Jump starting

WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety
precautions before working on the batteries or the electrical system ⇒ 12 Volt vehicle battery.
x Always make sure that the battery providing starting assistance (the booster battery) has the same voltage as the dead battery (12 V) and about the same amperage capacity (see battery label).
x Never jump-start a vehicle with a thawed or frozen battery. The battery can explode. A dead battery can freeze at temperatures around +32 °F (0 °C).
x A battery that is frozen or was frozen, but has since thawed, must be replaced.
x When the vehicle battery is jump-started, it gives off hydrogen gas, which is highly explosive! Always keep fire, sparks, open flame, and smoking materials far away from vehicle batteries. Never use a cellular telephone while connecting or disconnecting jumper cables.
x Jump-start batteries only in well-ventilated areas. Batteries give off highly explosive hydrogen gas during jump-starting.
x Always route the jumper cables so that they cannot get caught in any moving parts in the engine compartment.
x Never short out the battery terminals by connecting the positive terminal (+) and negative (–) terminals with each other.
x Never connect the negative cable from the other vehicle directly to the negative terminal of the dead battery, as this may cause the hydrogen gas given off by the dead battery to explode.
x Never attach the negative cable from the vehicle providing starting assistance to any part of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal parts of the vehicle.
x Always follow the instructions of the jumper cable manufacturer.
NOTICE
To help prevent extensive damage to the vehicle electrical system, read and heed the following:
x Connecting jumper cables improperly can cause a short circuit and do expensive damage to the vehicle's electrical system.
x Do not let the vehicles touch each other while the jumper cables are connected. If they do, electrical current may flow between the vehicles when the positive (+) terminals are connected, causing electrical system damage.

Positive and negative jump-starting terminals

Fig. 340 In the engine compartment: Positive jump start terminal + and negative jump start terminal -.

The procedure for attaching and for removing the jumper cables is described below. Perform each of the following steps only in the order in which it is described.
Before you begin
d Switch off the ignition in both vehicles.
d Open the hoods of both vehicles.
d Remove the cover from the positive terminal on your vehicle and, if necessary, the battery cover of the other vehicle.
Diagram A: Attaching jumper cables
Diagram A applies where the vehicle with the dead battery has jump start terminals (1) and is being
jump started by a vehicle whose battery is in the engine compartment (2) ⇒ .
1. Attach one end of the red jumper cable to the positive jump start terminal (+) of the vehicle with the dead battery (1).
2. Attach the other end of the red jumper cable to the positive terminal (+) of the booster battery (2).
3. Connect one end of the black jumper cable to a suitable ground connection (3) on the vehicle with the booster battery (2). A suitable ground connection is a solid metal part bolted directly to the engine block of the vehicle with the booster battery or this vehicle's engine block itself.
4. Attach the other end of the black jumper cable to the negative jump start terminal (-) of the vehicle with the dead battery (1).
Diagram B: Attaching jumper cables
Diagram B applies where the dead battery (1) is in the engine compartment of the vehicle being jump
started, and the vehicle providing starting assistance has jump start terminals (2) ⇒ .
1. Attach one end of the red jumper cable to the positive terminal (+) of the dead battery (1).
2. Attach the other end of the red jumper cable to the positive jump start terminal (+) of the vehicle providing starting assistance (2).
3. Attach one end of the black jumper cable to the negative jump start terminal (-) of the vehicle providing starting assistance (2).
4. Connect the other end of the black jumper cable to a suitable ground connection (3) on the vehicle with the dead battery (1). A suitable ground connection is a solid metal part bolted directly to the engine block of the vehicle with the dead battery or this vehicle's engine block itself.
Diagram C: Attaching jumper cables where both vehicles have jump start terminals
Diagram C applies where the vehicle with the dead battery has jump start terminals (1) and is being
jump started by a vehicle that also has jump start terminals (2) ⇒ .
1. Attach one end of the red jumper cable to the positive jump start terminal (+) of the vehicle with the dead battery (1).
2. Attach the other end of the red jumper cable to the positive jump start terminal (+) of the vehicle providing starting assistance (2).
3. Attach one end of the black jumper cable to the negative jump start terminal (-) of the vehicle providing starting assistance (2).
4. Attach the other end of the black jumper cable to the negative jump start terminal (-) of the vehicle with the dead battery (1).
Starting the engine
1. Start the engine of the vehicle with the good battery that is providing help and let it run at idle speed.

2. Turn the ignition of the vehicle with the dead battery. If the engine starts, wait 2 to 3 minutes until it
“runs smoothly” before removing the jumper cables as described below ⇒ . If the engine does not start within about 10 seconds, turn off the ignition and wait at least 1 minute; then try again.
Before removing the jumper cables
1. Switch off the headlights (if they are on).
2. In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps tit minimize voltage spikes when the cables are disconnected.
Removing the jumper cables
1. Before you remove the jumper cables, switch off the headlights (if they are on).
2. In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the jumper cables are disconnected.
3. With the engine running, remove the jumper cables in reverse order to the way they were connected. Specifically:
– Disconnect the black (–) cable from the vehicle with the dead battery.
– Disconnect the black (–) cable from the other vehicle (vehicle with the good battery).
– Disconnect the red (+) cable from the other vehicle (vehicle with the good battery).
– Disconnect the red (+) cable from the vehicle with the dead battery.
4. Turn off the heater fan and the rear winder defroster on the vehicle with the dead battery.
5. Snap the cap of the positive jump start terminal back on, reinstall covers, and close engine hoods.

WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety
precautions before working on the batteries or the electrical system ⇒ 12 Volt vehicle battery.
x Always wear proper eye protection. Never lean over the vehicle batteries.
x Attach the jumper cables in the correct order: first the positive cable, then the negative cable.
x Never connect the negative cable from the vehicle providing starting assistance to parts of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal parts of the vehicle.
x Specialized knowledge and tools are required to access the vehicle battery. For this reason, have an authorized Volkswagen dealer or an authorized Volkswagen Service Facility check the electrolyte level of the vehicle battery.
x Avoid electrostatic discharge in the vicinity of the vehicle battery. Sparks may cause the hydrogen gas escaping from the vehicle battery to ignite.
x Never jump start a vehicle with a battery that is damaged or frozen or that was frozen and has thawed. The battery can explode. Replace the battery instead.
x Always follow the instructions of the jumper cable manufacturer.
x Always make sure that the battery providing starting assistance has the same voltage as the dead battery (12 V) and about the same capacity (see battery label).
x Batteries give off explosive hydrogen gas. Always keep fire, sparks, open flame and smoking materials away from batteries.
x Never connect the negative cable from the other vehicle directly to the negative terminal of the dead battery. The hydrogen gas from the battery is explosive.
x Never short out the battery terminals by connecting the positive (+) and negative (–) terminals with each other.
NOTICE
Checking the electrolyte level
x The 12 Volt vehicle battery is located under the left front seat. Specialized knowledge and tools are required to access the vehicle battery. For this reason, have an authorized Volkswagen dealer or an authorized Volkswagen Service Facility check the electrolyte level of the vehicle battery.

Towing

WARNING
Towing a vehicle changes the way it handles and brakes. To help reduce the risk of an accident and serious personal injury, note the following:
x The driver of the vehicle that is being towed:
– Since the brake booster also does not work when the engine is stopped, you will need to press harder on the brake pedal to slow down or stop. Always be alert so as not to rear-end towing vehicle.
– Will have to use considerable more force to turn the steering wheel because the power steering is not working.
x The driver of the vehicle that is doing the towing:
– Must accelerate gradually and gently and avoid jerking movements.
– Must not brake hard or steer sharply.
– Must brake earlier and more gently than in normal driving.
WARNING
Never let the vehicle be towed unless its electrical system is working and the ignition is switched on. Otherwise, the steering column lock may engage, causing loss of control, a crash, and serious personal injuries.
NOTICE
x Be careful not to damage the paint when installing and removing the towing eye and the cover for the threaded hole behind the bumper.
x Unburned fuel can get into the catalytic converter during towing and damage it.
NOTICE
The vehicle may be damaged if it is towed with a tow rope or a tow bar.
x Never let the vehicle be towed with a tow rope or a tow bar unless it is absolutely necessary.
x If the vehicle breaks down, it can only be towed by a special tow truck.
Towing on a commercial tow truck
