2012 Lexus CT200h Owner's Manual (in English)

2When driving
185
CT200h_OM_OM76067E_(EE)
2-1. Driving procedures
Driving the vehicle........... 186
Power (ignition) switch .... 198
EV drive mode ................. 204
Hybrid transmission ......... 207
Turn signal lever .............. 216
Parking brake ................... 217
Horn ................................. 218
2-2. Instrument cluster
Gauges and meters ........... 219
Indicators and warning
lights .............................. 225
Multi-information
display ............................ 2292-3. Operating the lights and
windshield wipers
Headlight switch .............. 235
Fog light switch ............... 239
Windshield wipers and
washer ............................ 241
Rear window wiper and
washer ............................ 247
Headlight cleaner switch . 249
2-4. Using other driving
systems
Cruise control .................. 250
Dynamic radar cruise
control ............................ 255
Lexus parking
assist-sensor ................... 273
Rear view monitor
system ............................ 282
Driving assist systems ..... 291
Hill-start assist control ..... 296
PCS (Pre-Crash Safety
system)........................... 299
2-5. Driving information
Cargo and luggage ........... 308
Winter driving tips ............ 311
Trailer towing .................. 315

186
CT200h_OM_OM76067E_(EE)
2-1. Driving procedures
Driving the vehicle
The following procedures should be observed to ensure safe driving:
Starting the hybrid system
P. 198
Driving
With the brake pedal depressed, shift the shift position to
D.
(P. 207)
Check that the shift position indicator shows D.
Release the parking brake. (P. 217)
Gradually release the brake pedal and gently depress the
accelerator pedal to accelerate the vehicle.
Stopping
With the shift position in D, depress the brake pedal.
If necessary, set the parking brake.
When the vehicle will be stopped for an extended period of
time, shift the shift position to P. (
P. 207)
Parking the vehicle
Stop the vehicle completely.
Set the parking brake. (P. 217)
Shift the shift position to P. (P. 2 1 0 )
Check that the shift position indicator shows P. (P. 207)
Press the “POWER” switch to stop the hybrid system.
Slowly release the brake pedal.
Lock the door, making sure that you have the electronic
key on your person.
STEP1
STEP2
STEP3
STEP1
STEP2
STEP1
STEP2
STEP3
STEP4
STEP5
STEP6

187
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
Starting off on a uphill
Firmly set the parking brake with the brake pedal
depressed, and then shift the shift position to D.
Release the brake pedal and gently depress the accelerator
pedal.
Release the parking brake.
When starting off on a uphill
The hill-start assist control is available. (P. 296)
Driving in the rain
Drive carefully when it is raining, because visibility will be reduced, the
windows may become fogged-up, and the road will be slippery.
Drive carefully when it starts to rain, because the road surface will be
especially slippery.
Refrain from high speeds when driving on an expressway in the rain,
because there may be a layer of water between the tires and the road sur-
face, preventing the steering and brakes from operating properly.
STEP1
STEP2
STEP3

188
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
Breaking in your new Lexus
To extend the life of the vehicle, observing the following precautions is rec-
ommended:
For the first 300 km (200 miles):
Avoid sudden stops.
For the first 2000 km (1200 miles):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive at a constant speed for extended periods.
Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the avail-
ability of the correct fuel. (P. 6 5 3 )
For efficient use
Shift the shift position to D when driving.
In the N position, the gasoline engine operates but electricity cannot be
generated. The hybrid battery (traction battery) will discharge, requiring
unnecessary engine power to recharge.
Drive your vehicle smoothly.
Avoid abrupt acceleration and deceleration. Gradual acceleration and
deceleration will make more effective use of the electric motor (traction
motor) without having to use gasoline engine power.
Avoid repeated acceleration.
Repeated acceleration consumes hybrid battery (traction battery) power,
resulting in poor acceleration. Battery power can be restored by driving
with the accelerator pedal slightly released.
Shift the shift position to P when parking.
In the N position, the hybrid battery (traction battery) does not recharge.
Leaving the shift position in the N position for an extended period of
time may discharge the hybrid battery (traction battery). The vehicle
cannot run if the hybrid battery (traction battery) is discharged.

189
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
CAUTION
When starting the vehicle
Always keep your foot on the brake pedal while stopped with the hybrid
system operating. This prevents the vehicle from creeping.
When driving the vehicle
Do not drive if you are unfamiliar with the location of the brake and accel-
erator pedals to avoid depressing the wrong pedal.
• Accidentally depressing the accelerator pedal instead of the brake
pedal will result in sudden acceleration that may lead to an accident
that could result in death or serious injury.
• When backing up, you may twist your body around, leading to a diffi-
culty in operating the pedals. Make sure to operate the pedals properly.
• Make sure to keep a correct driving posture even when moving the
vehicle only slightly. This allows you to depress the brake and acceler-
ator pedals properly.
• Depress the brake pedal using your right foot. Depressing the brake
pedal using your left foot may delay response in an emergency, result-
ing in an accident.
The driver should pay extra attention to pedestrians when the vehicle is
powered only by the electric motor (traction motor). Because there is no
engine noise, the pedestrians may misjudge the vehicle’s movement.
Do not drive the vehicle over or stop the vehicle near flammable materi-
als.
The exhaust system and exhaust gases can be extremely hot. These hot
parts may cause a fire if there is any flammable material nearby.
Do not let the vehicle roll backward while a forward driving position is
selected, or roll forward while the shift position is in R.
Doing so may result in an accident or damage to the vehicle.

190
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
CAUTION
If the smell of exhaust is noticed inside the vehicle, open the windows and
check that the back door is closed. Large amounts of exhaust in the vehi-
cle can cause driver drowsiness and an accident, resulting in death or a
serious health hazard. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional
immediately.
Do not shift the shift position to P while the vehicle is moving.
Doing so can damage the transmission and may result in a loss of vehicle
control.
Do not shift the shift position to R while the vehicle is moving forward.
Doing so can damage the transmission and may result in a loss of vehicle
control.
Do not shift the shift position to D while the vehicle is moving backward.
Doing so can damage the transmission and may result in a loss of vehicle
control.
Moving the shift position to N while the vehicle is moving will disengage
the hybrid system. Engine braking is not available with the hybrid system
disengaged.
During normal driving, do not turn off the hybrid system. Turning the
hybrid system off while driving will not cause loss of steering or braking
control, but the power assist to these systems will be lost. This will make
it more difficult to steer and brake, so you should pull over and stop the
vehicle as soon as it is safe to do so. However, in the event of an emer-
gency, such as if it becomes impossible to stop the vehicle in the normal
way: P. 6 4 6
Use engine braking (shift position B instead of shift position D) to main-
tain a safe speed when driving down a steep hill.
Using the brakes continuously may cause the brakes to overheat and lose
effectiveness. (P. 207)

191
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
CAUTION
Do not adjust the positions of the steering wheel, the seat, or the inside or
outside rear view mirrors while driving.
Doing so may result in a loss of vehicle control that can cause accidents,
resulting in death or serious injury.
Always check that all passengers’ arms, heads or other parts of their body
are not outside the vehicle, as this may result in death or serious injury.
When driving on slippery road surfaces
Sudden braking, acceleration and steering may cause tire slippage and
reduce your ability to control the vehicle, resulting in an accident.
Abrupt changes from shift position D to B and rapid changes in the engine
speed could cause the vehicle to skid, resulting in an accident.
After driving through a puddle, lightly depress the brake pedal to make
sure that the brakes are functioning properly. Wet brake pads may prevent
the brakes from functioning properly. If the brakes on only one side are
wet and not functioning properly, steering control may be affected, result-
ing in an accident.
When changing the shift position
Be careful not to change the shift position with the accelerator pedal
depressed.
Changing the shift position to any positions other than P or N may cause the
vehicle to accelerate abruptly, causing an accident and resulting in death or
serious injury.
After changing the shift position, make sure to confirm the current shift
position displayed on the shift position indicator inside the meter.

192
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
CAUTION
If you hear a squealing or scraping noise (brake pad wear indicators)
Have any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional check and replace the brake pads as soon as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads
and/or those of the brake discs are exceeded.
When the vehicle is stopped
Do not depress the accelerator pedal unnecessarily.
If the vehicle is in any shift position other than P or N, the vehicle may
accelerate suddenly and unexpectedly, causing an accident.
Do not leave the vehicle with the hybrid system on for a long time.
If such a situation cannot be avoided, park the vehicle in an open space
and check that exhaust fumes do not enter the vehicle interior.
In order to prevent accidents due to the vehicle rolling away, always keep
depressing the brake pedal while the “READY” indicator is on. Apply the
parking brake as necessary.
If the vehicle is stopped on an incline, in order to prevent accidents caused
by the vehicle rolling forward or backward, always depress the brake
pedal and securely apply the parking brake as needed.
Avoid revving or racing the engine.
Running the engine at high speed while the vehicle is stopped may cause
the exhaust system to overheat, which could result in a fire if combustible
material is nearby.
