1997 FORD RANGER Owners Manual

216
WARNING
Do no tus ethi svehicl efo rsnowplowing.

217
Roadside Emergencies
%*[ER00200(R)03/96]Hazard Flasher
*[ER00210(R)01/96]The hazard flasher is used to alert other drivers to hazardous
situations.
*[ER00212(R)03/96]The flashers will flash and the high-mount brakelamp will stay
on steadily (not flash) with the brake pedal depressed.
*[ER00214(R)01/96]The flashers work whether your vehicle is running or not. The
flashers work for up to two hours when the battery is fully
charged and in good condition without draining the battery
excessively. If the flashers run for longer than two hours or if
the battery is not fully charged, the battery power can be
drained.
*[ER00216(R)01/96]To use the hazard flasher:
*[ER00218(R)01/96]1.Push in the flasher button; it will pop out and the lamps will
begin to flash.
*[ER00220(R)01/96]2.To stop the flashers, push in the flasher button again.
*[ER00230(R)01/96]NOTE: The flasher button will be sticking up slightly higher
when on than when off.
[ER00250(R)01/96]
10-1/2 pica
art:0020079-D
Hazard flasher
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

218
*
[ER00300(R)01/96]
The Fuel Pump Shut-off Switch
*
[ER00400(R)05/96]
If the engine cranks but does not start or if you have had a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device that stops the fuel
pump when your vehicle has been involved in a substantial jolt.
*
[ER00500(R)05/96]
For information on how to check and reset the fuel pump
shut-off switch, seeFuel pump shut-off switchin the Index.
%*
[ER00700(R)01/96]
Fuses
[ER00800(R)01/96]
Fuses protect your vehicle's electrical system from overloading.
If electrical parts in your vehicle are not working, the system
may have been overloaded and blown a fuse. Before you
replace or repair any electrical parts, check the appropriate
fuses.
[ER00900(R)01/96]
The following charts tell you which fuses protect each electrical
part of your vehicle. If a fuse blows, all the parts of your
vehicle that use that circuit will not work.
*
[ER01000(R)01/96]
Once you have determined which fuses to check, follow the
procedures underChecking and replacing fuseslater in this
chapter.
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

Roadside Emergencies
219
[ER01100(R)01/96]
17-1/2 pica
art:0021207-B
Fuse panel (located left side of instrument panel)
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

220
[ER01200(R)05/96]
33-1/2 pica
art:0090210-B
Fuses and their location
File:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

Roadside Emergencies
221
[ER01300(R)05/96]
thirty-two pica
chart:0090137-CFile:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

222
[ER01400(R)05/96]
twenty-eight pica
chart:0090138-EFile:10unerr.ex
Update:Thu Mar 20 08:56:46 1997

RoadsideEmergencies
223
WARNING
Alway sdisconnec tth ebatter ybefor eservicin ghigh
WARNING
Alway sreplac eth ecove rto thePowe rDistributio nBox
WARNING
Alway sreplac eafusewit hon etha tha sth especified
