Move the slider ? to change the setting
Adjusting the output volume
If the sound from the external audio source is too quiet, if possible, increase the output volume on the audio source. If that is not sufficient, increase the AUX volume .
If the sound from the connected audio source is too loud or distorted, if possible, lower the output volume on the audio source. If that is not sufficient, decrease the AUX volume .
The AUX volume function key is only displayed if the playback volume for the connected audio source can be adjusted.

MEDIA-IN multimedia jack

WARNING
Driving on today’s roads demands the full attention of the driver at all times. Driver distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System, when using your mobile phone, or when operating the mobile phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your mobile phone, and the mobile phone controls only if road, traffic, and weather conditions permit and you will not be distracted from your driving.
x If you cannot use the Infotainment System, your mobile phone, or the mobile phone controls safely while driving, wait until later or find a safe spot where you can pull off the road and park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other warning sounds outside the vehicle.
Requirements and information

Fig. 163 MEDIA-IN multimedia jack.

Connectable data media Requirements for playback via the Infotainment System
– USB flash drives (USB sticks). – USB data media that do not need special drivers. – External USB flash drives. – External USB hard drives (HDD) - 1'', 1,8'', 2,5'' with maximum peak and continuous current 500 mA. – iPods® and iPhones® of various generations7.
– USB 2.0 enabled media. – Subclass 1 and 6 USB devices (note manufacturer's information). – Data media in the FAT or FAT32 file systems. – Limit of 4 partitions and 4000 files on the data medium. – Limit of 1000 files per directory.

Connecting and operating

Fig. 164 Selection menu of available media sources.

iPod® and iPhone®
When an iPod® or iPhone® is connected, a special iPod selection menu is displayed at the top
selection level similar to the Media center selection menu ⇒ page 266. There you can select list views specific to the iPod ( Playlists,  Artists,  Albums,  Songs,  Podcasts etc.).
The iPod selection menu is used as normal.
The music control of a connected iPod® or iPhone® is disabled.
The output volume of some iPods® or iPhones® can be adjusted to the volume of the other audio
sources ⇒ page 266.
Files cannot be imported from an iPod® or iPhone®. The setting for the Repeat feature cannot be changed.
Possible error messages after connecting an external data medium

Error message Cause Remedy
Device is not supported. Playback of the external data medium or communication via the adapter cable is not possible.
Check the adapter cable. Update software of the MEDIA-IN multimedia jack via the Volkswagen dealer. If possible, update the software of the external data medium.
Device not functional Communication malfunctioning. Verify the connection and functionality of external data medium.

Due to the large number of different types of data media and several iPod® and iPhone® generations, no guarantee can be made that all functions described can be executed without errors.
