Removing the wheel
x Review the checklist ⇒ Preparations for changing a wheel.
x Loosen the wheel bolts ⇒ Wheel bolts.
x Lift the vehicle ⇒ Lifting the vehicle with the vehicle jack.
x Unscrew the topmost loosened wheel bolt using the hexagonal socket in the screwdriver handle
⇒ fig. 317 place it on a clean surface.
x Screw the mounting pin in the vehicle tool kit into the empty hole by hand ⇒ fig. 325.
x Remove the remaining wheel bolts using the hexagonal socket in the screwdriver handle
⇒ fig. 317 and place them on a clean surface.
x Remove the wheel.
Mounting spare tire or collapsible spare tire
If the tire is a unidirectional tire, be sure to install it in the proper rolling direction ⇒ Unidirectional tires.
x Put the spare tire or collapsible spare tire into place on the vehicle.
x Screw in all wheel bolts clockwise and tighten them slightly using the hexagonal socket in the screwdriver handle.
x Unscrew the mounting pin and screw in the last wheel bolt.
x Lower the vehicle with the jack.
x Use the lug wrench to firmly tighten all wheel bolts (turn clockwise) ⇒ . Do not tighten them in sequence! Tighten any wheel bolt to begin, then tighten the wheel bolt diagonally opposite the first bolt, and so forth.
x Install the wheel bolt caps, center wheel hubcap, or wheel cover, if any ⇒ Wheel trim.
WARNING
Wheel bolts that are tightened or installed improperly can come loose, causing loss of vehicle control, a crash, and serious personal injury.
x Always keep wheel bolts and threads in the wheel hub clean and free of oil and grease. The wheel bolts must turn easily and must be tightened with the right torque.
x Use the hexagonal socket in the screwdriver handle only to turn the wheel bolts when they are loose, never to loosen them or tighten them firmly.
WARNING
Improper use of a collapsible spare tire can cause loss of vehicle control, a crash or other accident, and serious personal injury.
x Never use a collapsible spare tire if it is damaged or worn down to the wear indicators.
x Never drive faster than 50 mph (80 km/h) with a collapsible spare tire. Avoid full-throttle acceleration, heavy braking, and fast cornering!
x Never drive more than 125 miles (200 km) with a 16" collapsible spare wheel that is installed on the front axle (drive axle).
x Replace the collapsible spare with a normal wheel and tire as soon as possible. Collapsible spare tires are designed for brief use only.

After changing a wheel

Tire mobility set

WARNING
Using the tire mobility set on the side of the road can be dangerous. To help reduce the risk of serious personal injury:
x Always stop the vehicle as soon as it is safe to do so and move the vehicle a safe distance off the road where it is safe to use the tire mobility set.
x Make sure that the ground is level and firm.
x All passengers and especially children must stay a safe distance away from you while you are working and keep out of the area you are working in.
x Turn on the emergency flasher and set up another warning device about 25 yards (25 meters) behind the vehicle to warn approaching traffic.
x Use the tire mobility set only if you are familiar with the necessary steps. Otherwise, get expert assistance.
x Use the tire mobility set only in emergencies and only until you can get professional help.
x Immediately replace a tire repaired with the tire mobility set.
x Sealant is harmful and must immediately be removed in case of skin contact.
x Always store the tire mobility set out of reach of children.
x Never use a vehicle jack, even if the jack is approved for use with your vehicle.
x Always switch off the engine, engage the electronic parking brake, and shift the transmission into Park (P) to reduce the risk that the vehicle will move unexpectedly.
WARNING
Improper use of the tire mobility set can cause a temporary tire to fail and lead to loss of vehicle control and serious personal injuries.
x Always remember that a tire filled with sealant does not handle as well as an undamaged tire without sealant.
x Never drive faster than 50 mph (80 km/h) with a sealed tire.
x Never use the tire mobility set if the outside temperature is below –4 °F (–20 °C).
x Never drive with a tire that has cuts or punctures, especially when they are larger than 3/16 in (4 mm).
x Use the tire mobility set only for emergencies until you can get professional help.
x If the tire cannot be inflated to at least 36 psi (2.5 bar), do not drive the vehicle. Contact the nearest authorized Volkswagen dealer, authorized Volkswagen Service Facility, or other qualified workshop.
x If the tire inflation pressure drops below 26 psi (1.8 bar) after driving for 10 minutes, do not drive the vehicle any farther. Contact the nearest authorized Volkswagen dealer, authorized Volkswagen Service Facility, or other qualified workshop.
x Always replace a tire repaired with the tire mobility set immediately. Do not drive a tire that has been repaired with the tire mobility set longer or farther than is absolutely necessary.
x Avoid full throttle acceleration, hard, braking, and fast cornering.
x Drive at slow speed for 10 minutes. Then get out and check the air pressure and condition of the sealed tire.
Obey all legal requirements when disposing of used or expired sealant.
New tire inflation cylinders are available from authorized Volkswagen dealers and authorized Volkswagen Service Facilities.

Read the separate user manual of the manufacturer of the tire mobility set.
Contents of the tire mobility set

Fig. 326 Basic diagram: Contents of the tire mobility set.

Checklist
Carry out the following steps in the order listed before starting to inflate a tire ⇒ :
1. If you have a flat tire, move it as far away from traffic as possible. Park the vehicle on a flat, level surface at a safe spot.
2. Apply the electronic parking brake ⇒ Braking and parking.
3. Automatic transmission: Shift the transmission into Park (P) ⇒ Shifting.
4. Stop the engine and remove the key from the ignition switch ⇒ Starting and stopping the engine.
5. Have all passengers exit and go to a safe place, such as behind the guard rail.
6. Switch on emergency flashers and put up the warning triangle ⇒ In an emergency. Observe all legal requirements.
7. Check whether a repair with the tire mobility set is possible ⇒ Tire sealant must not be used:.
8. If towing a trailer: Unhitch the trailer from the vehicle and park the trailer properly.
9. If the luggage compartment is loaded: Remove the luggage.
10. Remove the tire mobility set from the luggage compartment.
11. Affix the label ⇒ fig. 326 (2) from the tire mobility set on the dashboard in the driver's field of vision.
12. The foreign object (screw or nail, for example) should not be removed from the tire!
WARNING
Disregarding the safety-related checklist may lead to accidents and serious injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
Sealing and inflating the tire

Fig. 327 In the engine compartment: Compressor connection terminals.

x Unscrew the valve core from the tire valve using the valve core wrench ⇒ fig. 326 (1) and place it on a clean surface.
x Vigorously shake the tire inflation cylinder ⇒ fig. 326 (10) a few times back and forth.
x Tightly screw the filling hose ⇒ fig. 326 (3) to the tire inflation bottle (turn clockwise). The foil on the seal is automatically pierced.
x Remove the sealing plug from the filling hose ⇒ fig. 326 (3) and slide the open end onto the tire valve.
x Hold the cylinder with the bottom pointing up and fill the entire contents of the tire inflation cylinder into the tire.
x Detach the empty tire inflation cylinder from the valve.
x Using the valve core wrench ⇒ fig. 326 (1) screw the valve core back into the tire valve.
Inflating the tire
x Screw the tire inflation hose ⇒ fig. 326 (5) of the air compressor tightly to the tire valve.
x Check whether the air release valve ⇒ fig. 326 (7) is screwed on tightly.
x Open the engine hood ⇒ Working in the engine compartment.
x Attach the cable clips ⇒ fig. 326 (9) only to the jump-start terminals in the engine compartment
⇒ fig. 327. The red clip on the compressor cable is connected to the positive (+) terminal; the black clip is connected to the negative terminal (—).
x Start the vehicle engine and let it run.
x Switch the air compressor on using the ON / OFF switch ⇒ fig. 326 (8),
x Let the air compressor run until a pressure of 36 – 44 psi (250 - 300 kPa) is reached ⇒ .
Maximum run time 8 minutes ⇒ .
x Switch off the air compressor.
x If an air pressure of 36 – 44 psi (250 - 300 kPa) cannot be reached, unscrew the tire inflation hose from the tire valve.
x Drive about 30 feet (10 meters) backwards or forwards so that the sealant can be distributed inside the tire.
x Connect the tire inflation hose of the air compressor again to the tire valve and repeat the inflation process.
x If the required tire pressure still cannot be reached, the tire is too badly damaged. The tire cannot
be sealed using the tire mobility set. Do not drive the vehicle. Get professional assistance ⇒ .
x Disconnect the air compressor and unscrew the tire inflation hose from the tire valve.
x If a tire pressure of 36 – 44 psi (250 – 300 kPa) is reached, continue driving right away and drive at a speed of not more than 50 mph (80 km/h).
x Check tire pressure after 10 minutes of driving ⇒ Check after 10 minutes of driving.
WARNING
The tire inflation hose and air compressor can get hot during inflation.
x Protect hands and skin from hot parts.
x Do not place the hot tire inflation hose or hot air compressor on flammable material.
x Let the equipment cool off almost completely before stowing it.
x If the tire cannot be inflated to at least 36 psi (250 kPa), the damage is too great to be repaired with the tire mobility set. The sealant is not able to seal the tire. Do not drive the vehicle. Get professional assistance.

NOTICE
Do not let the compressor run for more than 8 minutes to help prevent overheating and damage. Let the compressor cool down for a few minutes before switching it on again. Let it cool down almost completely before stowing it in the repair kit.
Check after 10 minutes of driving
