2014 VOLKSWAGEN TOUAREG Owners Manual

Waypoint navigation (Off-road mode)

Menu for waypoint navigation

Fig. 209 Navigation main menu.

Fig. 210 Waypoint navigation menu with opened waypoint tour.

Plotting a waypoint tour

Fig. 211 Plotting a waypoint tour.

Start whole tour : Will start the entire waypoint tour. In the menu that follows you will have to select how the start point of the waypoint tour should be reached.
On road : The start point for the route guidance will be reached using public roads as far as possible.
Off-road : The start point for route guidance will be reached in off-road mode and any available roads will not be used.
When route guidance starts, the system will switch to the map view.
An audible signal is given when the starting point of the waypoint tour has been reached.
During route guidance
Characteristics of the terrain are ignored during route guidance. A driving recommendation will be given about 55 yards (50 meters) before reaching a turning point. You should therefore drive slowly and follow recommendations for turning as far as possible!
Changes in the direction of travel will be given in relation to the current direction of travel, such as “Please travel in direction 9 o'clock!”.
The tendency of the direction of travel will be shown in the instrument cluster display using arrows.
Stopping route guidance
x Press the Infotainment button NAV in the map display to open the Waypoint navigation menu.
x Press the Stop function key.
Stopping waypoint navigation

Fig. 214 Waypoint navigation menu.

Route guidance

Route options

Fig. 215 Navigation main menu.

Fig. 216 Routing options setup menu.

Dynamic route: Switching dynamic route guidance on or off
With this option, traffic reports can be taken into account in the route calculation
x In the Route options menu, press the Dynamic route function key.
x In the pop-up window, press the On or Off function key to enable or disable dynamic route guidance.
Excluding or including types of route in the calculation
Press the  Highways , ! Ferries , Toll roads and " Tunnels function keys to activate or deactivate them. This makes it possible to define whether these types of route should be allowed for the route calculation or not.
If no reasonable route exists without the road type to be avoided, this road type will be nevertheless considered in the route calculation. For instance, if an island cannot be reached without using a ferry. For the calculation of very long routes, it is not possible to avoid highways .
Starting and stopping route guidance

Fig. 217 3D map display during route guidance.

Fig. 218 Navigation main menu during route guidance.
