Compass

Fig. 14 Compass zones.

x Select the compass zone according to the current location ⇒ fig. 14.
x Adjust and confirm compass zone (1-15).
Calibrating the compass
In order to calibrate the compass, you need a valid compass zone for the location and enough room to drive in a circle.
x Switch on the ignition.
x Select the Settings menu followed by the Compass and Calibration menu items.
x Confirm the A complete circle must be driven for calibration message by pressing the OK button on the multi-function steering wheel, and then drive in a complete circle at about 6 mph (10 km/h).
During calibration, CAL is shown in the instrument cluster display. The calibration is complete when the compass direction is displayed.
Service reminder display

Volkswagen Information System

▪ Display since start
▪ Display since refuel
▪ Display long-term
▪ Digital speed (digital speed display).
Navigation
Audio
▪ Source list
– DAB
– FM
– AM
– Radio memory
– HDD
– SD
– DVD
– USB
– Bluetooth
– TV tuner
– TV station memory
– External AV source
Telephone ⇒ page 277.
▪ Directory
▪ Dialed numbers
▪ Missed calls
▪ Received calls
Using the instrument cluster menus

Fig. 15 Right side of the multi-function steering wheel: Controls for the menus in the instrument cluster.

x To access a menu item, press the OK button.
Displaying a sub-menu
x Press the ' button on the multi-function steering wheel to access a submenu.
x Press the * or + buttons until the menu item you want is highlighted. The highlighted menu item is between the two horizontal lines.
x Highlight or confirm the selection with the OK button.
If you make no selection within about 10 seconds, the screen switches back to the previous menu.
Returning to the main menu
x Press the

Menu Function
Hybrid Shows the current energy flow for hybrid vehicles ⇒ page 460.
Tire pressure Display of current tire pressures in vehicles with direct Tire Pressure Monitoring System
Display since start
Display and storage of the driving and fuel consumption data compiled from the time the ignition is switched on to the time it is switched off. If the journey is continued within two hours after the ignition is switched off, the information from the new leg of the journey is counted as well. The memory is automatically cleared if the vehicle is not driven for more than two hours.
Display since refuel Display and storage of driving and fuel consumption data. The memory is automatically cleared when the vehicle is fueled again.
Display long-term Display and storage of the accumulated driving and fuel consumption data of any number of single trips up to a total driving time of either 19 hours and 59 minutes or 99 hours and 59 minutes, and up to a total distance of either 1,999.9 miles (1,999.9 km) or 9,999 miles (9,999 km), depending on the instrument cluster version. If one of the stored values is exceeded, then the memory is automatically cleared and starts again from 0.
Digital speed Switch the digital speed on or off. Shows the current vehicle speed in digital form.
Back The display switches back to the main menu.
Possible displays

Submenu Function
Travel time Driving time in hours (h) and minutes (min) corresponding to trip memories 1 and 2 (toggle).
Current consumption Current fuel consumption in miles per gallon (l/100 km) while driving. When units are set to miles, dashes appear instead of a number when the engine is running and the vehicle is standing still. When units are set to kilometers, the display shows liters consumed per hour when the engine is running and the vehicle is standing still.
Average consumption Average fuel consumption in miles per gallon (l/100 km) on trips per trip memories 1 and 2 (toggle) is displayed once the vehicle has been driven about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every 5 seconds.
Range Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank the way you are currently driving. Takes account of the current fuel consumption, among other things.
Distance Distance driven in miles (km) from the time the ignition was switched on.
Average speed The average speed is displayed after the ignition is switched on and the vehicle has been driven about 300 feet (100 m). Up to this point, dashes appear instead of a number. The value displayed is updated every 5 seconds.

Submenu Function
AdBlue
This display appears when the AdBlue fuel range falls to about 1500 miles (2400 km) and then provides current information as the range continues to diminish. You must refuel with AdBlue within this range
Switching between the displays
x Press the * or + button on the multi-function steering wheel.
Clearing a memory manually
x Select the memory that you want to clear.
x Press and hold the OK button on the multi-function steering wheel for about 2 seconds.
