2014 VOLKSWAGEN TOUAREG Owners Manual

When real route guidance is started following route guidance in demo mode, the unit first has to reorient itself. Depending on the number of currently received satellites, this orientation may take some time. Vehicle movement can reduce the re-orientation time
If the vehicle is moved and the unit can determine its current location by GPS, any manually entered location will be overwritten with the current vehicle location.
Disable demo mode after use, otherwise you will be prompted to choose between virtual and normal route guidance each time you start route guidance.

MAP (map display)

Fig. 226 3D map display moved with vehicle position.

Browsing and centering map

Fig. 227 3D map view (map section moved).

Autozoom
If Autozoom is active, the map scale is adjusted automatically, depending on the route (small scale for driving on the highway and a large scale for driving in town).
x Press the

2D: Setting orientation of map
x Press the

Favorite destinations on the map
A favorite category can be specified for stored destinations. Favorite destinations can be displayed on the map with the orange favorite icon assigned to them (private T or business P).
The list of favorite destinations is called up from the Destination entry menu.
Points of interest on the map
Points of interest can be selected as a navigation destination.
Points of interest are divided into point of interest categories. These point of interest categories are assigned to blue point of interest icons (such as * hotel and , petrol station). A list of available point of interest categories can be called up from the Map settings menu. Map icons can be selected there for display.
Display detailed information on points of interest
x Press the symbol on the map briefly to display a window with further information.
Due to the map scale, there may be several entries behind one symbol on the map, in which case a list appears for selecting an entry.
x Select the required entry by pressing.
Function keys for further operation are displayed in the information window that appears.
x Selecting points of interest and favorite destinations from the map.
x TMC traffic reports on the map.
3D models on the map
An abstract 3D city model can be displayed in the 6 3D display type for some cities (such as Berlin).
In addition, special historical buildings and sights of interest are displayed as photo-realistic 3D models.
To display these, autozoom needs to be switched off in some cases and you have to zoom further into the map.
The display of 3D city models and 3D sights of interest is enabled and disabled in the map settings.
If no symbols or 3D models can be displayed due to the scale, turn the setting knob clockwise
⇒ fig. 133 (3) in order to zoom in on the map.
Map settings: selecting map symbols

Function key: effect on map
= 3D landmarks : Photo-realistic 3D models of special historical buildings and landmarks are displayed17.
= 3D city model : Buildings in cities are displayed as abstract 3D models17.
= P Important destinations (business) : Shows favorite destinations from the “business” category that were selected upon saving with P
= T Important destinations (private) : Shows favorite destinations from the “private” category that were selected upon saving with T
= > ... : Activated point of interest categories are displayed.
17 Only available for some cities.
