1997 FORD RANGER Owners Manual

232
[ER16700(R)01/96]
[ER16800(R)01/96] 3.Inser tth etapere den dof th elu g nu twrenc hbehin dwheel
WARNING
Us eonl ythelu g nu twrenc hprovide dto remov ewheel

RoadsideEmergencies
233
WARNING
Us eonl ythelu g nu twrenc hprovide dto remov ewheel
WARNING
To avoi dinjury ,neve rru n theengin ewit hon ewhee loff

234
[ER18301(R)01/96]
10-1/2 pica art:0020297-E
Front axle jacking point
[ER18401(R)01/96]
c. Turn the jack handle clockwise until the wheel is a
maximum of one inch off the ground.
[ER18551(R)01/96]
10-1/2 pica
art:0021187-B
Rear axle jacking point
[ER18650(R)01/96]
NOTE: Do not use the differential housing as a lift point.
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

RoadsideEmergencies
235
*WARNING
To lesse ntheris kof persona linjury ,do no tpu tan ypart

236
*WARNING
Neverus ewheel sor lu g nut sdifferen ttha ntheoriginal

RoadsideEmergencies
237
WARNING
Failur eto retighte nwhee llu g nut sat mileage sspecified
%
WARNING
Th egase saroun dthebatter ycan explod eif expose dto

238
WARNING
To protec tyoursel fwhe nchargin gabattery ,always
WARNING
Applyin gtoo muc hpressur eon theend swhe nliftin ga
WARNING
Batterie scontai nsulfuri caci dwhic hburn sskin ,eyes,
WARNING
D o no tpush-star tyou rvehicle .Yo ucoul ddamag ethe
WARNING
To avoi ddamag eor injury ,follo wthes edirection sin the

Roadside Emergencies
239
%*
[ER25100(R)02/96]
Preparing Your Vehicle
*
[ER25200(R)02/96]1.
Your vehicle has a 12-volt starting system, so you need to
use a 12-volt jumper system. You will damage your starting
motor, ignition system, and other electrical parts if you
connect them to a 24-volt power supply (either two 12-volt
batteries in series or a 24-volt generator set).
*
[ER25300(R)02/96]2.
Do not disconnect the battery of the disabled vehicle. You
could damage the vehicle's electrical system.
*
[ER25400(R)02/96]3.
Park the booster vehicle close to the hood of the disabled
vehicle.Make sure the vehicles do not touch each other.Set
the parking brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER25500(R)02/96]4.
Check all battery terminals and remove any excessive
corrosion before you attach the jumper cables.
*
[ER25600(R)02/96]5.
Turn on the heater fan in both vehicles. Turning on the fan
helps protect the electrical system from voltage surges. Turn
off all other switches and lights in both vehicles to prevent
possible damage to either vehicle's electrical systems.
%*
[ER25700(R)02/96]
Connecting the jumper cables
*
[ER25800(R)02/96]1.
Connect one end of the first jumper cable to the positive (+)
terminal of the discharged battery. (You can connect either
jumper cable to the positive (+) terminal, as long as you use
the same cable for both positive terminals.) Most jumper
cables have a red cable and a black cable. The red cable is
generally used for the positive terminals and the black for
the negative ones.
*
[ER25900(R)02/96]2.
Connect the other end of the first cable to the positive (+)
terminal of the booster battery.
*
[ER26000(R)02/96]3.
Connect one end of the second cable to the negative (s)
terminal of the booster battery Ð NOT to the discharged
battery.
