2006 MERCEDES-BENZ C55AMG Owner's Manual

128 Controls in detail
Control system
MenusThis is what you will see when you scroll
through the menus.The table on the next page provides an
overview of the individual menus.

129 Controls in detail
Control system
Menus, submenus and functions
Menu1Menu2Menu3Menu4Menu5Menu6Menu7
Standard
displayAUDIONAV*Vehicle status
message memorySettingsTrip computerTelephone*
(page 130)(page 131)(page 134)(page 134)(page 135)(page 150)(page 152)
Commands/submenus
Run Flat
Indicator*
(Canada only)Select radio
stationShow route guid-
ance instructions,
current direction
traveledCall up vehicle mal-
function, warning and
system status messag-
es stored in memory
1
1The vehicle status message memory menu is only displayed if there is a message stored.
Reset to
factory
settingsFuel consumption
statistics after
startLoad phone
book
Digital speed-
ometer or out-
side temperatureSelect satellite
radio station*
(USA only)Instrument
cluster sub-
menuFuel consumption
statistics since
the last resetSearch for
name in
phone book
Call up main-
tenance service
displayOperate
CD player* Time/Date
submenuDistance to emp-
ty
Check engine oil
levelLighting
submenu
Vehicle
submenu
Convenience
submenu

130 Controls in detail
Control system
Standard display menu
In the standard display, the main odometer
and the trip odometer are shown in the
multifunction display.
1Trip odometer
2Main odometer
If another display is shown instead of the
standard display:
Press buttonè orÿ repeatedly
until you see the standard display.
Press buttonk orj to select
the functions in the standard display
menu.The following functions are available:Display digital speedometer or outside
temperature
Press buttonj ork repeatedly
until you see the digital speedometer.
The current vehicle speed is shown in
the multifunction display.
1Digital speedometerFunctionPage
Run Flat Indicator* (Canada
only)318
Call up digital speedometer or
outside temperature130
Call up maintenance service
display338
Check engine oil level299
i
Select either the display of the digital
speedometer or the outside tempera-
ture indicator (
page 139).

131 Controls in detail
Control system
AUDIO menu
The functions in the
Audio menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
Audio off appears in the
multifunction display.
The following functions are available:Select radio station
Turn on the radio (page 200).
Vehicles with COMAND*:
Refer to separate operating
instructions.
Press buttonè orÿ repeatedly
until the currently tuned station
appears in the multifunction display.
1Waveband setting
2Station frequency
Press buttonk orj repeatedly
until the desired station is found.
FunctionPage
Select radio station131
Select satellite radio station*
(USA only)132
Operate CD player*132
i
You can only store new stations using
the corresponding feature on the radio
(
page 208).
Vehicles with COMAND*:
Refer to separate operating
instructions.
You can also operate the radio in the
usual manner.

132 Controls in detail
Control system
Select satellite radio station*
(USA only)
The satellite radio is treated as a radio
application.
Select satellite radio with the
corresponding soft key (SAT) in the
radio menu.
1SAT mode and preset number
2Channel name or number
Press buttonk orj repeatedly
until the desired channel is found.Operate the CD player*
Selecting CD track
Turn on the radio and select CD or
CD changer* (
page 219).
Vehicles with COMAND*:
Refer to separate operating
instructions.
Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the
multifunction display.
1Current CD (for CD changer*)
2Current track
Press buttonk orj repeatedly
until the desired track is selected.
i
For more information on satellite radio
operation, see “Introduction to satellite
radio* (USA only)” (
page 209).
Vehicles with COMAND*:
Refer to separate operating
instructions.
i
The COMAND* system and the CD
changer* can play audio CDs as well as
CDs with MP3 files.
i
To select a CD from the CD changer*
magazine, press a number on the audio
system or the COMAND* system key
pad located in the center dashboard.

133 Controls in detail
Control system
For more information on CD operation, see
“CD mode” (
page 214) and for the CD
changer*, see (
page 218).
Selecting CD MP3-track (vehicles with
COMAND* and/or CD changer*)
Turn on the radio and select the
CD changer* (
page 219) or turn on
COMAND* and select CD or
CD changer*.
Vehicles with COMAND*:
Refer to separate operating
instructions.
Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the
multifunction display.
1MP3 mode (vehicles with COMAND*)
2Current track
Press buttonk orj repeatedly
until the desired track is selected.For more information on MP3, see “MP3
notes” (
page 216), and for operating,
see “MP3 playback” (
page 217).i
A CD with MP3 files insert in the CD
changer* is handled by the
audio/COMAND* system like an audio
CD. Information contained on the CD
with MP3 files will not shown in the
multifunction display or in the au-
dio/COMAND* display.
i
Level of information displayed will vary
depending on the information con-
tained on the CD with MP3 files insert
in the single CD player of the
COMAND* system.
To select a CD from the CD changer*
magazine, press a number on the audio
system or the COMAND* system key
pad located in the center dashboard.

134 Controls in detail
Control system
NAV* menu
The
NAV menu contains the functions
needed to operate your navigation system.
Press buttonè orÿ repeatedly
until the message
NAV appears in the
multifunction display.

If COMAND* is switched off, the mes-
sage
NAV off appears in the multifunc-
tion display.

With COMAND* switched on but route
guidance not activated, the direction of
travel and, if available, the name of the
street currently traveled on appear in
the multifunction display.

With COMAND* switched on and route
guidance activated, the direction of
travel and maneuver instructions ap-
pear in the multifunction display.
Please refer to the COMAND* manual for
instructions on how to activate the route
guidance system*.
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the
system. Such messages appear in the mul-
tifunction display and are based on condi-
tions or system status the vehicle’s system
has recorded.
The vehicle status message memory menu
only appears if there are any messages
stored.
Press buttonè orÿ repeatedly
until the vehicle status message
memory appears in the multifunction
display.
If the vehicle status message memory
menu does not appear, then there are
no messages stored.
Warning!G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and
safety checks performed on the vehicle and
by bringing the vehicle to an authorized
Mercedes-Benz Center to address the mal-
function and warning messages
(
page 358).

135 Controls in detail
Control system
Vehicle status messages have been
recorded
If conditions have occurred causing status
messages to be recorded, the number of
messages appears in the multifunction
display:
1Number of messages
Press buttonk orj.
The stored messages will now be
displayed in the order in which they
have occurred. For malfunction and
warning messages, see “Vehicle status
messages in the multifunction display”
(
page 358).Should the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display when the SmartKey in the
starter switch is turned to position0 or
removed from the starter switch.
Settings menu
In the
Settings menu there are two
functions:

The function Reset to factory
settings
, with which you can reset all
the settings to the original factory
settings.

A collection of submenus with which
you can make individual settings for
your vehicle.
Press buttonè orÿ repeatedly
until the
Settings menu appears in the
multifunction display.
i
The vehicle status message memory
will be cleared when you turn the
SmartKey in the starter switch to
position1 or2. You will then only see
high-priority messages in the multi-
function display (
page 358).
