2014 VOLKSWAGEN TOUAREG Owners Manual

Safety belt height adjusters for the front seats can be used to adjust the height of the shoulder portion of the safety belt so that it is positioned correctly:
x Press and hold the safety belt attachment ⇒ fig. 70.
x Pinch the safety belt attachment together as indicated by the arrows and slide the seat belt attachment to the desired position .
x Slide the belt and upper attachment up or down until the safety belt is positioned over the center of
the shoulder ⇒ Safety belt position.
x Release the safety belt attachment.
x Pull on the safety belt to make sure that the upper attachment is securely locked in place.
WARNING
Never adjust the height of the safety belt while driving.
Safety belt extender

Fig. 71 A safety belt extender properly attached to the factory-installed safety belt.

Fig. 72 Positioning of the safety belt extender.

If a safety belt is too short to correctly fit you or one of your passengers, even when the safety belt is pulled out all the way, you can use a safety belt extender.
Never use the safety belt extender for any other purpose – including the attachment of a child restraint.
The extender adds about 8 inches (20 cm) to the safety belt. Always remove the safety belt extender when it is not needed and stow it safely. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility if you believe you may need an extender.
Key to fig. 71:
(1) Vehicle safety belt buckle.
(2) Buckle tongue on the safety belt extender.
(3) Safety belt buckle on the safety belt extender.
(4) Safety belt buckle tongue on the factory-installed safety belt.
Key to fig. 72:
(A) Safety belt buckle on the safety belt extender.
(B) Distance between the safety belt buckle on the safety belt extender and the centerline of the person using the safety belt extender. The distance must be more than 6 inches (15 cm)!
(C) Centerline of the person using the safety belt extender.
Using a safety belt extender
x Adjust both the seat and the head restraint properly ⇒ Adjusting the seating position.
x Insert the buckle tongue on the safety belt extender ⇒ fig. 71 (2) into the vehicle belt buckle for the seat where the safety belt extender is being used (1).
x Fastening or unfastening the vehicle safety belt ⇒ Fastening and unfastening safety belts.
x Pull the belt to make sure that the tongues are securely locked in the buckles.
x Make sure that the safety belt is positioned properly ⇒ Safety belt position.
Properly using safety belt extenders:
x Use a safety belt extender only when the factory installed safety belt is too short when worn properly by a person in proper seating position.
x Only use one safety belt extender per seat and vehicle safety belt.
x Always remove the safety belt extender when it is not needed.
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the extender is not needed and being used with the safety belt. Otherwise, the airbag control module will receive an incorrect signal from the safety belt buckle and this will prevent the airbag from working properly for a person who is not using the safety belt. Leaving the extender attached to the safety belt buckle when the front seat is occupied and the safety belt is not being used will signal the airbag control unit during a collision that the front passenger seat is occupied and that the safety belt is being used. The electronic control unit for the airbag system will then receive incorrect information that will cause the safety belt pretensioner to deploy unnecessarily and the front passenger airbag to deploy later in collisions that would normally trigger the front airbag earlier in the collision to help protect an unrestrained front seat occupant. The airbag will not be able to provide enough protection for an occupant not wearing a safety belt.
x Only use the safety belt extender approved by Volkswagen for your vehicle.

WARNING
Improper use or positioning of a safety belt extender increases the risk of serious personal injury and death.
x A driver or passenger who is not properly restrained can be seriously injured by striking the interior of the passenger compartment or by the safety belt itself, which can be displaced from stronger parts of the body into sensitive areas like the abdomen.
x Safety belt extenders offer optimum protection only when they are properly used.
x Only use the extender when the belt is not long enough to be worn low and snug and the person is in the correct seating position. Remove and stow extender safely when not needed.
x Always make sure the safety belt tongue of the safety belt extender is securely inserted into the buckle for the seating position that belongs to the seat where the safety belt extender is being used. Attaching the safety belt to the wrong buckle will reduce safety belt effectiveness and can cause serious personal injury.
x Never use the safety belt extender if you can properly attach the safety belt without it. Using a safety belt extender when not needed can increase the risk of injury, especially in a collision.
x Never use a safety belt extender if the distance ⇒ fig. 72 (B) between the front edge of the safety belt extender buckle (A) and the centerline of the person using the safety belt extender (C) is less than about 6 inches (15 cm).
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the extender is not needed and being used with the safety belt. Otherwise the airbag control module will receive an incorrect signal from the safety belt buckle and this will prevent the airbag from working properly for a person who is not using the safety belt.
x Never use more than 1 extender with a safety belt. Using more than 1 extender can change the way the safety belt passes over the body and can cause serious injury.
x Never use the safety belt extender to secure a child restraint.
x Never use a safety belt extender on your Volkswagen that you obtained from another automobile manufacturer or from an automotive parts store.
x Never use the safety belt extender you got for your vehicle for any other vehicle, regardless of make, model, or model year.
NOTICE
x Leaving the extender attached to the safety belt buckle when the front seat is occupied and the safety belt is not being used will signal to the airbag control unit that the front passenger seat is occupied and that the safety belt is being used. The electronic control unit for the airbag system will then receive incorrect information that will
– cause the safety belt pretensioner to deploy unnecessarily in collisions and
– cause the front passenger airbag to deploy later in collisions in which the front airbag would otherwise be triggered earlier to help protect an unrestrained front seat passenger.
x A pretensioner that has deployed cannot be repaired. The entire safety belt must be replaced.
NOTICE
If the safety belt extender is left attached to the safety belt buckle, the safety belt warning system will sense that the safety belt for that seat is being used. The warning light will not come on and the warning chime will not sound even though the seat is occupied and the safety belt is not being used.

Safety belt retractor, pretensioner, load limiter

WARNING
Improper handling, care, servicing, and repair procedures can increase the risk of personal injury and death by preventing a belt pretensioner from activating when needed or by causing it to activate unexpectedly.
x The pretensioner can be activated only once. If a pretensioner has been activated, the safety belt must be replaced.
x Safety belt systems including the pretensioners cannot be repaired. Special procedures are required to remove, install, and dispose of this system.
x Never repair, adjust, or change pretensioners or any other part of the safety belt system yourself. We strongly recommend that you have any work on the safety belt system performed by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
They have the necessary technical information, training, and special equipment ⇒ Parts, accessories, repairs and modifications.
WARNING
Undeployed safety belt pretensioners and airbag modules contain explosive materials that can cause serious personal injuries if they are not properly handled when they or the vehicles they are installed in are scrapped.
x Never abandon vehicles or vehicle parts.
x Always scrap vehicles and vehicle parts, especially those containing undeployed airbag modules and undeployed safety belt pretensioners, at a licensed facility that has the knowledge and experience to properly dispose of the vehicle and its safety belt and airbag systems.
Undeployed airbag modules and safety belt pretensioners are classified as Perchlorate Material. Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all applicable legal requirements regarding handling and disposal of the vehicle or parts of its restraint system, including airbag modules and safety belts with pretensioners. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that you have them perform this service for you.

Lights

Adaptive Front Lighting System (AFS) malfunction. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
 Headlight range adjustment malfunction. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
 Parking lights switched on.
; One or more license plate lights burned out.
Replace the light bulbs that aren't working
⇒ page 656. If all light bulbs are OK, see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Fog lights switched on.
Z

electrodes can wear down and the gap between them will get wider. The HID lamp’s control unit then increases the voltage to keep the arc’s brightness constant. However, the commonly called “Xenon” bulbs will also ultimately burn out. Before they burn out, HID lamps can flicker. A message will then appear in the MFI. This is your reminder to see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to check the headlights.
Turn signal lever and high beam switch

Fig. 86 Turn signal lever and high beam switch.
