2006 MERCEDES-BENZ C55AMG Owner's Manual

248 Controls in detail
Loading
Roof rack*
Mount the roof rack only between the
fastening points (see arrows).
Secure the roof rack according to
manufacturer’s instructions for
installation.
Warning!G
Only use roof racks approved by
Mercedes-Benz for your vehicle model to
avoid damage to the vehicle.
Follow the manufacturer’s installation in-
structions. Otherwise, an improperly at-
tached roof rack system or its load could
become detached from the vehicle.
Do not exceed the maximum roof load of
220 lb (100 kg).
Take into consideration that when the roof
rack is loaded, the handling characteristics
are different from those when operating the
vehicles without the roof rack loaded.
!
Load the roof rack in such a way that
the vehicle cannot be damaged while
driving.
Make sure

you can fully raise the tilt/sliding
sunroof.

you can fully open the trunk.

249 Controls in detail
Loading
Ski sack (Canada only)
1Handle
2Cover
3ArmrestUnfolding and loading
Fold armrest3 down (arrow).
Pull handle1 and swing cover2
down.4Hook and loop fastener
Unfasten hook and loop fastener4.
Pull ski sack into passenger compart-
ment and unfold.
!
Do not sit on or lean your body weight
against the armrest when it is folded
down, as you could otherwise damage
it.


250 Controls in detail
Loading
5Button
Open trunk lid.
Press button5.
The flap opens downward.
From trunk, slide skis into ski sack.6Strap
Tighten strap6 by pulling at the loose
end (arrow) until the skis in the ski sack
are tightly secured.
Warning!G
The ski sack is designed for up to four pairs
of skis. Do not load the ski sack with other
objects.
Always fasten the ski sack securely. In an
accident, an unfastened ski sack can cause
injury to vehicle occupants.


251 Controls in detail
Loading
7Hook
8Eye
Connect hook7 to eye8.
Tighten strap by pulling at the loose
end (arrow).Unloading and folding
Loosen the straps.
Disconnect hook7 from eye8.
Unload skis.
Close flap in trunk.
Fold and flatten ski sack lengthwise.
Place folded ski sack inside recess of
backrest.
Fasten hook and loop fastener.
Close ski sack compartment cover.Removing the ski sack
You can remove the ski sack for cleaning
or drying.
1Button
2Ski sack frame
3Flap
Open trunk lid.
Press button1.
The flap3 opens downward.
Press button1 firmly until ski sack
frame2 is released.
Pull ski sack frame2 with ski sack
out.

252 Controls in detail
Loading
Installing the ski sack
Install the ski sack in the reverse order.
Push ski sack frame2 with ski sack
inward until the ski sack frame snaps
into place.
Close flap3.
Close trunk lid.
Split rear bench seat
To expand the cargo area, you can fold
down the left and right rear seat backrests.
The two sections can be folded down
separately.Folding the backrest forward
The release handle1 is located in the
trunk.
Pull release handle1.
Fully retract and fold rearward head
restraints (
page 108).
Warning!G
Never drive vehicle with trunk open while
the ski sack is removed. Deadly carbon
monoxide (CO) gases may enter vehicle in-
terior, resulting in unconsciousness and
death.
i
To prevent unauthorized persons from
accessing the trunk, always close the
flap.
Warning!G
When expanding the luggage area, always
fold the seat cushions fully forward.
Unless you are transporting cargo, the
backrests must remain properly locked in
the upright position.
In an accident, during hard braking or
sudden maneuvers, loose items will be
thrown around inside the vehicle, and cause
injury to vehicle occupants unless the items
are securely fastened in the vehicle.
Always use the cargo tie down rings*
(
page 255).

253 Controls in detail
Loading
Pull release handle2.
Fold seat cushion3 forward.
Fold backrest4 forward.Returning the backrest to original
positionFold backrest2 rearward until it
engages.
Fold seat cushion1 rearward until it
locks into position.If the backrest is not locked into position,
a red indicator3 will be visible.
Check for secure locking by pushing
and pulling on the backrest.
!
Always release the seat cushion and
fold it forward before folding the seat
backrests forward. Otherwise, the
backrest covering may be damaged.

254 Controls in detail
Loading
Loading instructions
The total load weight including vehicle
occupants and luggage/cargo should not
exceed the load limit or vehicle capacity
weight indicated on the corresponding
placard located on the driver’s door
B-pillar.
The handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible.
The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.
Warning!G
If a red indicator is visible with the backrest
up, then the backrest is not properly locked
into position.
Always lock backrest in its upright position
when rear seat bench is occupied, cargo is
being carried in the trunk, or the extended
cargo compartment is not in use. Check for
secure locking by pushing and pulling on the
backrest.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.
To help avoid personal injury during a
collision or sudden maneuver, exercise care
when transporting cargo.
i
To prevent unauthorized persons from
access to the trunk, always lock
backrest in its upright position.
Warning!G
Always fasten items being carried as secure-
ly as possible using cargo tie-down rings and
fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.

255 Controls in detail
Loading
Cargo tie-down rings*
The four cargo tie-down rings are located
in the trunk.
Cargo tie-down rings
Carefully secure cargo by applying
even load on all rings with rope
sufficient strength to hold down the
cargo.
Always follow loading instructions
(
page 254).
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.
i
The trunk is the preferred place to carry
objects.
The enlarged cargo area should only be
used for items which do not fit in the
trunk alone.
