1996 FORD TAURUS Owners Manual

55 [SR28550(ALL)12/95]
9. Pull the shoulder belts out to ensure that the
crotch safety belt buckle is securely fastened
and the retractor is locked. Refer to Figure 8.
[SR28575(ALL)12/95]
half page art:0001455-B
Figure 8: Checking for securely latched buckle and locked
retractor
[SR28600(ALL)12/95]
10. If the belts become too tight, unbuckle the
crotch safety belt buckle, allow belts to
retract, then reinsert both belt tongues.
*
[SR28650(ALL)08/95]
To remove the child from the built-in child
seat:
[SR28700(ALL)12/95]
1. Squeeze the tabs on the top and bottom of
the chest clip and pull the halves apart to
open the chest clip. Refer back to Figure 7.
*
[SR28750(ALL)08/95]
2. Press the release button on the crotch safety
belt buckle.
[SR28800(ALL)12/95]
3. Slide the shoulder belts off the child's
shoulders and remove the child. Refer back
to Figure 5.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

56
*
[SR28850(ALL)08/95]
To stow the built-in child seat:
[SR28900(ALL)08/95]
1. Return the child seat cushion to the upright
position.
[SR28950(ALL)08/95]
2. Press firmly in the center and top of the
child seat to place it in the stowed position.
[SR28960(ALL)12/95]
3. Reattach the flap on the child seat to the top
of the seatback.
[SR29000(ALL)03/95]
The seat can now be used by an adult or the
seatback can be folded down.
[SR29025(ALL)09/95]
NOTE: The seatback cannot be folded down
unless the child seat is fully stowed.
*
[SR29050(ALL)08/95]
Inspection after a collision
[SR29100(ALL)08/95]
RWARNING
All built-in child restraints, including
seats, buckles, retractors, seat latches,
interlocks, and attaching hardware should
be inspected by a qualified Dealer
technician after any collision. If the child
seat was in use during a collision, Ford
recommends replacing it. However, if the
collision was minor and a qualified
technician finds that the child restraints
do not show damage and continue to
operate properly, they do not need to be
replaced. Built-in child seats not in use
during a collision should also be
inspected and replaced if either damage or
improper operation is noted.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

57
*
[SR29150(ALL)08/95]
Built-in child seat maintenance
*
[SR29200(ALL)08/95]
Regularly inspect the lap and shoulder belts
system of your child seat. See your Ford dealer
if the shoulder belt webbing is frayed, or if the
buckle and tongue are damaged and/or do not
function properly.
%*
[SR29250(ALL)08/95]
Cleaning
[SR29300(ALL)08/95]
Your built-in child seat may be cleaned with
mild soap and water. Do not use household
cleaners as they may weaken the webbing or
damage the plastic parts. For your convenience,
the liner is removable and can be
machine-washed and air-dried.
%*
[SR29500(ALL)07/95]
Safety Belts for Children
*
[SR29600(ALL)07/95]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SR29700(ALL)07/95]
RWARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SR29800(ALL)12/95]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

58
*
[SR29900(ALL)07/95]
To improve the fit of lap and shoulder belts on
children who have outgrown child safety seats,
Ford recommends use of a belt-positioning
booster seat that is labelled as conforming to all
Federal motor vehicle safety standards.
Belt-positioning booster seats raise the child and
provide a shorter, firmer seating cushion that
encourages safer seating posture and better fit of
lap and shoulder belts on the child. A
belt-positioning booster should be used if the
shoulder belt rests in front of the child's face or
neck, or if the lap belt does not fit snugly on
both thighs, or if the thighs are too short to let
the child sit all the way back on the seat cushion
when the lower legs hang over the edge of the
seat cushion. You may wish to discuss the
specific needs of your child with your
pediatrician.
*
[SR30000(ALL)07/95]
RWARNING
Do not use a belt-positioning booster with
a lap-only belt.
*
[SR30100(ALL)07/95]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
*
[SR30200(ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

59
Starting Your Taurus
*
[ST03300(ALL)03/95]
Ignition
%*
[ST03400(ALL)01/95]
Understanding the Positions of the Ignition
[ST03725(ALL)11/94]
quarter page art:0000017-D
The positions of the key in the ignition
%*
[ST04050(ALL)07/95]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
% [ST04100(ALL)10/89]
LOCK locks the steering wheel. It also locks the
gearshift for all vehicles with an automatic
transaxle.
*
[ST04175(ALL)08/95]
The automatic transaxle gearshift must be in P
(Park) to move the key to the LOCK position.
*
[ST04200(ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
%*
[ST04300(ALL)05/95]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
[ST04325(ALL)04/95]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transaxle gearshift lever.
File:04fcstt.ex
Update:Mon Jan 22 15:46:50 1996
ProCarManuals.com

60
*
[ST04350(ALL)05/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST04375(ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
%*
[ST04500(ALL)02/95]
Removing the Key From the Ignition
[ST06000(ALL)02/95]
Procedures for removing the key from the
ignition will be the same for both the column-
and console-mounted gearshifts.
*
[ST06300(ALL)06/95]
1. Put the gearshift in P (Park).
*
[ST06400(ALL)01/95]
2. Set the parking brake fully.
[ST06500(ALL)11/94]
3. Turn the ignition to the LOCK position.
*
[ST06600(ALL)03/95]
4. Remove the key.
[ST07310(ALL)05/95]
If you have difficulty in turning the key, rotate
the steering wheel slightly because it may be
binding.
%*
[ST07520(ALL)05/95]
If the driver's door is open while the key is still
in the ignition, a warning chime sounds.
*
[ST07525(ALL)06/95]
RWARNING
Always set the parking brake fully and
make sure the gearshift is securely latched
in P (Park).
File:04fcstt.ex
Update:Mon Jan 22 15:46:50 1996
ProCarManuals.com

61
*
[ST07575(ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
*
[ST08200(ALL)03/95]
Starting Your Vehicle
%*
[ST08300(ALL)05/94]
Preparing to Start Your Vehicle
*
[ST08350(ALL)09/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST08400(ALL)01/95]
Before you start your vehicle, do the following:
*
[ST08500(ALL)08/95]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST08600(ALL)03/95]
2. Make sure your headlamps and other
accessories are turned off and the parking
brake is set.
[ST08850(ALL)11/94]
3. Make sure that the gearshift is in P (Park)
before you turn the key.
*
[ST09150(ALL)03/95]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to theWarning
Lights and Gaugeschapter.
File:04fcstt.ex
Update:Mon Jan 22 15:46:50 1996
ProCarManuals.com

62 %
*
[ST09310(ALL)02/95]
Starting Your Engine
*
[ST09320(ALL)06/95]
To start your engine:
*
[ST09330(ALL)05/95]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[ST09340(ALL)03/95]
2. Turn the ignition key to the ON position.
*
[ST09350(ALL)06/95]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[ST09360(ALL)02/95]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[ST09370(ALL)02/95]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[ST09375(ALL)04/95]
For a cold engine:
*
[ST09381(ALL)06/95]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[ST09385(ALL)04/95]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
%*
[ST09387(ALL)05/95]
For a warm engine:
*
[ST09390(ALL)04/95]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
File:04fcstt.ex
Update:Mon Jan 22 15:46:50 1996
ProCarManuals.com
