2014 VOLKSWAGEN TOUAREG Owners Manual

SCAN
x Press the SIRIUS

Function key: Effect
Arrow Keys : Define the station selection for the arrow buttons

Media mode: Introduction

NOTICE
x When inserting and removing CDs and DVDs, always hold them at right angles to the front of the unit. Inserting or removing them at an angle to the DVD drive may lead to scratching.
x Inserting a second CD or DVD while a CD or DVD is inserted or is being ejected can destroy the DVD drive. Always wait until the data media is completely ejected.
NOTICE
Any foreign objects attached to a data medium and non-round data media can damage the DVD drive.
x Only clean 12-cm standard CDs or DVDs should be used!
– Do not attach stickers or other items to the data medium. Stickers may peel off and damage the drive.
– Do not insert 8-cm single CDs or non-round CDs (shaped CDs) or DVDs.
– Do not insert DVD-Plus, Dual Discs and Flip Discs, as these are thicker than standard CDs.
CDs can also be played in a DVD drive if they meet the requirements
Uneven road surfaces and strong vibrations may cause CDs and DVDs being played in the DVD drive to jump.
If the temperature inside a DVD drive is too high, loading and playback of CDs and DVDs is disabled.
Data media and file requirements

Data media Conditions for playback
Audio filesVideo files
I Audio CDs (up to 80 min). I Standard video DVD and DVD-compatible DVD audio. I CD-ROM-, CD-R-, CD-RW audio data CD up to max. 700 MB (Megabyte) in the data system ISO 9660 Level 1 and 2, Joliet or UDF 1.02, 1.5, 2.01, 2.5 I DVD+/-R/RW up to 4.7 GB and dual layer DVDs up to 8.5 GB in the Joliet file system (single-session only); UDF.

Inserting or removing data media

Fig. 152 Data media slots in glove compartment.

Navigation data (VCards etc.) can only be read via the Directory menu ⇒ page 299.
WARNING
Inserting data media when the vehicle is moving can distract you from the road and lead to accidents. Always keep the storage compartment closed when the vehicle is moving.
NOTICE
The memory card slot's locking mechanism and the memory card can be damaged by incorrect insertion of a memory card or by inserting a incompatible memory card!
x When inserting a card, make sure it is correctly positioned.
x Excessive pressure can destroy the locking mechanism in the memory card slot.
x Only use suitable memory cards
If you insert a number of different CDs and DVDs and receive the message Drive error every time, contact a qualified workshop.
Loading external DVD changer

To eject all data media from the DVD changer, press and hold the  button for longer than 3 seconds. The data media will be ejected one after the other.
NOTICE
Only insert or remove CDs or DVDs if the LEDs on the DVD slot are flashing green.
NOTICE
Before closing the side compartment in the luggage compartment, check whether the CD or DVD has been drawn in or removed completely. The DVD changer or the data medium might otherwise be damaged.
Playlists in the format cannot be played in the external DVD changer.
Open MEDIA main menu

Fig. 153 MEDIA main menu: Audio menu.

Fig. 154 MEDIA main menu: Video DVD menu.
