2012 Lexus CT200h Owner's Manual (in English)

209
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
Selecting a driving mode
The following modes can be selected to suit driving condi-
tions:
Normal mode
Eco drive mode
Suitable for improving the
fuel economy, because the
torque corresponding to the
accelerator pedal depression
amount can be generated
more smoothly than it is in
normal conditions and the
operation of the air condi-
tioning system (heating/cool-
ing) will be minimized.
When the driving mode
select switch is turned left,
the “ECO MODE” indicator
comes on in the instrument
cluster.
Press the switch to change
the driving mode to normal
mode.
Sport mode
Use when high levels of
response and feeling are
desirable, such as when driv-
ing in mountainous regions
or when overtaking.
When the driving mode
select switch is turned right,
the “SPORT MODE” indica-
tor comes on in the instru-
ment cluster

210
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
P position switch
When shifting the shift position to P
Fully stop the vehicle and set
the parking brake, and then
press the P position switch.
When the shift position is
changed to P, the switch indica-
tor comes on.
Check that the P position is illu-
minated on the shift position
indicator.
Shifting the shift position from P to other positions
While depressing the brake pedal firmly, operate the shift
lever. If the shift lever is operated without depressing the
brake pedal, the buzzer will sound and the shifting operation
will be disabled.
When selecting the shift position, make sure that the shift
position has been changed to the desired position by checking
the shift position indicator provided on the instrument cluster.
The shift position cannot be changed from P to B directly.

211
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
Operation of the air conditioning system in Eco drive mode (without navi-
gation system)
Eco drive mode controls the heating/ cooling operations and fan speed of
the air conditioning system to enhance fuel efficiency. (P. 326) To
improve air conditioning performance, adjust the fan speed or turn off Eco
drive mode.
Operation of the air conditioning system in Eco drive mode (with navigation
system)
Eco drive mode controls the heating/cooling operations and fan speed of the
air conditioning system to enhance fuel efficiency. To improve air condi-
tioning performance, adjust the fan speed or turn off Eco drive mode. (Refer
to the “Navigation System Owner’s Manual”.)
For the shift positions
When the “POWER” switch is off, the shift position cannot be changed.
When the “POWER” switch is in ON mode (the hybrid system is not
operating), the shift position can only be changed to N. The shift position
will be changed to N even if the shift lever is shifted to D or R and held
in that position.
When the “READY” indicator is on, the shift position can be changed
from P to D, N or R.
When the “READY” indicator is flashing, the shift position cannot be
changed from P to another position even if the shift lever is operated.
Wait until the “READY” indicator changes from a flashing to a solid
light, and then operate the shift lever again.
The shift position can only be changed to B directly from D.

212
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
In addition, if an attempt is made to change the shift position by moving the
shift lever in any of the following situations, the buzzer will sound and the
shifting operation will be disabled or the shift position will automatically
change to N. When this happens, select an appropriate shift position.
Situations where the shifting operation will be disabled:
• When an attempt is made to change the shift position from P to another
position by moving the shift lever without depressing the brake pedal.
• When an attempt is made to change the shift position from P or N to B
by moving the shift lever.
Situations where the shift position will automatically change to N:
• When the P position switch is pressed while the vehicle is running.
*1
• When an attempt is made to select the R position by moving the shift
lever when the vehicle is moving forward.
*2
• When an attempt is made to select the D position by moving the shift
lever when the vehicle is moving in reverse.
*3
• When an attempt is made to change the shift position from R to B by
moving the shift lever.
*1: Shift position may be changed to P when driving at extremely low
speeds.
*2: Shift position may be changed to R when driving at low speeds.
*3: Shift position may be changed to D when driving at low speeds.
Reverse warning buzzer
When shifting into R, a buzzer will sound to inform the driver that the shift
position is in R.

213
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
About engine braking
When shift position B is selected, releasing the accelerator pedal will apply
engine braking.
• When the vehicle is driven at high speeds, compared to ordinary gaso-
line-fueled vehicles, the engine braking deceleration is felt less than that
of other vehicles.
• The vehicle can be accelerated even when shift position B is selected.
If the vehicle is driven continuously in the B position, fuel efficiency will
become low. Usually, select the D position.
When driving with cruise control or dynamic radar cruise control activated
Even if switching the driving mode to sport mode with the intent of enabling
engine braking, engine braking will not activate because cruise control or
dynamic radar cruise control will not be canceled.
Automatically P position selection function
When the shift position is in a position other than P, pressing the “POWER”
switch with the vehicle stopped completely will cause the shift position to
change to P automatically, and then the “POWER” switch will turn off.
If the shift position cannot be shifted from P
There is a possibility that the 12-volt battery is discharged. Check the 12-
volt battery in this situation. (P. 633)
Sport mode automatic deactivation
Sport mode is automatically deactivated if the “POWER” switch is turned
off after driving in sport mode.
After recharging/reconnecting the 12-volt battery
P. 5 1 1
Customization
Settings (e.g. Reverse warning buzzer) can be changed.
(Customizable features P. 667)

214
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
CAUTION
When driving on slippery road surfaces
Do not accelerate or shift the shift position suddenly.
Sudden changes in engine braking may cause the vehicle to spin or skid,
resulting in an accident.
For the shift lever
Do not remove the shift lever knob or use anything but a genuine Lexus
shift lever knob. Also, do not hang anything on the shift lever.
Doing so could prevent the shift lever from returning to position, causing
unexpected accidents to occur when the vehicle is in motion.
P position switch
Do not press the P position switch while the vehicle is moving.
If the P position switch is pressed when driving at very low speeds (for
example, directly before stopping the vehicle), the vehicle may stop sud-
denly when the shift position switches to P, which could lead to an accident.

215
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
NOTICE
Hybrid battery (traction battery) charge
If the shift position is in N, the hybrid battery (traction battery) will not be
charged. To help prevent the battery from discharging, avoid leaving the N
position selected for an extended period of time.
Situations where P position control system malfunctions are possible
If any of the following situations occurs, P position control system malfunc-
tions are possible.
Immediately stop the vehicle in a safe place on level ground, apply the park-
ing brake, and then contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
When the “P LOCK MALFUNCTION” warning message appears on the
multi-information display. (P. 580)
When the shift position indicator remains off.
Notes regarding shift lever and P position switch operation
Avoid repeatedly operating the shift lever and P position switch in quick
succession.
The system protection function may activate and it will not be temporarily
possible to shift the shift position other than P. If this happens, please wait
for a while before attempting to change the shift position again.

216
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
Turn signal lever
Turn signals can be operated when
The “POWER” switch is in ON mode.
If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
The turn signal lever can be used to show the following intention
of the driver:
Right turn
Left turn
Lane change to the right
(push and hold the lever
partway)
The right hand signals will
flash until you release the
lever.
Lane change to the left
(push and hold the lever
partway)
The left hand signals will
flash until you release the
lever.
