1996 FORD TAURUS Owners Manual

187 %
*
[AS32310(ALL)08/95]
How To Take Care of and Clean Your CD
Player and Discs
*
[AS32312(ALL)08/95]
To ensure the continued performance of your
Ford Compact Disc Player, carefully read the
following precautions:
*
[AS32314(ALL)08/95]
q
Always handle the disc by its edge. Never
touch the playing surface.
*
[AS32316(ALL)08/95]
q
Before playing, inspect the disc for any
contamination. If needed, clean the disc with
an approved disc cleaner, such as the
DiscwasherHCompact Disc Cleaner or the
Allsop 3HCompact Disc Cleaner, by wiping
from the center out to the edges.Do not use
a circular motion to clean.
*
[AS32318(ALL)08/95]
q
Do not clean discs with solvents such as
benzine, thinner, commercially available
cleaners or antistatic spray intended for
analog records.
*
[AS32320(ALL)08/95]
q
Do not expose the disc to direct sunlight or
heat sources such as defroster and floor
heating ducts. Do not leave any discs in a
parked car in direct sunlight where there may
be a considerable rise in temperature or
damage may result.
*
[AS32322(ALL)08/95]
q
After playing, store the disc in its case.
*
[AS32324(ALL)08/95]
q
If a disc has already been inserted, do not try
to insert another disc. Doing so may damage
the disc player.
*
[AS32326(ALL)08/95]
q
Do not insert anything other than a disc into
the disc player.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

188
*
[AS32328(ALL)08/95]
CAUTION:The use of optical instruments with
this product will increase eye hazard as the laser
beam used in this compact disc player is
harmful to the eyes. Do not attempt to
disassemble the case. Refer servicing to qualified
personnel only.
*
[AS32330(ALL)08/95]
Common Operating Conditions of Your
CD Player
*
[AS32332(ALL)08/95]
The following information is designed to help
you recognize typical situations that could be
mistakenly interpreted as mechanical
malfunctions of the disc player.
*
[AS32336(ALL)08/95]
q
The disc is inserted with the label surface
downward.
*
[AS32338(ALL)08/95]
q
The disc is dusty or defective.
*
[AS32340(ALL)08/95]
q
The player's internal temperature is above
140ÊF (60ÊC).Allow the player to cool off
before operating.
*
[AS32342(ALL)08/95]
q
Different manufacturers of compact discs may
produce discs with different dimensions or
tolerances, some of which may not be within
industry standards or in accordance with the
CD format. Because of this, a new disc that is
free of dust and scratches could be defective
and may not play on your Ford Compact
Disc Player.
*
[AS32344(ALL)09/95]
If play does not begin after the CD button is
pushed:
*
[AS32345(ALL)08/95]
q
The radio is not on.
[AS32346(ALL)02/95]
q
The disc magazine is not fully seated in
changer.
*
[AS32348(ALL)08/95]
q
Moisture may have condensed on the lenses
within the unit. If this occurs, remove the
disc and wait approximately an hour until the
moisture evaporates.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

189
*
[AS32350(ALL)08/95]
If the sound skips:
*
[AS32352(ALL)08/95]
q
Badly scratched discs or extremely rough
roads will cause the sound to skip. Skipping
will not damage the disc player or scratch the
discs.
*
[AS32400(ALL)02/95]
CD Error Messages
[AS32500(ALL)02/95]
Your system is equipped to diagnose certain
problems you may experience. The displayed
error codes are:
[AS32600(ALL)02/95]
NO then CDÐ Empty slot or magazine,
mechanical error, disc(s) unreadable, or
mechanism focus error. Check all discs in the
magazine for scratches and proper insertion. If
problem persists, refer problem to qualified
personnel for service.
[AS32700(ALL)02/95]
NO then DJÐ CD Changer not connected or
not communicating to audio system. Refer
problem to qualified personnel for service.
[AS32800(ALL)04/95]
TOO then HOTÐ The changer's internal
temperature is above140ÊF (60ÊC).Allow the
player to cool before operating.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

190
%*
[AS37000(ALL)08/95]
Important Warranty and Service
Information
*
[AS37050(ALL)07/90]
q
Warranty
*
[AS37100(ALL)08/95]
Your sound system is warranted for three years
or 36,000 miles (60,000 kilometers), whichever
comes first. Consult your vehicle warranty
booklet for further information. Ask your dealer
for a copy of this limited warranty.
*
[AS37150(ALL)07/90]
q
Service
*
[AS37200(ALL)08/95]
At Ford Electronics, we stand behind our audio
systems with a comprehensive service and repair
program. If anything should go wrong with
your Ford audio system, return to your dealer
for service. There is a nationwide network of
qualified Ford authorized repair centers to assist
you.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

191
Driving Your Taurus
*
[DR00300(ALL)07/95]
Your vehicle will have one of the following
types of transaxles:
*
[DR00500(ALL)11/94]
q
an automatic overdrive transaxle, or
[DR00510(ALL)02/95]
q
an automatic overdrive transaxle with
Overdrive Off (O/D OFF) switch
*
[DR00700(ALL)11/94]
If you are not sure which transaxle your vehicle
has, talk to your dealer.
*
[DR00800(ALL)04/95]
Your vehicle is equipped with an Electronic
Powertrain Control Module that limits engine
and/or vehicle speeds with a cut-out mode to
promote durability.
% [DR03510(ALL)04/95]Driving with an Automatic
Overdrive Transaxle (Column
Gearshift without O/D OFF
Switch)
%*
[DR03600(ALL)04/95]
Your automatic overdrive transaxle provides
fully automatic operation in eitherj
(Overdrive) or D (Drive). Driving with the shift
selector inj(Overdrive) gives the best fuel
economy for normal driving conditions. For
manual control, start in 1 (First) and then shift
manually.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

192 %
*
[DR03800(ALL)01/95]
Putting Your Vehicle in Gear
*
[DR04001(ALL)05/95]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
*
[DR04050(ALL)03/95]
To operate:
*
[DR04101(ALL)01/95]
1. Start the engine.
*
[DR04150(ALL)01/95]
2. Depress and hold the brake pedal.
*
[DR04201(ALL)01/95]
3. Move the gearshift lever out of P (Park).
%*
[DR04250(ALL)04/95]
Your vehicle is equipped with a Brake Shift
Interlock safety feature. This feature prevents the
gearshift from being moved from the P (Park)
position until the brake pedal is depressed. This
feature is active when the ignition is in the ON
position. If the gearshift lever CANNOT be
moved from P (Park) with the brake pedal
depressed:
*
[DR04300(ALL)01/95]
1. Turn the engine off and remove the ignition
key.
[DR04350(ALL)11/94]
2. Reinsert the ignition key and turn clockwise
to the first position (OFF).
[DR04400(ALL)11/94]
3. Depress the brake pedal, move the gearshift
lever to N (Neutral) and start the engine.
*
[DR04425(ALL)07/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Taurus
in this Owner Guide for instructions on checking
and replacing fuses.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

193
*
[DR04451(ALL)09/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
%*
[DR04501(ALL)11/94]
Using a column-mounted gearshift
*
[DR04550(ALL)04/95]
If your gearshift is on the column, you can use
any of the following positions:
[DR04601(ALL)11/94]
one third page art:0000491-E
The column-mounted gearshift
*
[DR04650(ALL)01/95]
Once you place the gearshift securely into
position, gradually release the brake pedal and
use the accelerator as necessary.
%*
[DR05100(ALL)01/95]
R (Reverse)
*
[DR05200(ALL)08/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[DR05250(ALL)01/95]
N (Neutral)
*
[DR05275(ALL)01/95]
With the gearshift in the N (Neutral) position,
the vehicle can be started and is free to roll.
Hold the brake pedal down while in this
position.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com

194 %
*
[DR05300(ALL)01/95]
Driving
%*
[DR05400(ALL)04/95]
When to usej(Overdrive)
*
[DR05500(ALL)04/95]
j(Overdrive) is the usual driving position for
an automatic overdrive transaxle. It works the
same way D (Drive) works, automatically
upshifting or downshifting as the vehicle speeds
or slows.
*
[DR05600(ALL)04/95]
However,j(Overdrive) also shifts into a fourth
gear Ð an overdrive gear Ð when your vehicle
cruises at a consistent speed for any length of
time. This fourth gear will increase your fuel
economy when you travel at cruising speeds.
*
[DR05800(ALL)06/95]
When to use D (Drive)
[DR06000(ALL)12/95]
D (Drive) eliminates the excessive shifting
between third and fourth gears that your vehicle
sometimes does when you are traveling through
hilly terrain inj(Overdrive). It also provides
more engine braking thanj(Overdrive) for
descending hills or city driving.
*
[DR06100(ALL)06/95]
When to use 1 (First)
*
[DR06200(ALL)11/94]
Use 1 (First) when added engine braking is
desired when descending steep hills.
*
[DR06220(ALL)11/94]
The automatic transaxle will shift to the proper
gear to ascend any grade without any need to
shift to 1 (First).
[DR06300(ALL)04/95]
Do not go faster than 38 mph (61 km/h) in this
gear. You can upshift from 1 (First) to D (Drive)
or from 1 (First) toj(Overdrive) at any speed.
*
[DR06400(ALL)01/95]
P (Park)
*
[DR06500(ALL)11/94]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transaxle and prevents the front wheels from
rotating.
File:10fcdrt.ex
Update:Mon Jan 22 15:59:33 1996
ProCarManuals.com
