2006 MERCEDES-BENZ C55AMG engine oil

Contents
Loading .............................................. 248
Roof rack* .................................... 248
Ski sack (Canada only) ................. 249
Split rear bench seat .................... 252
Loading instructions ..................... 254
Cargo tie-down rings* .................. 255
Useful features .................................. 256
Storage compartments................. 256
Cup holders .................................. 258
Ashtrays ....................................... 260
Cigarette lighter ........................... 262
Power outlet ................................. 263
Telephone*................................... 263
Tele Aid* ...................................... 264
Garage door opener ..................... 273
Operation......................................... 281
The first 1 000 miles (1 500 km)......... 282
Driving instructions............................ 283
Drive sensibly – save fuel ............. 283
Drinking and driving ..................... 283
Pedals .......................................... 283
Power assistance ......................... 283
Brakes .......................................... 284
Driving off .................................... 285
Parking ......................................... 285
Tires ............................................. 286
Hydroplaning ................................ 287
Tire traction.................................. 287
Tire speed rating .......................... 288
Winter driving instructions ........... 288
Standing water ............................. 289
Passenger compartment .............. 290
Driving abroad.............................. 290
Control and operation of radio
transmitters ................................. 290
Catalytic converter ....................... 291
Emission control .......................... 291
Coolant temperature .................... 292At the gas station .............................. 293
Refueling ...................................... 293
Check regularly and before a
long trip ....................................... 294
Engine compartment ......................... 297
Hood ............................................ 297
Engine oil ..................................... 298
Transmission fluid level ................ 301
Coolant level ................................ 301
Battery ......................................... 303
Windshield washer system and
headlamp cleaning system*......... 304
Tires and wheels................................ 305
Important guidelines .................... 305
Tire care and maintenance........... 306
Direction of rotation..................... 308
Loading the vehicle ...................... 308
Recommended tire inflation
pressure ....................................... 315
Checking tire inflation pressure ... 317
Tire labeling ................................. 321
Load identification ....................... 325
DOT, Tire Identification Number
(TIN) ............................................. 326
Maximum tire load ....................... 327
Maximum tire inflation pressure .. 328

Contents
Technical data.................................. 423
Parts service ...................................... 424
Warranty coverage ............................. 425
Loss of Service and Warranty
Information Booklet...................... 425
Identification labels............................ 426
Layout of poly-V-belt drive ................. 427
Engine ................................................ 428
Rims and Tires ................................... 429
Same size tires ............................. 431
Mixed size tires ............................ 432
Spare wheel (collapsible tire) ....... 433
Electrical system................................ 434
Main dimensions and weights ............ 435
Main dimensions .......................... 435
Weights ........................................ 435Fuels, coolants, lubricants, etc. ......... 436
Capacities .................................... 436
Engine oils.................................... 437
Engine oil additives ...................... 437
Air conditioning refrigerant .......... 437
Brake fluid .................................... 437
Premium unleaded gasoline ......... 438
Gasoline additives ........................ 438
Fuel requirements ........................ 439
Coolants....................................... 439
Windshield washer and headlamp
cleaning system* ......................... 442Technical terms............................... 443
Index................................................. 449

129 Controls in detail
Control system
Menus, submenus and functions
Menu1Menu2Menu3Menu4Menu5Menu6Menu7
Standard
displayAUDIONAV*Vehicle status
message memorySettingsTrip computerTelephone*
(page 130)(page 131)(page 134)(page 134)(page 135)(page 150)(page 152)
Commands/submenus
Run Flat
Indicator*
(Canada only)Select radio
stationShow route guid-
ance instructions,
current direction
traveledCall up vehicle mal-
function, warning and
system status messag-
es stored in memory
1
1The vehicle status message memory menu is only displayed if there is a message stored.
Reset to
factory
settingsFuel consumption
statistics after
startLoad phone
book
Digital speed-
ometer or out-
side temperatureSelect satellite
radio station*
(USA only)Instrument
cluster sub-
menuFuel consumption
statistics since
the last resetSearch for
name in
phone book
Call up main-
tenance service
displayOperate
CD player* Time/Date
submenuDistance to emp-
ty
Check engine oil
levelLighting
submenu
Vehicle
submenu
Convenience
submenu

130 Controls in detail
Control system
Standard display menu
In the standard display, the main odometer
and the trip odometer are shown in the
multifunction display.
1Trip odometer
2Main odometer
If another display is shown instead of the
standard display:
Press buttonè orÿ repeatedly
until you see the standard display.
Press buttonk orj to select
the functions in the standard display
menu.The following functions are available:Display digital speedometer or outside
temperature
Press buttonj ork repeatedly
until you see the digital speedometer.
The current vehicle speed is shown in
the multifunction display.
1Digital speedometerFunctionPage
Run Flat Indicator* (Canada
only)318
Call up digital speedometer or
outside temperature130
Call up maintenance service
display338
Check engine oil level299
i
Select either the display of the digital
speedometer or the outside tempera-
ture indicator (
page 139).

295 Operation
At the gas station
Coolant
For normal replenishing, use water (pota-
ble water quality). For more information,
see “Coolant level” (
page 301) and
“Fuels, coolants, lubricants, etc.”
(
page 436).
Brake fluid
Removing fuse box cover (
page 421).Windshield washer and headlamp
cleaning system*
For more information on filling up the
washer reservoir, see “Windshield washer
system and headlamp cleaning system*”
(
page 304).
Engine oil level
For more information on engine oil level,
see “Engine oil” (
page 298).Vehicle lighting
Check function and cleanliness. For more
information on replacing light bulbs, see
“Replacing bulbs” (
page 394).
Exterior lamp switch (
page 114).
!
If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately.
Notify an authorized Mercedes-Benz
Center immediately. Do not add brake
fluid as this will not solve the problem.
For more information, see “Practical
hints” (
page 351).

298 Operation
Engine compartment
Closing
Let the hood drop from a height of
approximately 1 ft (30 cm).
The hood will lock audibly.
Check to make sure the hood is fully
closed.
If you can raise the hood at a point
above the headlamps, then it is not
properly closed. Open it again and let it
drop with somewhat greater force.
Engine oil
The amount of oil your engine needs will
depend on a number of factors, including
driving style. Higher oil consumption can
occur when

the vehicle is new

the vehicle is driven frequently at
higher engine speeds
Engine oil consumption checks should only
be made after the vehicle break-in period.
Warning!G
If you see flames or smoke coming from the
engine compartment, or if the coolant tem-
perature gauge indicates that the engine is
overheated, do not open the hood. Move
away from vehicle and do not open the hood
until the engine has cooled. If necessary,
call the fire department.
Warning!G
The engine is equipped with a transistorized
ignition system. Because of the high voltage
it is dangerous to touch any components
(ignition coils, spark plug sockets, diagnos-
tic socket) of the ignition system

with the engine running

while starting the engine

if ignition is “on” and the engine is
turned manually
Warning!G
Be careful that you do not close the hood on
anyone.
i
Do not use any special lubricant addi-
tives, as these may damage the drive
assemblies. Using special additives not
approved by Mercedes-Benz may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
More information on this subject is
available at any Mercedes-Benz
Center.

299 Operation
Engine compartment
Checking engine oil level with the
control system
When checking the oil level

the vehicle must be parked on level
ground

with the engine at operating tempera-
ture, the vehicle must have been
stationary for at least 5 minutes with
the engine turned off

with the engine not at operating tem-
perature yet, the vehicle must have
been stationary for at least 30 minutes
with the engine turned off
To check the engine oil level via the
multifunction display, do the following:
Switch on the ignition (page 33).
The standard display (
page 125) should
appear in the multifunction display.
Press buttonk orj on the
multifunction steering wheel until the
following message is seen in the multi-
function display:One of the following messages will
subsequently appear in the multifunc-
tion display:

Engine oil
level
OK

Add 1.0 qt engine oil
for max. oil level
(Canada: 1.0 l)

Add 1.5 qts engine oil
for max. oil level
(Canada: 1.5 l)

Add 2.0 qts engine oil
for max. oil level
(Canada: 2.0 l)
If necessary, add engine oil.
For adding engine oil, see (
page 300).
For more information on engine oil, see the
“Technical data” section (
page 436) and
(
page 437).
Other display messages
If the SmartKey is not turned to position2
in the starter switch, the following
message will appear:
Switch ignition on to
check engine oil level
Switch on the ignition (page 33).
i
If you want to interrupt the checking
procedure, press thek orj
button on the multifunction steering
wheel.

300 Operation
Engine compartment
If you see the message:
Observe waiting time
If engine is at operating temperature,
wait 5 minutes before repeating check
procedure.
If engine is not at operating tempera-
ture yet, wait 30 minutes before
repeating check procedure.
If you see the message:
Engine oil level
Not when engine on
Turn off the engine.
If the engine is at operating tempera-
ture, wait 5 minutes before checking
oil.
If the engine is not at operating temper-
ature yet, you must wait 30 minutes
before checking oil.If there is excess engine oil with the engine
at operating temperature, the following
message will appear:
Engine oil level
Reduce oil level
Have excess oil siphoned or drained
off. Contact an authorized
Mercedes-Benz Center.
For more information on messages in the
multifunction display concerning engine
oil, see the “Practical hints” section
(
page 371) and (page 372).Adding engine oil
!
Excess oil must be siphoned or drained
off. It could cause damage to the
engine and catalytic converter not
covered by the Mercedes-Benz Limited
Warranty.
!
Only use approved engine oils and oil
filters required for vehicles with
Maintenance System (U.S. vehicles) or
FSS (Canada vehicles). For a listing of
approved engine oils and oil filters,
refer to the Factory Approved Service
Products pamphlet in your vehicle
literature portfolio, or contact an
authorized Mercedes-Benz Center.
Using engine oils and oil filters of
specification other than those
expressly required for the Maintenance
System (U.S. vehicles) or FSS (Canada
vehicles), or changing of oil and oil filter
at change intervals longer than those
called for by the Maintenance System
(U.S. vehicles) or FSS (Canada
vehicles) will result in engine damage
not covered by the Mercedes-Benz
Limited Warranty.
