2006 MERCEDES-BENZ C55AMG Owner's Manual

96 Controls in detail
Locking and unlocking
Factory settingGlobal unlocking
Press buttonŒ.

All turn signal lamps flash once.

An acoustic signal sounds once
(if equipped and feature activated).

The locking knobs in the doors
move up.

The anti-theft alarm system* is dis-
armed.
The vehicle will lock again automatically
and reactivate the anti-theft alarm
system* within approximately 40 seconds
of unlocking if:

neither a door nor the trunk is opened

the SmartKey is not inserted in the
starter switch

the central locking switch is not
activatedGlobal locking
Press button‹.

All turn signal lamps flash three
times.

An acoustic signal sounds three
times (if equipped and feature acti-
vated).

The locking knobs in the doors
move down.

The anti-theft alarm system* is
armed.
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressingŒ only unlocks the driver’s
door and the fuel filler flap.
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds.
Battery check lamp5 (
page 94)
flashes twice.
i
Your vehicle may be equipped with an
acoustic lock and unlock confirmation
signal feature. If your vehicle is
equipped with this feature and the fea-
ture is activated, an acoustic signal will
sound when the vehicle is locked or un-
locked using the SmartKey.
To determine whether or not your vehi-
cle is equipped with this feature, con-
tact an authorized Mercedes-Benz
Center. If equipped and you wish to ac-
tivate or deactivate the feature, or ad-
just its signal volume, also contact an
authorized Mercedes-Benz Center.

97 Controls in detail
Locking and unlocking
The SmartKey will then function as follows:
Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.

All turn signal lamps flash once.

An acoustic signal sounds once
(if equipped and feature activated).

The locking knob in the driver’s
door moves up.

The anti-theft alarm system* is dis-
armed.
Global unlocking
Press buttonΠtwice.

All turn signal lamps flash once.

An acoustic signal sounds once
(if equipped and feature activated).

The locking knobs in the doors
move up.

The anti-theft alarm system* is dis-
armed.Global locking
Press button‹.

All turn signal lamps flash three
times.

An acoustic signal sounds three
times (if equipped and feature acti-
vated).

The locking knobs in the doors
move down.

The anti-theft alarm system* is
armed.
Restoring to factory setting
Press and hold buttonsŒ and‹
simultaneously for about 6 seconds un-
til battery check lamp5 (
page 94)
flashes twice.
The SmartKey is set to factory setting
again.
!
If you can no longer lock or unlock the
vehicle with the SmartKey, then either
the batteries in the SmartKey are dis-
charged, the SmartKey is malfunction-
ing or the vehicle battery is drained.

Try second SmartKey.

Check the batteries in the
SmartKey (
page 98) and replace
them if necessary (
page 393).

Use the mechanical key to unlock
the driver’s door (
page 386) and
the trunk (
page 387).

Use the mechanical key to lock the
driver’s door (
page 387) and the
trunk (
page 103).

Have the vehicle battery and the
battery connections checked
(
page 411).
If the SmartKey is malfunctioning,
contact an authorized Mercedes-Benz
Center.

98 Controls in detail
Locking and unlocking
Checking the batteries
Press button‹ orŒ.
Battery check lamp5 (
page 94)
comes on briefly to indicate that the
SmartKey batteries are in order.Unlocking and opening the trunk
You can unlock and open the trunk
separately.
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
Press buttonŠ until trunk lid
unlocks and begins to open.Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:
Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.
Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.
If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
i
If battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 393).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
i
If the batteries are checked within
signal range of the vehicle, pressing
the‹ orŒ button will lock or
unlock the vehicle accordingly.
!
The trunk lid swings open upwards
automatically. Always make sure there
is sufficient overhead clearance.
i
If the trunk does not open, it is still
locked separately (
page 103).

99 Controls in detail
Locking and unlocking
Opening the doors from the inside
You can open a locked door from the
inside. Open door only when conditions
are safe to do so.
1Locking knob
2Inside door handleFront doors
Pull on door handle2 on the
respective front door to open door.
If door was locked, locking knob1 will
move up.
Rear doors
Pull up locking knob1 on the
respective rear door to unlock door.
Pull on door handle2 on the
respective rear door to open door.
Opening the trunk
Opening the trunk from the outside
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
The handle is located above the rear
license plate recess.
1Handle
i
If the vehicle has previously been
locked with the SmartKey, opening a
door from the inside will trigger the
anti-theft alarm system*.
To cancel the alarm, do one of the
following:

Press buttonŒ or‹ on the
SmartKey.

Insert the SmartKey in the starter
switch.

100 Controls in detail
Locking and unlocking
The vehicle must be unlocked.
Pull on handle1.
The trunk opens.
The trunk can also be opened using
buttonŠ on the SmartKey or from its
inside in an emergency, see “Trunk emer-
gency release” (
page 102).Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
The remote trunk opening switch is locat-
ed on the driver’s door.
1Remote trunk opening switch with indi-
cator lamp
Press switch1 until the trunk begins
to open.
The indicator lamp in the switch
remains lit as long as the trunk is open.
The trunk can also be opened using
buttonŠ on the SmartKey or from its
inside in an emergency, see “Trunk emer-
gency release” (
page 102).
!
The trunk lid swings open upwards
automatically. Always make sure there
is sufficient overhead clearance.
i
If the trunk does not open, it is still
locked separately (
page 103).
!
The trunk lid swings open upwards
automatically. Always make sure there
is sufficient overhead clearance.
i
If the trunk does not open, it is still
locked separately (
page 103).

101 Controls in detail
Locking and unlocking
Closing the trunk
1Handle
2Handles
Lower trunk lid by pulling firmly on
handle1 or handles2.
Close trunk lid with hands placed flat
on trunk lid.
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
opening when closing the trunk. Be espe-
cially careful when small children are
around.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.
Warning!G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.
i
Do not place the SmartKey in the open
trunk. You may lock yourself out.
i
If the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it. The turn signals will
flash three times to confirm locking.

102 Controls in detail
Locking and unlocking
Trunk emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
The emergency release button is located
on the inside of the trunk lid.
1Emergency release button
Briefly press emergency release
button1.
The trunk unlocks and the trunk lid
opens.Illumination of the emergency release
button:

The button flashes 30 minutes after
opening the trunk.

The button flashes 60 minutes after
closing the trunk.
!
The trunk lid swings open upwards
automatically.
i
The emergency release button unlocks
and opens the trunk while the vehicle is
standing still or in motion.
i
The emergency release button does
not open the trunk lid if the vehicle
battery is discharged or disconnected.
i
If the vehicle has previously been
locked with the SmartKey, opening the
trunk from the inside using the emer-
gency release button will trigger the
anti-theft alarm system*.
To cancel the alarm, do one of the
following:

Press buttonŒ or‹ on the
SmartKey.

Insert the SmartKey in the starter
switch.

103 Controls in detail
Locking and unlocking
Valet locking
The lock is located next to the handle
above the rear license plate recess.
1Neutral position
2Locked
Close the trunk (page 101).
Pull the mechanical key out of the
SmartKey (
page 386).
Insert the mechanical key in the trunk
lid lock.
Turn the mechanical key clockwise to
position2 and remove the mechani-
cal key in that position to lock the
trunk.
The trunk remains locked even when the
vehicle is centrally unlocked.
Insert the mechanical key in the trunk
lid lock.
Turn the mechanical key counterclock-
wise to neutral position1 and remove
the mechanical key in that position to
unlock the trunk.
You can now open the trunk
(
page 99).
Automatic central locking
The doors and the trunk automatically lock
when the ignition is switched on and the
wheels are turning at vehicle speeds of
approximately 9 mph (15 km/h) or more.
You can open a locked door from the
inside. Open door only when conditions
are safe to do so.
You can deactivate the automatic locking
mode using the control system, see “Set
automatic locking” (
page 147).
i
To deny any unauthorized person ac-
cess to the trunk, lock it separately
with the mechanical key. Leave only
the SmartKey less its mechanical key
with the vehicle.
i
You can only cancel the separate trunk
locking mode by means of the
mechanical key.
i
The doors unlock automatically after an
accident if the force of the impact
exceeds a preset threshold.
To prevent the vehicle door locks from
locking, deactivate the automatic
central locking when the vehicle

is pushed or towed

is on a test stand
