⇒ fig. 267 (5) in the cover ⇒ fig. 267 (3) to get to the jump-start terminals in the engine compartment
⇒ Removing and installing engine compartment cover.
Hybrid warning labels
There are additional warning labels that warns against touching hybrid system components. The warning labels are placed:
x on each high-voltage component for example in the engine compartment or underneath the
luggage compartment ⇒ fig. 265 A.
x in the engine compartment on the hood latch carrier B.
For procedures regarding stickers and labels ⇒ Technical data.
NOTICE
When refilling operating fluids, make sure not to confuse them. Otherwise serious malfunctions and engine damage can occur!
Removing and installing engine compartment cover

Fig. 267 Engine hood open: Engine compartment cover.

(5) Opening for jump starting.
(6) Warning label for high-voltage hybrid components.
(7) Engine compartment seal.
Engine compartment covers (1) and (3) must be removed in the following situations:
x Replacing light bulbs in the left headlight assembly.
Engine compartment covers (1) and (2) must be removed in the following situations:
x Replacing light bulbs in the right headlight assembly.
x Adding engine coolant to the low temperature coolant circuit ⇒ Checking coolant level and refilling coolant.
Removing engine compartment cover
When removing any part of the engine compartment cover, always pull carefully on the relevant
attachment points ⇒ .
x Open the engine hood

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious personal injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility to the front, sides, and rear.
x Maximum heating output and fast defrosting will only be possible after the engine has reached operating temperature. Wait until you have good visibility before driving off.
x Always make sure you know how to properly use the heating and ventilation systems as well as the rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, collisions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation a long period of time because no fresh air will come into the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor) switched on. Press the !

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal convenience settings and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Climatronic controls

Fig. 283 In the front center console: Climatronic controls.

Button/Knob More information. Front Climatronic controls .
) Air distribution to the windshield, the upper body, and the footwells. Push the button repeatedly until you get the setting you want; the selected setting is shown in the front Climatronic display.
2%34 Residual heat mode
!54/ Automatic temperature, fan, and air distribution control.
/&& Switch off: Press OFF button or adjust manually to 0. This switches Climatronic off entirely. /&& lights up in the front Climatronic display.
WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions and serious personal injury.
x Never switch off the fan for a long time and never use air recirculation a long period of time because no fresh air will enter the passenger compartment.
Operation via the Infotainment System

Fig. 284 Infotainment System: Front climate control settings.

Function key More information. Front Climatronic controls ⇒ fig. 284.
u Air distribution to the windshield and footwells.
 Heated steering wheel: The steering wheel is heated to about +77 °F (+25 °C) and held constant at about this temperature.
AUTO Automatic temperature, fan, and air distribution control. By tapping the function key repeatedly, you can select from the air conditioning profiles Low, Medium, and High in AUTO mode.
Fan switch Manual fan speed adjustment. Setting 0: fan and Climatronic switched off.

x Press the SETUP Infotainment button.
x Press the System feature key.
x Press the Units feature key.
x Select the desired unit.
Automatic window fog detection
Automatic window fog detection checks whether the windows are fogged up and if necessary automatically adjusts the air flow to the windshield and side windows or switches on the windshield heating. If the fan or the air conditioner !
