1996 FORD TAURUS Owners Manual

171 [AS10550(ALL)10/95]
full page art:0001448-B
Stereo Cassette with CD-DJ
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

172
% [AS10600(ALL)04/95]
Stereo and Stereo Cassette Radios
*
[AS10650(ALL)08/95]
Using the Controls on Your New Radio
*
[AS10700(ALL)10/95]
How to turn the radio on and off
[AS10750(ALL)04/95]
Press the ªVOL PUSH ONº button to turn the
radio on. Press again to turn off.
*
[AS10800(ALL)10/95]
How to adjust the volume
[AS10825(ALL)02/95]
Turn the ªVOL PUSH ONº knob to the right to
increase the volume and to the left to decrease
the volume. Dots illuminate in the display to
show relative volume level.
[AS10840(ALL)09/95]
NOTE: If the volume is set above a certain
level when the ignition is turned off,
the volume will come back to a
ªnominalº listening level when the
ignition is turned back on. However, if
the radio power is turned off with the
ªVOL PUSH ONº button, the volume
will not change and will remain at the
level set when the radio is turned back
on.
*
[AS11000(ALL)10/95]
Selecting the AM or FM frequency band
[AS11125(ALL)04/95]
Press the ªAMº or ªFMº button to select the
desired frequency band or to stop/store cassette
tape (when a cassette is playing). Pressing the
ªFMº button more than once will alternate
between FM1 and FM2. These functions are used
with the station memory buttons described
underHow to tune radio stations.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

173 %
*
[AS11200(ALL)10/95]
How to tune radio stations
[AS11300(ALL)04/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªTUNEº button, ªSEEKº to the
station, ªSCANº to the station or select the
station by using the memory buttons. These four
methods are described below.
*
[AS11400(ALL)09/95]
q
Using the ªTUNEº function
[AS11525(ALL)02/95]
You can change the frequency up or down
one increment at a time by pressing and
releasing either the right (
a) or left (
b) side
of the ªTUNEº or ªTUNE/DISCº button. To
change frequencies quickly, press and hold
down either the right or left side of the
button.
*
[AS11700(ALL)10/95]
q
Using the ªSEEKº function
*
[AS11825(ALL)01/95]
Press the right (
a) side of the ªSEEKº
button to select the next listenable station up
the frequency band. Press the left (
b) side of
the button to select the next listenable station
down the frequency band. By pressing and
holding the button, listenable stations can be
passed over to reach the desired station.
*
[AS12200(ALL)01/95]
q
Using the ªSCANº function
[AS12325(ALL)05/95]
Pressing the ªSCANº button will begin the
scan mode up the frequency band, stopping
on each listenable station for approximately
five seconds. The band indicator (AM, FM1,
FM2) flashes during scan operation.
*
[AS12340(ALL)02/95]
To stop the scan mode on the presently
sampled station, press the ªSCANº button
again.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

174
*
[AS12700(ALL)10/95]
q
Setting the Station Memory Preset buttons
*
[AS12850(ALL)10/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
[AS12900(ALL)02/95]
Follow the steps below to set these buttons to
the desired frequencies:
*
[AS13025(ALL)10/95]
1. Select a band, then select a frequency.
*
[AS13200(ALL)10/95]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS13300(ALL)10/95]
3. Follow the two steps above for each station
memory preset button you want to set.
[AS13510(ALL)04/95]
q
Using the Radio Set feature
[AS13515(ALL)04/95]
With Radio set, you can automatically set
strong stations into your memory buttons.
AM, FM1 and FM2 will be set sequentially.
[AS13545(ALL)04/95]
Turn the radio off with the ªVOL PUSH ONº
knob. Press and hold the ªSCANº button and
turn the radio on by pressing the ªVOL
PUSH ONº knob. Continue holding the
ªSCANº button until ªRADº is shown in the
display.
[AS13550(ALL)09/95]
NOTE: If there are less than six strong stations
in the frequency band, the remaining
unfilled buttons will store the last
strong station detected on the band.
*
[AS13560(ALL)10/95]
After all stations have been filled, the radio
will begin playing the station stored on
memory button 1.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

175
*
[AS13600(ALL)10/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS13800(ALL)10/95]
q
Increasing or decreasing bass response
[AS13925(ALL)04/95]
Press the right (
a) side of the ªBASSº button
to increase bass (more ªlowsº); press the left
(
b) side of the ªBASSº button to decrease
bass (less ªlowsº).
*
[AS14000(ALL)10/95]
q
Increasing or decreasing treble response
[AS14125(ALL)04/95]
Press the right (
a) side of the ªTREBº
button to increase treble (more ªhighsº);
press the left (
b) side of the ªTREBº button
to decrease treble (less ªhighsº).
*
[AS14400(ALL)10/95]
q
Adjusting speaker balance
[AS14525(ALL)04/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Press the right (
a) side of the
ªBALº button to shift the sound to the right
speakers, and press the left (
b) side to shift
the sound to the left speakers. The display
will show ªBALº and a dot indicating the
balance position.
*
[AS14600(ALL)10/95]
q
Adjusting speaker fader
[AS14725(ALL)04/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Press the right (
a) side of the
ªFADEº button to shift the sound to the front
speakers, and press the left (
b) side to shift
the sound to the rear speakers. The display
will show ªFADEº and a dot indicating the
fade position.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

176 [AS14800(ALL)04/95]Using the Power Antenna (If equipped)
*
[AS14850(ALL)02/95]
The power antenna will automatically rise when
your radio is turned on and the ignition is in the
ON or ACC position. It will lower when either
the radio or the ignition is turned off.
*
[AS14900(ALL)02/95]
Power antenna maintenance and care
*
[AS14950(ALL)02/95]
q
Never drive your vehicle through a car wash
with the power antenna mast extended. This
can cause damage to the antenna mast, which
is not covered under warranty. Turn off your
radio and/or the vehicle. This will
automatically retract the antenna.
*
[AS15000(ALL)02/95]
q
If your power antenna mast ever becomes
damaged, the mast may not extend or retract
properly which might limit reception
performance. In this case, it is not necessary
to replace the entire power antenna assembly.
A replacement mast can be obtained from
your dealership for a nominal fee.
*
[AS15050(ALL)02/95]
q
Occasionally, the power antenna mast should
be wiped clean with mild soap and water or
denatured alcohol. This prevents debris from
accumulating on the mast which can cause
excessive wear and decrease the power
antenna life. Never use petroleum-based
products to clean your antenna mast.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

177 %
*
[AS15100(ALL)08/95]
Common Radio Reception Conditions
*
[AS15150(ALL)08/95]
Several conditions prevent FM reception from
being completely clear and noise-free, such as
the following:
*
[AS15200(ALL)08/95]
1. Distance/Strength
*
[AS15250(ALL)08/95]
The strength of the FM signal is directly related
to the distance the signal must travel. The
listenable range of an average FM signal is
approximately 25 miles (40 kilometers). Beyond
this distance, the radio is operating in a fringe
area and the signal becomes weaker.
*
[AS15300(ALL)08/95]
2. Terrain
*
[AS15350(ALL)08/95]
The terrain (hilly, mountainous, tall buildings) of
the area over which the signal travels may
prevent the FM signal from being noise-free.
*
[AS15400(ALL)04/95]
3. Rounded off frequencies
*
[AS15450(ALL)08/95]
Some FM radio stations advertise a
ªrounded-offº frequency which is not the
frequency they actually broadcast on. For
example, a radio station that is assigned a
frequency of 98.7 MHz may call itself ªRadio 99º
even though 99.0 MHz is not an allowable FM
broadcast frequency.
%*
[AS15600(ALL)08/95]
Using the Controls of Your Cassette Tape
Player
[AS15700(ALL)09/95]
NOTE: Radio power must be on to use the
cassette tape player.
[AS15800(ALL)09/95]
NOTE: Adjust the volume, treble, bass, balance
and fade controls in the same manner
as for radio stations.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

178
*
[AS15900(ALL)08/95]
How to insert a tape
[AS16025(ALL)12/95]
Your cassette player is equipped with power
loading. Once you insert a tape and push
slightly (with the open edge to the right), the
loading mechanism draws the tape the rest of
the way in and play will begin after a
momentary tape tightening process. Display
indicates ªTAPEº while tape is playing. If the
ªTAPEº button is pressed when the cassette tape
player is empty, ªNOº and ªTAPEº will flash in
the display and radio play will continue.
[AS16050(ALL)09/95]
NOTE: A cassette tape can be loaded with the
ignition on whether the radio is on or
off. However, if the radio is off, the
cassette tape will be loaded and stored.
[AS16300(ALL)12/95]
How to locate a desired selection on the
tape
*
[AS16350(ALL)08/95]
There are four ways to quickly locate a desired
selection on the tape. You can use the fast
forward, rewind, ªSEEKº or ªSCANº function.
Following are brief descriptions of each.
*
[AS16400(ALL)09/95]
q
Fast forwarding the tape
[AS16525(ALL)04/95]
To fast forward the tape, press the ªFFº
button. The radio will automatically begin
playing until fast forward is manually
stopped (by pressing the ªTAPEº, ªEJº,
ªREWº or ªFFº button) or the end of the
tape is reached. The display will show a
flashing
Xto indicate fast forward.
*
[AS16535(ALL)01/95]
At the end of the tape, the direction
automatically reverses and plays the other
side of the tape.
