Page 217 of 473

216 Controls in detail
Audio system
Tips on handling CDs
Handle CDs carefully to prevent
interference during playback.
Avoid scratches, fingerprints and dust
on the CDs.
Do not write on CDs or apply any labels
or other material to them.
Clean CDs from time to time with a
commercially available cleaning cloth.
Never wipe the CD in a circular motion;
instead, wipe it in a straight line start-
ing in the center and moving outward.
Do not use solvents, anti-static sprays,
etc. for cleaning.
Replace the CD in its case after use.
Protect CDs from heat and direct
sunlight.MP3 notes
The CD changer* can play audio CDs as
well as CDs with MP3 files.
Information on MP3 data carriersCompatible MP3 data carriers
The CD changer can read the following
data carriers in MP3 mode:
CD-DA
CD-R
CD-RW
Compatible file systems and compres-
sion methods
Use Romeo or Joliet. Depending on file for-
mat used, up to 128 characters are possi-
ble.
The following compression methods are
compatible:
MP3
WMA
WAV
i
CD media, CD burning software and
CD writers are available in great vari-
ety. Due to this variety, it cannot be
guaranteed that the CD changer will be
able to play every user-written CD.
The burning process can lead to data
errors and aging of the medium may re-
sult in data loss. Therefore, the
CD changer may be restricted in its
ability to play MP3 data carriers; it may
play them with reduced sound quality,
or it m ay not b e a bl e to pl ay them a t al l.
Problems may be encountered during
playback of user-written CDs with a
storage capacity of more than 700 MB.
These CDs do not meet valid standards
as of this printing.
Page 218 of 473

217 Controls in detail
Audio system
Compatible bit and sampling rates
Fixed and variable bit rates of up to
320 kBit/s are possible.
The following table lists possible sampling
rates:Information on copyright
The music tracks that you create for use in
MP3 mode or that you play in MP3 mode
are subject to copyright laws under appli-
cable international and national regula-
tions.
In many countries, the reproduction of
copyrighted materials is not permitted,
even if only for personal use, without the
express prior consent of the copyright
holder.
Please check the current copyright laws
for your country and comply with them.
These restrictions do not apply, for exam-
ple, to your own compositions and record-
ings, or for recordings for which
authorization has been obtained from the
copyright holder.MP3 playback
You can play a CD with MP3 files on the
CD changer* as you would any standard
audio CD. All of the functions described for
the CD changer also apply for the playback
of CDs with MP3 files. Keep in mind that
the single CD player in the audio system
unit is not able to read CDs with MP3 files.
The first 99 tracks on the CD, including
tracks in subdirectories, are recognized
and played. Any additional tracks will not
be played.
MPEG1
Audio Layer344.1 KHz, 48 KHz,
32 KHZ
MPEG2
Audio Layer322.5 KHz, 24 KHz,
16 KHz
MPEG2.5
Audio Layer311.025 KHz,
12 KHz, 8 KHz
WMA32 KHz, 44.1 KHz,
48 KHz
i
Only use MP3 tracks with a bit rate of
128 kBit/s or higher and with the spec-
ified sampling rates.
The use of rates other than those spec-
ified may lead to noticeably inferior
sound quality.
i
Due to the branched data structure,
playback of the first track may be de-
layed slightly.
Page 219 of 473

218 Controls in detail
Audio system
Operating the single CD player in the
audio system unit
Loading a CD
The single CD player in the audio system
unit has capacity for one CD. The CD slot
for loading the drive is located underneath
the soft keys.
Make sure the system is switched on.
Insert CD into CD slot. The label side of
the CD must face upwards.
The system automatically pulls the CD
into the CD slot. The audio CD begins
to play.Ejecting a CDMake sure the system is switched on.
Press EJECTbutton.
The system ejects the CD.
NO CD will
appear in the display.
Remove CD from slot.Operational readiness of CD changer*
If a CD changer* has been installed in the
vehicle, it can be operated from the front
control panel of the audio system.
A loaded magazine must be installed to
play CDs.
The CD changer* is located in the glove
box.
i
Keep in mind that the single CD player
in the audio system unit is not able to
read CDs with MP3 files.
!
If a CD is already loaded, it must be
ejected before inserting a new CD.
Inserting a second CD in the slot with
another CD still loaded will cause dam-
age to the CD drive not covered by the
Mercedes-Benz Limited Warranty.
i
If a CD has been inserted incorrectly or
cannot be read,
WRONG CD ERROR will ap-
pear in the display.
i
If you do not take the CD out of the CD
slot within approx. 15 seconds, the
system automatically pulls the CD back
in and plays it.
If a CD is pulled back in, press
EJECTbutton for 5 seconds; the CD
will then be ejected.
Page 220 of 473

219 Controls in detail
Audio system
Loading/unloading the CD magazine
Slide changer door to the right and
press gbutton.
Magazine will be ejected.
1CD
2CD changer
3CD tray
4CD magazine
Remove magazine4 and pull
CD tray3 fully out.
Place CD1 in recess of tray, label side
up.
Push tray into magazine in direction of
arrow.
Push magazine into CD changer*2 in
direction of arrow and close sliding
door.Playing CDs
Single CD player in the audio unit
Pressi button.
CD 0 will appear in the upper left-hand
corner of the display.
The CD will resume playback at the point
where it was switched off.
CD changer*
Press Q button.
CD and the selected magazine slot
number appear in the upper left-hand
corner of the display.
If you have not removed a CD since the last
time the CD audio source was activated,
the last CD listened to will begin to play at
the point where it was switched off.
After the last track on a CD has finished,
the next CD is automatically played.
i
The CD changer* may not be able to
play audio CDs with copy protection.
i
CDs which have been inserted
improperly or are unreadable will not
be played.
Page 221 of 473
220 Controls in detail
Audio system
Playing tracks
You have the following options:
Audio system with CD changer*:
selecting CDs
Direct track entry
Track skip forward/reverse
Fast forward/reverse
Scan
Random tracks
Repeat trackSelecting CDs in the audio unit with CD
changer*
You can select from among the
inserted CDs with buttons
Rto6.
R = CD player in the audio unit
1to6 = CDs in the
CD changer*
The magazine slot number of the
selected CD appears next to
CD in the
display, and the number of the
currently played track appears next
to
TRACK.Direct track entry
You can make a direct selection from
among the tracks on a CD.
Press * button.
Enter track number using buttons 1
to R.
The number of the track being played
appears next to
TRACK in the display.
You can only enter available track
numbers.
i
If there is no CD in the selected
magazine slot,
NO CD appears in the
display with the corresponding slot
number.
Page 222 of 473

221 Controls in detail
Audio system
Skipping tracks forward/backward
Skipping tracks forward
Press S button briefly.
The next track will be played.
Skipping tracks backward
Press T button briefly.
If the track has been playing for
more than 10 seconds, the unit
skips back to the beginning of the
track currently playing. If less than
10 seconds have been played, the
unit skips back to the beginning of
the previous track.
Pressing the T or S button
repeatedly will result in multiple tracks
being skipped.Fast forward/reverse
Fast forward
Press and hold S button until
desired point has been reached.
Reverse
Press and hold T button until
desired point has been reached.
Scan
Starting scan
Press SC soft key.
SC will appear in the display.
Each track on the current CD will be
played for approx. 8 seconds in as-
cending order.
Ending scan
Press SC soft key or T or S.Random play
The random function (RDM) plays the
tracks of the current CD in random order.
Switching on random
Press RDM soft key.
RDM appears in the display.
A randomly selected track is
played.
Switching off random
Press RDM soft key again.
i
The track number and the relative time
of the track is shown in the display
during the search.
i
When you start the RDM function, the
RPT function is automatically switched
off.
Page 223 of 473
222 Controls in detail
Audio system
Repeat
The track being played is repeated until the
repeat function is switched off.
Switching on repeat
Press RPT soft key.
RPT appears in the display.
Switching off repeat
Press RPT soft key again.Pause function
The CD changer mode is interrupted by an
incoming call on the telephone*
(
page 227).
Switching on pause function
Press U button.
The CD changer mode is
interrupted and
PAUSE appears in
the display.
Switching off pause function
Press U button.
The CD changer mode is active
again.Track and time display
Press T soft key.
The number of the track being played
and the elapsed playing time appear in
the display.
Press T soft key again.
The total number of tracks and the total
playing time of the CD appear in the
display.
Press T soft key.
The standard CD playback menu
appears in the display.
i
When you start the RPT function, the
RDM function is automatically
switched off.
Page 224 of 473

223 Controls in detail
Audio system
GSM network phones
Using your Mercedes-Benz specified
mobile telephone*, a number of functions
and operating steps can be performed and
displayed in the audio system display.
Further operating instructions not covered
here can be found in the operating instruc-
tions for the multifunction steering wheel
and the cellular telephone*.
I f y o u r a u d i o s y s t e m i s s e t u p f o r t e l e p h o n e
operation, the tsymbol will appear in
the display.
When you insert your Mercedes-Benz
specified mobile telephone* into the
telephone cradle, you will be prompted to
enter your PIN for 30 seconds
(
page 223). This display disappears
when you press any button.
When your mobile telephone is inserted
into the telephone cradle, you will see the
reception strength in the upper right-hand
corner of the display.Switching on the telephone
Switching on the telephone
Pressh button.
If the telephone was previously
switched off,
PROCESSING appears in
the display and you will then be
prompted to enter your PIN.
Switching off the telephone
Pressh button for approximately
3 seconds.
PROCESSING appears in the display until
the telephone is off. Afterward,
PHONE OFF appears in the display.PIN entry
Enter PIN number using buttons 1
to R.
If necessary, correct number entered
with the
CLR soft key. Press soft key
briefly to delete the last digit entered;
press soft key and hold to delete the
complete number.
Press OK soft key after entering correct
PIN.
READY or ROAMING will appear in the
display.
