2012 Lexus CT200h Owner's Manual (in English)

407
3-3. Using the Bluetooth® audio system
3
Interior features
CT200h_OM_OM76067E_(EE)
Deleting a registered portable player
Select “Delete Audio” using .
Select the desired portable player to be deleted using
.
If the portable player to be deleted is paired as a Bluetooth
® phone,
the registration of the cellular phone can be deleted at the same
time.
When “Del Phone?” is displayed, select “Yes” or “No”
using . (Bluetooth
® phone P. 413)
The number of portable players that can be registered
Up to 2 portable players can be registered in the system.
STEP1
STEP2
STEP3

408
3-3. Using the Bluetooth® audio system
CT200h_OM_OM76067E_(EE)
Bluetooth® audio system setup
System setup items and operation procedures
To enter the menu of each setting, follow the steps below.
Press the off-hook switch (P. 419) and select “Setup”
using .
Select “System Setup” using .
Select one of the following items using :
Setting voice guidance volume
“Guidance Vol” (P. 436)
Displaying the Bluetooth
® device address and name
“Device Name” (P. 436)
Initializing the system
“Initialize” (P. 437)
STEP1
STEP2
STEP3

409
3
Interior features
CT200h_OM_OM76067E_(EE)
3-4. Using the hands-free phone system (for cellular phones)
Hands-free system for cellular phone
The hands-free system is a function that allows you to use your cellu-
lar phone without touching it.
This system supports Bluetooth
® cellular phones. Bluetooth® is a
wireless data system that allows the cellular phone to wirelessly con-
nect to the hands-free system and make/receive calls.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system
Hands-free system quick guide
Setting a cellular phone. (P. 420)
Adding an entry to the phonebook. (Up to 20 names can
be stored.) (P. 438)
Dialing by inputting a name. (P. 425)
Hands-free function list
TitlePage
Using the hands-free system
Using the hands-free phone system for
the first time
P. 4 2 0
STEP1
STEP2
STEP3

410
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
TitlePage
Making a phone call
Making a phone call
• Dialing by inputting a name
• Speed dialing
•Redial
• Call back
Receiving a phone call
• Answering the phone
• Refusing the call
Transferring a call
Using a call history memory
• Dialing
• Storing data in the phone book
• Deleting
P. 4 2 4
Setting a cellular phone
Functions and operation proceduresP. 4 2 9
Security and system setup
Security setting items and operation
procedure
System setup items and operation
procedure
P. 4 3 3

411
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
TitlePage
Using the phone book
Adding a new phone number
Changing the registered name in the
phone book
Listing the registered data
Setting speed dials
Deleting the registered data
Deleting speed dials
P. 4 3 8

412
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Conditions under which the system will not operate
If using a cellular phone that does not support Bluetooth®
If the cellular phone is switched off
If you are outside service range
If the cellular phone is not connected
If the cellular phone’s battery is low
If the cellular phone is behind the seat or in the glove box or console box
If metal is covering or touching the phone
Signal status
This display may not correspond exactly with the cellular phone itself.
When using the hands-free system
The audio system and voice guidance are muted when making a call.
If both parties speak at the same time, it may be difficult to hear.
If the incoming call volume is overly loud, an echo may be heard.
Try to face toward the microphone as much as possible when speaking.
In the following circumstances, it may be difficult to hear the other
party:
• When driving on unpaved roads
• When driving at high speeds
• When a window is open
• When the air conditioning is blowing directly on the microphone
• When the air conditioning is set to high

413
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
When transferring ownership of the vehicle
Be sure to initialize the system to prevent personal data from being improp-
erly accessed. (P. 437)
About Bluetooth®
Compatible models
Compatible with HFP (Hands Free Profile) Ver. 1.5 and OPP (Object Push
Profile) Ver. 1.1.
If your cellular phone does not support HFP, you cannot enter the Blue-
tooth
® phone. If your cellular phone supports OPP alone, you cannot use the
Bluetooth® phone.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.

414
3-4. Using the hands-free phone system (for cellular phones)
CT200h_OM_OM76067E_(EE)
Certification for the hands-free system
