2012 Lexus CT200h Owner's Manual (in English)

471
3-7. Other interior features
3
Interior features
CT200h_OM_OM76067E_(EE)
Removing the luggage cover
Retract the cover and release
both ends, then lift it out.
Luggage cover (if equipped)
Pull out the luggage cover
and secure it to the hook
brackets.

472
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
Stowing the luggage cover
Remove the side deck boards
and open the center auxiliary
box.
Adjust the cover so that the
information label is facing up.
Fold the rear edge of the cover
over, replace the side deck
boards and close the center aux-
iliary box.
STEP1
STEP2
STEP3

473
3-7. Other interior features
3
Interior features
CT200h_OM_OM76067E_(EE)
CAUTION
When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their stowed positions.
Deck boards
If the deck boards are removed, return them to their original positions before
driving. In the event of sudden braking, an accident may occur due to an
occupant being struck by the deck boards or the items stored in the auxiliary
box.
Caution for the luggage cover
Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

474
3-7. Other interior features
CT200h_OM_OM76067E_(EE)

4Maintenance and care
475
CT200h_OM_OM76067E_(EE)
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 476
Cleaning and protecting
the vehicle interior ......... 482
4-2. Maintenance
Maintenance
requirements .................. 485
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions..................... 488
Hood ................................ 492
Positioning a floor jack .... 494
Engine compartment ........ 496
12-volt battery.................. 508
Tires ................................. 515
Tire inflation pressure ...... 519
Wheels ............................. 521
Air conditioning filter ...... 523
Electronic key battery ...... 527
Checking and replacing
fuses ............................... 532
Light bulbs ....................... 546

476
CT200h_OM_OM76067E_(EE)
4-1. Maintenance and care
Cleaning and protecting the vehicle exterior
Automatic car washes
Fold the mirrors and remove the antenna before washing the vehicle.
Start washing from the front of the vehicle. Make sure to re-install the
antenna and extend the mirrors before driving.
Brushes used in automatic car washes may scratch the vehicle surface
and harm your vehicle’s paint.
Roof antenna, rear spoiler may not be washable in some automatic car
washes. There may also be an increased risk of damage to vehicle.
Perform the following to protect the vehicle and maintain it in prime
condition:
Working from top to bottom, liberally apply water to the
vehicle body, wheel wells and underside of the vehicle to
remove any dirt and dust.
Wash the vehicle body using a sponge or soft cloth, such as
a chamois.
For hard-to-remove marks, use car wash soap and rinse
thoroughly with water.
Wipe away any water.
Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the
vehicle body is cool.

477
4-1. Maintenance and care
4
Maintenance and care
CT200h_OM_OM76067E_(EE)
High pressure car washes
Do not allow the nozzles of the car wash to come within close proximity
of the windows.
Before using the car wash, check that the fuel filler door on your vehicle
is closed properly.
When using a car wash
If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. Place the key in a posi-
tion 2 m (6 ft.) or more separate from the vehicle while the vehicle is being
washed. (Take care to ensure that the key is not stolen.)
Aluminum wheels
Remove any dirt immediately by using a neutral detergent. Do not use
hard brushes or abrasive cleaners. Do not use strong or harsh chemical
cleaners.
Use the same mild detergent and wax as used on the paint.
Do not use detergent on the wheels when they are hot, for example after
driving for long distance in the hot weather.
Wash detergent from the wheels immediately after use.
Bumpers
Do not scrub with abrasive cleaners.

478
4-1. Maintenance and care
CT200h_OM_OM76067E_(EE)
Front side windows water-repellent coating
The following precautions can extend the effectiveness of the water-
repellent coating.
• Remove any dirt, etc. from the front side windows regularly.
• Do not allow dirt and dust to accumulate on the windows for a long
period.
Clean the windows with a soft, damp cloth as soon as possible.
• Do not use wax or glass cleaners that contain abrasives when cleaning
the windows.
• Do not use any metallic objects to remove condensation build up.
When the water-repellent performance has become insufficient, the coat-
ing can be repaired. Contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
Outside rear view mirror rain-clearing coating
Observe the following precautions in order to retain the rain-clearing prop-
erties of the mirrors:
Clean the mirrors using a car shampoo or glass cleaner that does not con-
tain silicone or an abrasive compound, and rinse thoroughly with water.
Allow the mirrors to be exposed to direct sunlight for 1 to 2 days.
