Checking and Replacing Fuses
*
[SV35300(ALL)02/95]
If you need to check a fuse, follow these steps:
[SV35400(ALL)11/94]
1. Lift the handle of the fuse panel or power
distribution box to unlatch the cover.
[SV35600(ALL)11/94]
2. On the cover, find the fuse you want to
check. The diagram on the cover tells you
where to locate the fuse on the panel.
[SV35900(ALL)11/94]
3. Check the fuse to see if it is blown. To
remove the fuse, use the pulling tool
attached to the inside cover of the fuse
panel. Look through the clear side of the
fuse to see if the metal wire inside is
separated. If it is, the fuse should be
replaced.
*
[SV36000(ALL)10/95]
quarter page art:0030248-C
Fuse puller tool and fuse
*
[SV36100(ALL)11/94]
4. Replace the fuse with one that has the right
amperage rating. (See the following chart.)
[SV36200(ALL)04/95]
six pica chart:0001443-AFile:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
