2014 VOLKSWAGEN TOUAREG Owners Manual

Lights up Possible cause Proper response
Engine cannot be started with starter button (Keyless Access).
Start the engine with the remote control vehicle key. Take the vehicle to an authorized Volkswagen dealer or an authorized Volkswagen Service Facility and have the system checked.
When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn on the emergency flashers, stop the engine, and use other warning devices to warn approaching traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Vehicle key positions in the ignition switch

Fig. 248 In the ignition switch: Vehicle key positions.

Ignition switched on, engine is started. Diesel engine is preheated. vehicle key cannot be removed from ignition switch.
On Hybrid vehicles depending on the environmental conditions and the current operating state of the vehicle, either the combustion engine will be started or pure electric departure will be enabled. This leaves the combustion engine off for the time being. In both cases, the vehicle 2%!$9 indicator will be displayed in the instrument cluster
To stop the engine, again turn the vehicle key to the left or right and release. vehicle key can then be removed from ignition switch.
To switch off the engine, turn the vehicle key either clockwise or counterclockwise and release. The vehicle key can be removed from the ignition switch when the transmission shift lever is in the (P) position.
If you use the wrong key
If an unauthorized remote control vehicle key has been inserted into the ignition switch, it can be removed as follows:
x The vehicle key cannot be removed from the ignition unless both the key and the selector lever have been moved to the correct position. Press the release button on the transmission selector lever, move the selector lever to the Park (P) position and release the button. The vehicle key can now be removed.
WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. The engine can be started and vehicle systems such as the power windows can be operated, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked with the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat build-up in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
x Never remove the key from the ignition switch while the vehicle is moving or rolling to a stop. The steering wheel will lock and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position other than Park (P) when the ignition is switched off can drain the vehicle battery.
The vehicle key can be removed from the ignition switch only when the transmission is in Park (P). You may have to press the release button on the transmission selector lever to put the lever into Park (P).

Starter button

Fig. 249 In the front center console: Starter button of the Keyless Access locking and starting system.

WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. Children or unauthorized persons may use it to lock the vehicle, start the engine, and operate vehicle systems such as the power windows, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked using the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat build-up in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
In vehicles with a diesel engine and Keyless Access, the engine start may be delayed if the engine has to be preheated.
If the ignition is switched on or the engine is running and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the engine and turn off the ignition before leaving and locking the vehicle from the outside.
Starting the engine

WARNING
“Starting fluids” can explode and can cause a “run-away” vehicle condition.
x Never use starting assist fluids.
NOTICE
x You can damage the starter or the engine if you try to start the engine when the vehicle is still moving, or if you try to restart the engine right after switching it off.
x Avoid high engine speeds, full throttle acceleration and heavy engine loads when the engine is cold.
x Do not try to start the engine by pushing or towing the vehicle. Unburned fuel can get into the catalytic converter and damage it. The steering column may also be locked.
Do not let your vehicle warm up while standing; instead, start driving right away after making sure that you have good visibility through all windows. This will help the engine reach operating temperature faster and keep down emissions.
If the battery in the remote control vehicle key is weak or dead, the engine cannot be started with the starter button. In this case, remove the starter button from the ignition switch and insert the remote control vehicle key into the ignition switch to start the vehicle.
Major consumers of electricity are temporarily switched off when the engine is being started.
After starting a cold engine, there may be increased operating noises for a few seconds. This is normal and harmless.
Stopping the engine

Emergency shut-off function
If the engine does not switch off when the vehicle key is turned in the ignition lock or when the starter button is pressed briefly, it must be switched off using the emergency switch-off function.

The steps should only be carried out in the specified order.
Vehicles without Keyless AccessVehicles with Keyless Access
1a. Selector lever in position D/S/R: turn the vehicle key clockwise or counterclockwise in the ignition lock twice within 1 second and then release the key.
Selector lever in position D/S/R: at a speed below 10 km/h (6 mph) and with the brake pedal depressed, press the starter button twice within a 1 second period and then
release ⇒ .
OR: hold the vehicle key in the required position for longer than 2 seconds. OR: press and hold the starter button for longer than 2 seconds.
1b. Selector lever in position N: turn the vehicle key in the ignition lock clockwise or counterclockwise and then let go of the key.
Selector lever in position N: irrespective of the speed at which the vehicle is travelling, press
the starter button once ⇒ .
2. The engine switches itself off.
WARNING
Never stop the engine before the vehicle has come to a complete stop. You can lose control of the vehicle, crash, and be seriously injured.
x The airbags and safety belt pretensioners will not work when the ignition is switched off.
x The brake booster does not work when the engine is not running. More brake pedal pressure will be needed to stop the vehicle.
x The power steering system does not work when the engine is not running, and you will need more force to steer the vehicle.
x When the key is removed from the ignition switch, the steering will lock and you will not be able to steer the vehicle.
NOTICE
If the vehicle has been driven hard for a long time, the engine could overheat when it is stopped. To reduce the risk of engine damage, let the engine idle in Neutral for about 2 minutes before you switch off the ignition.
If the ignition is switched on or the engine is running and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the engine and turn off the ignition before leaving and locking the vehicle from the outside.
The vehicle key can be removed from the ignition only when the transmission is in Park (P).
After the engine has been switched off, the radiator fan in the engine compartment may keep running for several minutes, or may start running after the vehicle has been parked for a while, even if the ignition is switched off and the vehicle key has been removed. The radiator fan shuts off automatically when the engine has cooled down enough.

Electronic immobilizer

Shifting
