2006 MERCEDES-BENZ C55AMG Owner's Manual

136 Controls in detail
Control system
Resetting all settings
You can reset all the functions of all
submenus to the factory settings.
Press the reset button in the
instrument cluster (
page 122) for
approximately 3 seconds.
The request to press the reset button
once more to confirm appears in the
multifunction display.
Press the reset button once more.
The functions of all the submenus will
reset to factory settings.Submenus in the Settings menu
Press buttonj.
The collection of the submenus
appears in the multifunction display.
Press buttonç.
The selection marker moves to the next
submenu.
The submenus are arranged by hierarchy.
Scroll down with buttonç, scroll up
with buttonæ.
With the selection marker on the desired
submenu, use the buttonj to access
the individual functions within that sub-
menu. Once within the submenu, you can
use the button j to move to the next
function or the button k t o m o v e t o t h e
previous function within that submenu.
The settings themselves are made with
buttonæ orç.
i
The settings you have changed will not
be reset unless you confirm the action
by pressing the reset button a second
time. After approximately 5 seconds,
the
Settings menu reappears in the
multifunction display.
For safety reasons, the following
function are not reset while driving:

the Hdlamp mode function in the
Lighting submenu

137 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus. Detailed instructions on making individual
settings can be found on the following
pages.
Instrument clusterTime/DateLightingVehicleConvenience
Select speedometer
display modeTime synchronization with head
unit*Set daytime running lamp
mode (USA only)Set automatic lock-
ingActivate easy-entry/exit
feature
Select languageSet time (hours)Set locator lightingSet parking position for
exterior rear view mirror
Select display (speed
display or outside
temperature) for status
indicatorSet time (minutes)Set night security
illumination
Select automatic time change
(Daylight Saving Time (DST)
summer/Standard time winter)Set interior lighting de-
layed shut-off
Set date (month)
Set date (day)
Set date (year)

138 Controls in detail
Control system
Instrument cluster submenu
Access the
Instr.Cl. submenu via the
Settings menu. Use the Instr.Cl.
submenu to change the instrument cluster
display settings.
The following functions are available:Select speedometer display mode
Move the selection marker with
buttonæ orç to the
Instr.Cl.
submenu.
Press buttonj ork repeatedly
until the message
Disp.Unit
Speed/odo
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to set
speedometer unit to
Km orMiles.Select language
Move the selection marker with
buttonæ orç to the
Instr.Cl.
submenu.
Press buttonj ork repeatedly
until the message
Language appears in
the multifunction display.
The selection marker is on the current
setting.
FunctionPage
Select speedometer display
mode138
Select language138
Select display (speed display or
outside temperature) for status
indicator139

139 Controls in detail
Control system
Press buttonæ orç to select
the language to be used for the
multifunction display messages.
Available languages:

German (Deutsch)

English (English)

French (francais)

Italian (italiano)

Spanish (Español)

Dutch (Nederlands)

Danish (Dansk)

Swedish (Svenska)

Portuguese (Português)

Turkish (Türkçe)Select display (digital speedometer or
outside temperature) for status
indicator
Move the selection marker with
buttonæ orç to the
Instr.Cl.
submenu.
Press buttonj ork repeatedly
until the message
Status line
display
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
the desired setting.
The selected display is then shown
continuously in the lower display.
The other display now appears in the
menu of the standard display:

Digital speedometer
or

Outside temperature

140 Controls in detail
Control system
Time/Date submenu
Access the
Time/Date submenu via the
Settings menu. Use the Time/Date
submenu to change the instrument cluster
display settings.
The following functions are available:Time synchronization with head unit*
This function can only be seen on vehicles
with COMAND* and navigation module*.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Time synchro.
w/Head Unit
appears in the multifunc-
tion display.
The selection marker is on the current
setting.
Press buttonæ orç to select
the desired setting.Set the time (hours)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Time Hours appears
in the multifunction display.
FunctionPage
Time synchronization with
head unit*140
Set time (hours)140
Set time (minutes)141
Select automatic time change
(Daylight Saving Time (DST)
summer/Standard time winter)142
Set date (month)142
Set date (day)143
Set date (year)143
i
Vehicles with COMAND*:
For information on setting the time,
refer to the separate COMAND
operating instructions.

141 Controls in detail
Control system
The selection marker is on the hour
setting.
Press buttonæ orç to set the
hour.Set the time (minutes)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Time Minutes
appears in the multifunction display.The selection marker is on the minute
setting.
Press buttonæ orç to set the
minutes.
i
Vehicles with COMAND*:
For information on setting the time,
refer to the separate COMAND
operating instructions.

142 Controls in detail
Control system
Select automatic time change (Daylight
Saving Time (DST) summer/Standard
time winter)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Change-over
Summer / Winter time
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to select if
the changeover between summer and
winter time should be automatic or
manual.
Set the date (month)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set MM appears
in the multifunction display.
The selection marker is on the month
setting.
Press buttonæ orç to set the
month.
i
Vehicles with COMAND*:
For information on setting the date,
refer to the separate COMAND
operating instructions.

143 Controls in detail
Control system
Set the date (day)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set day
appears in the multifunction display.The selection marker is on the day
setting.
Press buttonæ orç to set the
day.Set the date (year)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set YY appears
in the multifunction display.
i
Vehicles with COMAND*:
For information on setting the date,
refer to the separate COMAND
operating instructions.
i
Vehicles with COMAND*:
For information on setting the date,
refer to the separate COMAND
operating instructions.
