2012 Lexus CT200h Owner's Manual (in English)

360
3-2. Using the audio system
CT200h_OM_OM76067E_(EE)
Control panel
Type A
Displaying
text message
Song selection Shuffle
playback
Powe Volume
Repeat playPlayback/pause
PlaybackGo back
iPod menu/
Song selection

361
3-2. Using the audio system
3
Interior features
CT200h_OM_OM76067E_(EE)
Type B
Displaying text mes-
Song selection Shuffle
playback
Powe Volume
Repeat play
Playback/pause
Play back
Go back
iPod menu/
Song selection

362
3-2. Using the audio system
CT200h_OM_OM76067E_(EE)
Selecting a play mode
Press to select iPod menu mode.
Turning changes the play mode in the following
order:
“PLAYLISTS” “ARTISTS”  “ALBUMS” 
“SONGS” 
“PODCASTS” “GENRES”  “COMPOSERS” 
“AUDIOBOOKS”
Press to select the desired play mode.
STEP1
STEP2
STEP3

363
3-2. Using the audio system
3
Interior features
CT200h_OM_OM76067E_(EE)Play mode list
Play modeFirst
selectionSecond
selectionThird
selectionFourth
selection
“PLAY-
LISTS”Playlists
selectSongs select--
“ARTISTS”Artists selectAlbums
selectSongs select-
“ALBUMS”Albums
selectSongs select--
“SONGS”Songs select---
“POD-
CASTS”Albums
selectSongs select--
“GENRES”Genre selectArtists selectAlbums
selectSongs select
“COMPOS-
ERS”Composers
selectAlbums
selectSongs select-
“AUDIO-
BOOKS”Songs select---

364
3-2. Using the audio system
CT200h_OM_OM76067E_(EE)Selecting a list
Turn to display the first selection list.
Press to select the desired item.
Pressing the knob changes to the second selection list.
Repeat the same procedure to select the desired song name.
To return to the previous selection list, select “GO BACK” or
press (type A) or (type B).
Selecting songs
Turn or press “”or “” on to select the
desired song.
Playing and pausing songs
To play or pause a song, press
(type A) or (type B).
Fast-forwarding and rewinding songs
To fast-forward or rewind, press and hold “”or “” on
until you hear a beep.
STEP1
STEP2
STEP3

365
3-2. Using the audio system
3
Interior features
CT200h_OM_OM76067E_(EE)
Shuffle playback
Playing songs from one playlist or album in random order
Press .
To cancel, press again.
Playing songs from all the playlists or albums in random order
Press and hold until you hear a beep.
To cancel, press again.
Repeat play
Press .
To cancel, press again.
Switching the display
Press .
Each time the button is pressed, the display changes in the following
order: Elapsed time  Album title  Track title  Artist name
Adjusting sound quality and volume balance
Press to enter iPod menu mode.
Pressing changes sound modes. (P. 381)
STEP1
STEP2

366
3-2. Using the audio system
CT200h_OM_OM76067E_(EE)
Portable audio device holder (if equipped)
P. 3 3 3
About iPod
Apple is not responsible for the operation of this device or its compli-
ance with safety and regulatory standards.
iPod is a trademark of Apple, Inc., registered in the U.S. and other coun-
tries.
iPod functions
When an iPod is connected and the audio source is changed to iPod
mode, the iPod will resume play from the same point in which it was last
used.
Depending on the iPod that is connected to the system, certain functions
may not be available. Disconnecting the device and reconnecting it once
again may resolve some malfunctions.
iPod problems
To resolve most problems encountered when using your iPod, disconnect
your iPod from the vehicle iPod connection and reset it.
For instructions on how to reset your iPod, refer to your iPod Owner’s Man-
ual.
Display
P. 3 4 6
Error messages
“ERROR”: This indicates a problem in the iPod or its connection.
“NO MUSIC”:This indicates that there is no music data in the iPod.
“EMPTY”: This indicates that an empty playlist is selected.
“UPDATE”: This indicates that the version of the iPod is not compatible.
Upgrade your iPod software to the latest version.

367
3-2. Using the audio system
3
Interior features
CT200h_OM_OM76067E_(EE)
