2012 Lexus CT200h Owner's Manual (in English)

455
3-6. Using the storage features
3
Interior features
CT200h_OM_OM76067E_(EE)
Auxiliary box (type E)
If an object has fallen down the back of
the lid, the fallen object can be retrieved
by removing the cover inside the auxil-
iary box.
Remove the mat.
Remove the cover using a flathead screw-
driver protected with tape etc.
STEP1
STEP2
Auxiliary boxes

456
3-6. Using the storage features
CT200h_OM_OM76067E_(EE)
CAUTION
Caution while driving (type A and E)
Keep the auxiliary boxes closed when not in use. In the event of sudden
braking, an accident may occur due to an occupant being struck by an open
auxiliary box or the items stored inside.
Items unsuitable for storing (type A)
Do not store items heavier than 200 g (0.44 lb.).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.
NOTICE
Auxiliary box (type E)
Do not leave items in the auxiliary box or on the dashboard for long periods
of time when the vehicle is in the sun.
The inside of the auxiliary box and the dashboard will become extremely
hot compared to other parts of the vehicle, and the items could be deformed
or damaged.
Auxiliary boxes

457
3
Interior features
CT200h_OM_OM76067E_(EE)
3-7. Other interior features
Sun visors
To set the visor in the for-
ward position, flip it down.
To set the visor in the side
position, flip down,
unhook, and swing it to the
side.

458
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge
Do not leave the vanity lights on for extended periods while the hybrid sys-
tem is off.
Slide the cover to open.
The light turns on when the
cover is opened.

459
3-7. Other interior features
3
Interior features
CT200h_OM_OM76067E_(EE)
Clock
The clock is displayed when
The “POWER” switch is in ACCESSORY or ON mode.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without navigation system
The clock can be adjusted by pressing the buttons.
Adjusts the hours
Adjusts the minutes
Rounds to the nearest
hour
*
*
:e.g.1:00 to 1:291:00
1:30 to 1:592:00

460
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
Power outlet
The power outlet can be used for 12 V accessories that run on less than
10 A.
Center console
Press down and release the
lid.
Open the cover.
STEP1
STEP2

461
3-7. Other interior features
3
Interior features
CT200h_OM_OM76067E_(EE)
Auxiliary box (if equipped)
Press the button.
Open the cover.
STEP1
STEP2

462
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
The power outlet can be used when
The “POWER” switch is in ACCESSORY or ON mode.
Connecting power cables from the power outlet (auxiliary box)
NOTICE
To avoid damaging the power outlet
Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.
To prevent blown fuse
Do not use an accessory that uses more than 12 V 10 A.
To prevent 12-volt battery discharge
Do not use the power outlet longer than necessary when the hybrid system is
off.
The gap in the lid allows power cables to
be passed through even when the lid is
closed.
